[PPT] - Laplacian Regularized Few Shot Learning (LaplacianShot) Imtiaz PowerPoint Presentation

SLIDE 1

Laplacian Regularized Few Shot Learning (LaplacianShot)

Imtiaz Masud Ziko, Jose Dolz, Eric Granger and Ismail Ben Ayed

1

ETS Montreal

SLIDE 2

Overview

2

Few-Shot Learning

What and Why ?
Brief discussion
n existing

approaches.

Proposed LaplacianShot

The context
Proposed formulation
Optimization
Proposed Algorithm

Experiments

Experimental Setup
SOTA results on

5 different few-shot benchmarks.

SLIDE 3

Few-Shot Learning (An example)

3

SLIDE 4

Few-Shot Learning (An example)

4

Given C = 5 classes
Each class c having 1

examples. (5-way 1-shot) Learn a Model

From these

To classify this

SLIDE 5

Few-Shot Learning (An example)

5

From these

2 4

Given C = 5 classes
Each class c having 1

examples. (5-way 1-shot)

Learn a Model

To classify this

SLIDE 6

Few-Shot Learning

6

Humans recognize perfectly with few examples

2 4

SLIDE 7

Few-Shot Learning

7

❏ Modern ML methods generalize poorly ❏ Need a better way.

SLIDE 8

Few-shot learning

8

A very large body of recent works, mostly based on: Meta-learning framework

SLIDE 9

Meta-Learning Framework

9

SLIDE 10

Meta-Learning Framework

10

Training set with enough labeled data (base classes different from the test classes)

SLIDE 11

Meta-Learning Framework

11

Training set with enough labeled data to learn initial model

SLIDE 12

Meta-Learning Framework

12

Create episodes and do episodic training to learn meta-learner

Vinyal et al, (Neurips ‘16), Snell et al, (Neurips ‘17), Sung et al, (CVPR ‘ 18), Finn et al, (ICML‘ 17), Ravi et al, (ICLR‘ 17), Lee et al, (CVPR‘ 19), Hu et al, (ICLR ‘20), Ye et al, (CVPR ‘20), . . .

SLIDE 13

Taking a few steps backward . .

13

Recently [Chen et al., ICLR’19, Wang et al., ’19, Dhillon et al., ICLR’20] :

Simple baselines outperform the overly convoluted meta-learning based approaches.

SLIDE 14

Baseline Framework

14

No need to meta-train

SLIDE 15

Baseline Framework

15

Simple conventional cross-entropy training The approaches mostly differ during inference

SLIDE 16

Inductive vs Transductive inference

16

Query/Test point

Examples

Vinayls et al., NEURIPS’ 16 (Attention mechanism) Snell et al., NEURIPS’ 17 (Nearest Prototype) Supports

SLIDE 17

Inductive vs Transductive inference

17

Transductive: Predict for all test points, instead of one at a time

Query/Test points

Examples

Liu et. al., ICLR’19 (Label propagation) Dhillon, ICLR’20 (Transductive fine-tuning) Supports

SLIDE 18

Proposed LaplacianShot

18

Latent Assignment matrix for N

query samples:

Label assignment for each

query:

And Simplex Constraints:

Laplacian-regularized

bjective:

SLIDE 19

Proposed LaplacianShot

19

Laplacian-regularized

bjective:

Nearest Prototype classification When Similar to ProtoNet (Snell ’17) or SimpleShot (Wang ’19) Laplacian Regularization Well known in Graph Laplacian: Spectral clustering (Shi

I‘00, Von ‘07) , SLK

(Ziko ’18) SSL (Weston ‘12, Belkin

‘06)

SLIDE 20

LaplacianShot Takeaways

20

✓ SOTA results without bell and whistles. ✓ Simple constrained graph clustering works very well. ✓ No network fine-tuning, neither meta-learning ✓ Fast transductive inference: almost inductive time ✓ Model Agnostic

SLIDE 21

21

LapLacianShot More Details

SLIDE 22

Proposed LaplacianShot

22

Laplacian-regularized

bjective:

Nearest Prototype classification

Feature embedding:
Prototype can be :
The support example in 1-shot or
Simple mean from support examples or
Weighted mean from both support and

initially predicted query samples When Labeling according to nearest support prototypes

SLIDE 23

Proposed LaplacianShot

23

Laplacian-regularized

bjective:

Laplacian Regularization Well known in Graph Laplacian: Encourages nearby points to have similar assignments Pairwise similarity

SLIDE 24

Proposed Optimization

24

Laplacian-regularized

bjective:

Tricky to optimize due to:

SLIDE 25

Proposed Optimization

25

Laplacian-regularized

bjective:

Tricky to optimize due to: ✖ Simplex/Integer Constraints.

