Define-XML Creation & Validation Anran Xie Agenda 1. Define-XML introduction 2. Building Define-XML 3. Define-XML Validation CDISC CDISC website www.cdisc.org Define-XML introduction CDISC

slide-1
SLIDE 1

满足递交标准的Define-XML Creation & Validation

Anran Xie

slide-2
SLIDE 2

Agenda

  • 1. Define-XML introduction
  • 2. Building Define-XML
  • 3. Define-XML Validation
slide-3
SLIDE 3

CDISC website www.cdisc.org

CDISC数据标准模块

slide-4
SLIDE 4

Define-XML introduction

  • CDISC XML Technology standard.
  • Provides machine readable metadata for SEND,

SDTM and ADaM datasets.

  • Provides a table of contents for people who need to

use CDISC datasets.

  • Formatting standard based on the CDISC ODM
  • Required by US FDA & PMDA for all CDISC

submissions.

slide-5
SLIDE 5
slide-6
SLIDE 6

Features

  • Platform independent
  • Vendor neutral
  • Open source
  • Machine readable
  • Easily transformed using XSL and other tools
slide-7
SLIDE 7
slide-8
SLIDE 8

ODM

Define- XML

SEND Metadata SDTM Metadata ADaM Metadata

Dataset- XML

SEND Data SDTM Data ADaM Data

slide-9
SLIDE 9

ODM Structure

ODM Study AdminData ClinicalData ReferenceData MetaDataVersion I nclude Protocol StudyEventDef FormDef I temGroupDef I temDef CodeList Presentation MethodDef ConditionDef

slide-10
SLIDE 10

Define-XML Structure

MetaDataVersion

def:AnnotatedCRF def:SupplementalDoc def:ValueListDef def:WhereClauseDef I temGroupDef I temDef CodeList MethodDef def:CommentDef def:leaf

Annotated case report forms Reviewers guide Value level metadata Where clause definitions Datasets Variable or value definitions Controlled terminology Computational algorithms Comments Referenced documents

slide-11
SLIDE 11

Latest status

  • Current version: Define-XML 2.1
  • Released: 8 May 2019

URL: https://www.cdisc.org/standards/data-exchange/define-xml)

  • Specification
  • XML Schema
  • Stylesheets
  • Examples
  • ADaM
  • SDTM
  • Includes XSL stylesheet
slide-12
SLIDE 12

Define-XML 2.1 Specification

slide-13
SLIDE 13

XML Schema

  • Definition:
  • XML documents that describe structure and

content for a specific type of XML document

  • Purpose:
  • Standardize contents of XML documents for a

specific use case.

  • XML namespace declarations
  • Define allowable elements and attributes
  • Define allowable datatypes for element and

attributes

  • Define relationships between elements and attributes
  • Define enumerations
  • Support validation of XML documents
slide-14
SLIDE 14

XSL-Extensible Stylesheet Language

  • XSL is a sophisticated transformation language

with many built in functions

  • Requires a tool known as XSLT processor –

included in most browsers

  • For Define-XML we use XSL to display the XML

file as a web page

<?xml version="1.0"?> <xsl:stylesheet version="1.0“ ... XML Docum ent New Docum ent XSL Docum ent

XSLT

Processor

slide-15
SLIDE 15

Before and After

slide-16
SLIDE 16
  • 1. Define-XML introduction
  • 2. Building Define-XML
  • 3. Define-XML Validation
slide-17
SLIDE 17
  • Define-XML Creation
  • Commercial applications
  • SAS Clinical Standards Toolkit
  • Pinnacle21 Community Version
  • Formedix
  • Xclinical Tabulator
  • XML4Pharma SDTM-ETL
  • CROs
slide-18
SLIDE 18

Process

SDTM/Adam Spec Datasets Control Terminology Excel Define Spec Define-XML P21 P21 macro macro

Define-XML creation process

aCRF Reviewers guide

slide-19
SLIDE 19

Spec template

slide-20
SLIDE 20

Excel Define-XML Spec Pinnacle 21 Spec template

slide-21
SLIDE 21

Spec to Define-XML Pinnacle 21 Define-XML Generator

slide-22
SLIDE 22
  • 1. Define-XML introduction
  • 2. Building Define-XML
  • 3. Define-XML Validation
slide-23
SLIDE 23

Define-XML conformity is define by

  • XML Syntactic & Semantic requirements defined by the Define-XML

schema

  • Define-XML Semantic requirements & Business rules defined by the Define-

XML 2.1 Specification

ValidationTools

  • Validating parsers
  • Pinnacle 21

Validation rules

  • SD: SDTM3.2，454个
  • AD: ADaM 1.1, 342条
  • DD: define.xml 2.0, 136条
slide-24
SLIDE 24

Pinnacle 21 Validator

slide-25
SLIDE 25

Validation Results

slide-26
SLIDE 26

Issue Details

slide-27
SLIDE 27

Validation Rules

slide-28
SLIDE 28

联系我们

讲者：彭瑞玲 手机：13426088975 邮箱：Ruiling.peng@improve-quality.com

数据•标准 数据•管理 数据•统计 数据•法规 数据•软件 数据中心 隔天更新 追踪法规 分享知识 提高质量

咨询电话： 010-5944 2174 咨询邮箱：info@improve-quality.com 公司网址：www.improve-quality.com

slide-29
SLIDE 29

Q & A
