Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 1

Crossing boundaries

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 2

Crossing Bounderies

Making KDE Technology Available to Embedded Devices Eva Brucherseifer basysKom GmbH 12.08.2008 aKademy 2008 l Just another Platform? l Strategies for cross device development l Example: Decibel l Benefit for KDE

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 3

Embedded Applications

l Consumer Devices

– Phone – Multimedia Devices – Children's PCs – Navigation System – Home Automation – Ticket Vending Machine

l Industry Applications

– Medical Industry: Ultrasonic – Production: Quality Assurance System for

Manufacturing Process

– Measurement: Network Analyser – Logistics: Storage Management – Automotive: Agricultural Tractors

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 4

Just another platform to compile on?

l Different hardware

– ARM, x86, PowerPC, SH4, Mips – Flash, GPS, Touch, ...

l Different Tools

– Crosscompiler, Remote Debugging, etc – Embedded Linux

l Less Ressources

– little MB

32-64 MB

– little MHz

150-800 MHz

– different capabilites

with/without FPU

– small amount of space

usually flash, 64 MB

– smaller screens

480x240, 800x600

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 5

Differences Desktop – Embedded Device

l Embedded Devices are specialised to enable single use cases l touch screen & small screen resolution require optimized user interfaces l Embedded devices are built by manufacturers Community devices usually not possible

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 6

KDE has a lot to offer

l Current Embedded Linux market:

– Qt offers a maintained and supported toolkit, Qt is preferred in industry

l KDE has rich and powerful functionality extending Qt

– with more powerful CPU functionality is becoming an option

l But:

– KDE components mostly unknown – KDE components have too many dependencies, no easy plug & play

l Required: more building blocks l some components are already on use:

– Frameworks: Phonon – Widgets: Webkit

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 7

Strategies for Cross-Device Development

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 8

Design Goals for Modular Components

l separate functionality from view l make integration optional l stabilize & test component APIs using unit tests

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 9

Strategy 1: D-BUS Services

l API as D-BUS specification l hide functionality in daemons l Good for

– data storage – system wide services

l Existing Examples:

– HAL – Strigi – Akonadi – Decibel

Application DBUS Service Daemon API bindings

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 10

Strategy 2: Plugins

l Plugins are libraries loaded on demand l one API with a variety of implementations l useful for

– optional functionality – optional integration

l Existing Examples:

– Passwort Storage: Plain Text vs. KWallet

API headers Plugin Plugin Application / Service Daemon

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 11

Strategy 3: Model-View Concepts

l Application implemented as Qt's model-view architecture l Model contains all data handling and core functionality l View can be replaced as needed for use case l Enables different views for Embedded /Desktop without much reimplementation / porting l Existing Examples:

– Plasma: DataEngines + Applets

View Model API Desktop View View Model API Embedded View

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 12

Application bindings Model API

Component Puzzle

l Putting it all together

DBUS Service Daemon API API headers Embedded Integration Desktop Integration bindings Embedded View Desktop View

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 13

Example: Decibel

l Communication Framework l building block for IM and VoIP applications

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 14

Classic Applications History

Wengophone Qt4, SIP KPhone Qt4, SIP Skype Qt4, proprietary PSI Qt4, Jabber qutim Qt4, AIM/ICQ sim-im Qt3, multi-protocol Kopete KDE4, multi-protocol Konversation KDE3, IRC KCall KDE3, SIP KCall for KDE4 KDE4, Decibel

Qt-based Realtime Communication Technologies Eva Brucherseifer

Design Goals

l Portable Works across platforms, desktops and devices l Integrated Seamlessly works with the environment of the user l Flexible

– Can handle different use-cases – Do not hard-code policy

l Minimal

– each component should be minimal and focus on its purpose – Less to code, test, debug and port

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 16

Password Mgt

Decibel Architecture

Telepathy

Jabber AIM/ICQ SIP

Decibel

Buddy List Chat Window Dial Dialog UI: Use Case Specific

Accounts Dispatching Contacts Presence Configuration

Addressbook

DBUS DBUS

Addressing Use Cases

l Embedded Chat Plain Text Jabber AIM/ICQ

Decibel

Embedded GUI Accounts Dispatching Contacts Presence Configuration Plain Text KWallet Jabber AIM/ICQ SIP

Decibel

Accounts Dispatching Contacts Presence Configuration Akonadi l KDE Desktop Chat+VoIP Full Desktop GUI

shared model

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 18

Benefit for KDE

l Faster way to address use cases and user requirements l Easier quality assurance l Enable industry to create more KDE devices :-)

Crossing Boundaries Eva Brucherseifer 12.08.2008 Seite 19

Contact

l Eva Brucherseifer

eva.brucherseifer@basyskom.de eva@kde.org

l basysKom is hiring!

– Qt Consulants – KDE Consultants – Squish Consultants
