H-1: Kuykendahl Road Collector Network (bounded by Grand Pkwy, FM 2920, Root Road and Northcrest Drive) Harris County Engineering Department 48

Location • [Insert location map] 49

H-1: Kuykendahl Collector Network 50

Plats and GP previously submitted around Kuykendahl Collector Network area 51

Request Add Avalon Lake Crest Drive as a Minor Collector (MN-2- • 60) from the Grand Parkway frontage Road to Root Road Add unnamed NW-SE Road as a minor collector (MN-2- • 60) from proposed Avalon Lake Crest Drive to proposed Creekside Timbers Drive ( Two alternatives are proposed for connection to proposed Avalon Lake Crest Drive) Add Creekside Timbers Drive as a minor collector (MN-2- • 60) from east of Willow Edge Drive to proposed Klein Oak Lane Add Klein Oak Lane as a Minor Collector (MN-2-60) from • Dowdell road to Northcrest Drive 52

Name 2017 MTFP Existing Conditions Proposed MTFP Classification Classification N/A Avalon Lake Crest N/A MN-2-60 Drive N/A NW-SE Minor N/A MN-2-60 Collector 50-55 ft, 2 lanes; Portion N/A Creekside Timbers N/A MN-2-60 Drive 50 ft, 2 lanes; Portion N/A Klein Oak Lane N/A MN-2-60 53
