COSMOS X-Haul Overview

Dan Kilper dkilper (at) optics (dot) Arizona (dot) edu

X-Haul Network

Provide experimenter customizable and sliceable front- /mid-/back-haul network and edge cloud research platform supporting research on:

• High capacity, low latency radio/edge cloud networks
• mmWave and fiber convergence
• Optical networking
• SDR/SDN and cloud computing
• Testbed control and management

Fronthaul Networks (d-RoF)

3

• T. Pfeiffer JOCN 2015

Midhaul Networks

4

Fronthaul Connection Midhaul Connection ONDM 2018

Split PHY Processing

5

Small Cell Forum 2016

Saving Capacity

• Adding midhaul

processing reduces wavelength blocking

• Reduced BW &

Improved efficiency

• Additional latency

6

Offered Load (Erl)

Wavelength Blocking Probability (%)

Fronthaul Midhaul ONDM 2018

COSMOS Network

Mudd Nash 560 Riverside Drive CC @NYU – 32 AoA CC @Columbia CC @Rutgers NAC SSA Studebaker

Site Ownership:

DOE CU NYCHA CCNY Lightower

COSMOS Network

Optical Switching

• Use both for configuring topology for

different/concurrent experiments & converged wireless/optical experiments

– Slicing by wavelength or space

• Stackable whitebox ROADM 1 RU

– Switching time:

• ~ 1 second

– Includes optical amplifiers – SDN controlled

• High port count space switch

– Switching time: ~ 100 ms – SDN controlled

Lumentum ROADM Calient Space Switch

ROADM Module

Thru In1 Thru In2 Add1 Thru Out1 Drop1 D1 D2 Thru In2 Add1 Thru Out1 Drop1 Thru In1 Thru Out2 Thru Out2 Line In Osc In Osc Out Line Out Osc OSP Out OSP Out Aux OSP Out Mon OSP In OSP In Aux OSP In Mon C In C Out Line In Osc In Osc Out Line Out Osc OSP Out OSP Out Aux OSP Out Mon OSP In OSP In Aux OSP In Mon C In C Out

Lumentum 96 WDM Channels X6 Fiber pairs 576 Connections Flex-grid & Colorless 20 Add/Drop/Thru ports

Front-Haul/CoMP

100G 10G

ROADM

3D MEMS

Ethernet

BBU/Server

100G 10G

WDM PON ROADM

3D MEMS

Ethernet

BBU/Server

• T. Bierman, et. al. Comm Mag. 2013

Reconfiguration space switching

• n ms time scales

ROADM/WDM wavelength switching on second timescales

Converged mmWave/Fiber Transmission

12

OE EO EO OE EO OEO l1 mmWave Mesh mmWave Also consider digital RoF BBU Pool WDM Switch OE EO EO OEO l1 mmWave E EO l3, l4 mmWave l1 l1, l2, l3, l4 PON Splits E EO l2 mmWave WDM Switch/Split WDM/TDM PON WDM/mmWave Mesh Network BBU Pool Pi, BER, EVM Pi Pi Pi Pi Pi, BER, EVM Pi Pi, li

Programmable Topologies

13

CC @NYU – 32 AoA CC @Columbia 6 Fiber Pairs

Programmable Topologies

14

CC @NYU – 32 AoA CC @Columbia

Programmable Topologies

15

CC @NYU – 32 AoA CC @Columbia

PON

16

CC @NYU – 32 AoA CC @Columbia OLT ONU PON Split 1 km 10 km

Long Reach PON

17

CC @NYU – 32 AoA CC @Columbia OLT ONU PON Split 1 km 10 km

WDM PON

18

CC @NYU – 32 AoA CC @Columbia OLT2 ONU PON Split 1 km 10 km OLT1

MidHaul Network

19

CC @NYU – 32 AoA CC @Columbia 1 km 10 km

Converged mmWave/Fiber Transmission

Mudd Hall Studebaker Hall Access Point Fixed Wireless Link Fixed Wireless Link Edge Data Center Wavelength Switches Eth Switch Optical Switch Columbia Univ. CCNY Campus Harlem Street Location S2, C2 S5, C5

mmWave Analog RoF

• Ultra-low latency, simple radio head

– No digitization until data center

• COSMOS: Sub-6 GHz, plus select routes to 40 GHz

– Can mix down from higher frequencies

• Other bands?

(Figure courtesy of A. Kanno, NICT)

Other Unique Capabilities

• Free space optical

– High performance, long distance – Low cost, short distance

• Hybrid mmWave/FSO
• 100G coherent
• 10G SFP+ OTN
• Fast tunable laser-based switching (~ns)

Advanced Free Space Optical Link Juniper Menara IPG Koruza

FMF/SMF To RRH To RRH FMF/SMF Lens/Lantern Lens/Lantern Active Mirror Active/ Deform. Mirror Wavefront Sensor & Control Expander

QUESTIONS?

23
