SLIDE 1
DREDGING THE MIGHTY FRASER RIVER >
1
AGENDA > FRPD > About Us > Fraser River Dredging Program > Dredging > Why, where & how? > Dredging Materials Management > Questions
2
DREDGING THE MIGHTY FRASER RIVER > Port of Vancouver | Delta - - PowerPoint PPT Presentation
DREDGING THE MIGHTY FRASER RIVER > Port of Vancouver | Delta - - PowerPoint PPT Presentation
DREDGING THE MIGHTY FRASER RIVER > Port of Vancouver | Delta Community Office November 28, 2017 1 AGENDA > FRPD > About Us > Fraser River Dredging Program > Dredging > Why, where & how? > Dredging Materials Management
SLIDE 2
SLIDE 3
FRPD > About Us
3
SLIDE 4
Fraser River Pile & Dredge (GP) Inc. (FRPD) is one
- f Canada's largest Marine & Infrastructure, Land
Foundations and Dredging contractor.
4
SLIDE 5
5
- Marine Construction Capabilities for any size structure
- r facility on Canada’s West Coast
- 10 Marine Derricks to 350 Ton Craning Capacity
- 16 Cranes available for Land Foundation Projects up to
225 Ton Capacity
- Rock Drilling & Pile Socketing up to 1524 mm dia.
SLIDE 6
We are committed to providing to: > Our employees with a safe and rewarding place of employment and opportunities for ongoing professional growth; > Our customers with innovative and cost effective solutions through intelligent use of resources; and > Our communities with sustainable and environmentally sound business practices.
6
SLIDE 7
Fraser River Maintenance Dredging Program >
7
SLIDE 8
8
1900 1980 1998 1999 2010+
1900 – mid- 1980’s
> Federal government responsible for
- maint. dredging
> Administered by Public Works Canada (PWC) until mid-1980’s
1999 – 2010
> FRPD awarded 10 year maint. dredging contract (1999 – 2009) > 2006: FRPD awarded contract extension > 2008: Port amalgamation to
2010 – Current
> 2010: VFPA puts out RFP internationally > 2011: FRPD awarded 10 year maint. dredging contract (2012 – 2022)
Fraser River Maintenance Dredging Timeline
mid-1980’s
> FRPD begins maint. dredging (mid-1980’s – 1998)
1998
> Fraser River Port Authority (FRPA) now responsible for maint. dredging > FRPA puts out RFP for maint. dredging
SLIDE 9
Dredging > Why?
9
SLIDE 10
The Vancouver Fraser Port Authority (VFPA) is responsible for providing safe & unimpeded access for vessels to terminals at the Port of
- Vancouver. Ensuring appropriate water depth is a
primary component to this safe access and often requires dredging - the removal of sediment - from the Fraser River seabed. VFPA mandates that this dredging must be economically, environmentally and socially sustainable.
10
Port of Vancouver Dredging Philosophy
SLIDE 11
Dredging > Why?
Freshet*
*freshet: the flood of a river from heavy rain or melted snow
> The Fraser River
freshet typically occurs between May and July
- f each year
> The increased flow
rates transport sediments down the river
> This sediment
transport process is what creates “infill”
11
SLIDE 12
Dredging > Why?
> The Fraser River requires annual dredging because
- f the continuous
run-off of the river and the silt that is deposited from upstream as it nears the sea
12
SLIDE 13
Dredging > Why? Safe Navigation
> The Fraser River deep
sea shipping channel is vital to the Canadian economy
> This supports the Port’s
mandate to facilitate marine trade
> Provides access to river
terminals such as Fraser Surrey Docks and Annacis Auto Terminals
13
SLIDE 14
Dredging > Why? Flood Protection
>
Without dredging, the lower reaches of the river bottom would rise and therefore require higher dykes
>
The 200 year flood level predictions are based on the assumption that the dredging program continues
>
Upriver of Port Mann Bridge the river is managed by dykes
>
Downriver of the Port Mann Bridge the river is managed by dykes, training structures and dredging
14
SLIDE 15
Dredging > Where & When?
15
SLIDE 16
16
SLIDE 17
Dredging > Where? Survey Program
>
CCG through PWGSC runs their survey program which monitors the channel conditions
>
FRPD also conducts hydrographic surveys to monitor channel condition and determine dredging priorities
>
Both parties implement the latest survey/positioning technology available to produce the most accurate data for use in the setup
- f vessel traffic and in dredging
priorities
17
SLIDE 18
18
SLIDE 19
19
SLIDE 20
20
SLIDE 21
> Prior to dredging all activities require approvals
> Applications categorized from A to D > For material to be disposed at sea, the material requires chemical and physical testing and a DAS permit
21
SLIDE 22
Dredging > How?
22
SLIDE 23
> Equipment:
> Dredging requires intensive capital investment in equipment > FRPD owns and operates 3 types of dredges which conduct dredging operations in the Fraser River
23
SLIDE 24
Dredging Equipment Trailing Suction Hopper
“FRPD 309”
> Built 1983 > Purchased 2012 > 4,500 m3 capacity (450 dump trucks) > Load in approx. 1 hour > Either bottom dump of pump ashore to upland stockpile (1.5hrs) > Discharge pipe
diameter of 800mm
24
SLIDE 25
Dredging Equipment Cutter Suction
“Sceptre Columbia”
> Pumps 1,500m3/hour (150 dump trucks per hr) > Discharge pipe diameter 650mm > Can deliver sand to 2 kilometers through pipeline > Can either pump to upland stockpile or in- river disposal
25
SLIDE 26
Dredging Equipment Clamshell
> Bucket sizes vary > Places material in dump or flat scows > Material is typically taken to DAS - Ocean Disposal
26
SLIDE 27
Dredging Materials Management >
27
SLIDE 28
FRPD’s goal is to maximize beneficial use of dredged material in order to minimize ocean disposal. > The options for beneficial use are:
> Upland Placement – Construction Use > Land Reclamation > Environmental Habitat Creation
28
SLIDE 29
Dredging Materials Management Upland Placement
29
SLIDE 30
Dredging Materials Management Upland Placement
30
SLIDE 31
Dredging Materials Management Land Reclamation
31
SLIDE 32
Dredging Materials Management Environmental Habitat Creation
32
SLIDE 33
Questions >
33
