Development of New Generation of Ester Plasticizers for High Temperature Ethylene Acrylic Elastomers

2

Agenda

• Background on EAM elastomers
• Plasticizer for high-temperature AEM applications
• Goal of the project
• Overview of the experimental plan
• Results and discussion
• Conclusions
• Acknowledgements

3

Background on AEM Elastomers

• AEM are used in applications requiring continual service up to 175°C and

intermittent exposure to extremely high temperatures of up to 200 °C

• Lower cost alternatives to FKM and FVQM
• Exhibit improved high temperature resistance over HNBR and ECO
• There are two well known types:

– ACM (Acrylic Co-Monomer) – AEM (Acrylic-Ethylene Monomer)

4

Background on AEM Elastomers

• Conventional CB and Silica fillers provide stiffness in AEM compounds but

– Accelerate oxidative degradation – Reduce thermal stability

• DuPont™ developed novel melt-blending technology which allowed reinforcement of AEM

with a dispersion of grafted PA6 droplets

• DuPont™ VMX 5000 elastomers are based on amine cure system
• Result is a strong, heat-resistant elastomer compound with good heat-aging and compression

set properties

• Enhanced performance is due to

– Extensive AEM-PA6 grafting – Absence of filler-filler contacts – Beneficial modification of oxidation profile under diffusion-limited conditions

5

Plasticizer for high-temperature AEM applications

• Highly polar AEM elastomers require higher-polarity ester plasticizers to

assure optimal compatibility

• Due to the high post-cure and application temperature requirements few

plasticizer have found utility in demanding AEM applications

• Polar monomeric plasticizer have good low temperature properties but suffer

from higher weight losses during high temperature aging

• Polar high MW plasticizer have good permanence but lack optimal low

temperature flexibility

6

Goal of the Project

• To develop new generation of high-performance ester modifiers and help

expand modifier options for the acrylic elastomer market.

7

Experimental Plan – Part I

SAMPLES USED IN THIS STUDY

8

Testing

9

Original Properties – Part I

TegMeR 812 RX-14434 RX-14565 RX-14562 No plasticizer Stress @ 100% Elongation, MPa 2.1 2.0 2.4 2.2 3.0 Stress @ 200% Elongation, MPa 5.6 6.2 7.1 6.6 9.1 Stress @ 300% Elongation, MPa 10.3 11.9 12.6 12.1 15.1 Tensile Ultimate, MPa 13.8 15.6 14.6 14.6 16.2 Elongation @ Break, % 382 367 348 359 318 Hardness Duro A, pts. 60 60 63 58 65 Specific Gravity 1.078 1.078 1.078 1.078 1.079

10

Heat Aging – Weight Change, Part I

• 1.6
• 1.4
• 1.2
• 1
• 0.8
• 0.6
• 0.4
• 0.2

0.2 0.4 TegMer 812 RX-14434 RX-14565 RX-14562

Weight Change, % (Normalized)

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

• Neat AEM polymer exhibited

some weight loss so all of the data were normalized.

• Normalized data helped

elucidate performance differentiation between the 4 samples used in this study

11

Heat Aging – Volume Change, Part I

• 1.5
• 1
• 0.5

0.5 1 TegMeR 812 RX-14434 RX-14565 RX-14562

Volume Change, % (Normalized)

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

• The compounds showing a

weight or volume “gain” are at low enough levels as to be considered equivalent with the control compound, effectively losing no weight or volume due to plasticizer loss

12

Heat Aging – Changes in Elongation, Part I

• 20
• 15
• 10
• 5

5 TegMer 812 RX-14434 RX-14565 RX-14562

Elongation Change, % (Normalized)

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

13

Heat Aging – Changes in Tensile Properties, Part I

20 40 60 80 TegMer 812 RX-14434 RX-14565 RX-14562

M100 Change, % (Normalized)