SLIDE 26

Proposed Optimization

26

Laplacian-regularized

bjective:

Tricky to optimize due to: ✖ Laplacian over discrete variables.

SLIDE 27

Proposed Optimization

27

Laplacian-regularized

bjective:

Relax integer constraints: ➢ Convex quadratic problem

✖ Require solving for the N×C variables all together ✖ Extra projection steps for the simplex constraints

SLIDE 28

Proposed Optimization

28

Laplacian-regularized

bjective:

We do: ✓ Concave relaxation

✓ Independent and closed-form updates for each assignment variable ✓ Efficient bound optimization

SLIDE 29

Concave Laplacian

29

SLIDE 30

Concave Laplacian

30

= = When Equal

SLIDE 31

Concave Laplacian

31

= When

Not Equal

SLIDE 32

Concave Laplacian

32

= When

Not Equal

Degree

฀฀ ฀฀

SLIDE 33

Concave Laplacian

33

=

Remove constant terms

SLIDE 34

Concave Laplacian

34

Concave for PSD matrix

SLIDE 35

Concave-Convex relaxation

35

Convex barrier function:

Avoids extra dual variables for
Closed- form update for the simplex constraint duel

Putting it altogether

SLIDE 36

Bound optimization

36

First-order approximation

f concave term

Fixed unary

SLIDE 37

Where:

Bound optimization

37

We get Iterative tight upper bound:

Iteratively optimize:

SLIDE 38

Bound optimization

38

Independent upper bound:

SLIDE 39

KKT conditions brings closed form updates:

Bound optimization

39

Minimize Independent upper bound:

SLIDE 40

LaplacianShot Algorithm

40

SLIDE 41

Experiments

41

Datasets:

1. Mini-ImageNet 2. Tierd-ImageNet 3. CUB 200-2001 4. Inat

Generic Classification miniImageNet splits: 64 base, 16 validation and 20 test classes tieredImageNet splits: 351 base, 97 validation and 160 test classes Fine-Grained Classification Splits: 100 base, 50 validation and 50 test classes

SLIDE 42

Experiments

42

Datasets:

1. Mini-ImageNet 2. Tierd-ImageNet 3. CUB 200-2001 4. Inat

Evaluation protocol:

5-way 1-shot/5-shot .
15 query samples per class

(N=75).

Average accuracy over 10,000

few-shot tasks with 95% confidence interval.

SLIDE 43

Experiments

43

Datasets:

1. Mini-ImageNet 2. Tierd-ImageNet 3. CUB 200-2001 4. Inat

More realistic and challenging
Recently introduced (Wertheimer&

Hariharan, 2019)

Slight class distinction
Imbalanced class distribution with

variable number of supports/query per class

SLIDE 44

Experiments

44

Datasets:

1. Mini-ImageNet 2. Tierd-ImageNet 3. CUB 200-2001 4. Inat

Evaluation protocol:

227-way multi-shot .
Top-1 accuracy averaged over

the test images Per Class.

Top-1 accuracy averaged over all

the test images (Mean)

SLIDE 45

Experiments

45

We do Cross-entropy training with base classes LaplacianShot during inference

SLIDE 46

Results (Mini-ImageNet)

46

SLIDE 47

Results (Mini-ImageNet)

47

SLIDE 48

Results (Tiered-ImageNet)

48

SLIDE 49

Results (CUB)

49

Cross Domain

SLIDE 50

Results (iNat)

50

SLIDE 51

Ablation: Choosing

51

SLIDE 52

Ablation: Convergence

52

SLIDE 53

Ablation: Average Inference time

53

Transductive

SLIDE 54

LaplacianShot Takeaways

54

✓ SOTA results without bell and whistles. ✓ Simple constrained graph clustering works very well. ✓ No network fine-tuning, neither meta-learning ✓ Fast transductive inference: almost inductive time ✓ Model Agnostic: during inference with any training model

and gain up to 4/5%!!!