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

14

Heat Aging – Compression Set, Part I

5 10 15 20 25 TegMeR 812 RX-14434 RX-14565 RX-14562 None

Compression Set, %

Original 2 wk @ 190 C 4 wk @ 190 C

70 hrs at 150°C, under constant deformation

22.4 12.0 15.8 14.0 10.2 15.8 23.4 12.9 13.0 14.0 10.8 16.9 14.5 11.2 13.3

15

Original Tg, Part I

• As expected, TegMeR 812 is

most efficient at lowering Tg compared to experimental polymeric materials

• All provide good starting Tg
• 39
• 38
• 37
• 36
• 35
• 34
• 33
• 32

TegMeR 812 RX-14434 RX-14565 RX-14562

Original Tg, °C

• 38.46
• 35.68
• 35.64
• 34.58

Ramping -100 to 70 C @ 20 C/min

16

Heat Aging – Effect on Low Temperature, Part I

• TegMeR 812, while starting

with the lowest Tg, loses the most performance after aging

• RX-14562 retains the best

performance after aging

• 40
• 38
• 36
• 34
• 32
• 30
• 28

TegMeR 812 RX-14434 RX-14565 RX-14562 None

Tg, before and after aging, °C

Original 2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

17

Experimental Plan – Part II

SAMPLES USED IN THIS STUDY

• Based on results from Part I, the

formula was adjusted to increase plasticizer level

• RX-14562, as the best performing

material in Part I, is used as a control

18

Original Properties – Part II

RX-14562 RX-14600 RX-14601 RX-14602 RX-14603 No Plasticizer Stress @ 100% Elongation, MPa 2.6 2.7 3.1 2.8 2.7 4.4 Stress @ 200% Elongation, MPa 7.6 7.5 8.5 7.8 7.5 12.4 Stress @ 300% Elongation, MPa 12.8 13.2

• 13.2

12.5

• Tensile Ultimate, MPa

13.0 14.2 13.3 13.9 13.1 16.9 Elongation @ Break, % 305 320 293 316 308 275 Hardness Duro A, pts. 59 58 59 59 57 64 Specific Gravity 1.081 1.082 1.086 1.086 1.085 1.084

19

Heat Aging – Weight Change, Part II

• Neat AEM polymer exhibited

some weight loss so all of the data were normalized.

• Normalized data helped

elucidate performance differentiation between the 5 samples used in this study

• 3.5
• 3
• 2.5
• 2
• 1.5
• 1
• 0.5

RX-14562 RX-14600 RX-14601 RX-14602 RX-14603

Weight Change (Normalized), %

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

20

Heat Aging – Changes in Elongation, Part II

• 70
• 60
• 50
• 40
• 30
• 20
• 10

RX-14562 RX-14600 RX-14601 RX-14602 RX-14603 No Plasticizer

Elongation Change, %

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

• All plasticizers show good

behavior with elongation loss compared to non-plasticized control

• RX-14562 and RX-14600

show best retention of elongation after aging

21

Heat Aging – Changes in Tensile Properties, Part II

• 70
• 60
• 50
• 40
• 30
• 20
• 10

RX-14562 RX-14600 RX-14601 RX-14602 RX-14603 No Plasticizer

Tensile Change, %

2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

• All plasticizers show good

behavior with tensile strength loss compared to non- plasticized control

• RX-14562, RX-14600, and

RX-14602 show best retention of tensile strength after aging

22

Heat Aging – Compression Set, Part II

70 hrs at 150°C, under constant deformation

5 10 15 20 25 30 RX-14562 RX-14600 RX-14601 RX-14602 RX-14603 No Plasticizer

Compression Set

Originals 2 week aged 4 week aged

• Decrease in compression set

after aging in most cases likely due to increased cross- linking during aging

• Increase in set after aging

likely due to degradation

• RX-14602 overall best initial

compression set and retention after aging

23

Heat Aging – Effect on Low Temperature, Part II

• All plasticizers have excellent

initial low temperature properties

• RX-14562 and RX-14602
• ffer best retention of low

temperature properties after heat aging

• 43
• 41
• 39
• 37
• 35
• 33
• 31
• 29
• 27
• 25

RX-14562 RX-14600 RX-14601 RX-14602 RX-14603

Tg by DSC, C

Original 2 wk @ 190 C 3 wk @ 190 C 4 wk @ 190 C

24

Conclusions

• Plasticizers tested here offer better

performance than others in different aspects

• Overall, RX-14562, RX-14600, and

RX-14601 offer best maintenance of properties after extreme heat aging

• Adjusting molecular weight and

chemistries of polymeric materials can

• ptimize properties according to

application requirements
