VEM-Group Company Presentation www.vem-group.com VEM-Group Who we are VEM: V ereinigter E lektro- M aschinenbau (United Electrical Machinery) a globally active mid-sized company with German roots successful on the market under the

slide-1
SLIDE 1

www.vem-group.com

VEM-Group Company Presentation

slide-2
SLIDE 2

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Who we are

  • VEM: Vereinigter Elektro-Maschinenbau (United Electrical Machinery)
  • a globally active mid-sized company with German roots
  • successful on the market under the group brand name VEM – since privatisation in 1997

Product Range

  • Motors from 0.06 kW to 60 MW, generators up to 90 MVA and components for drive systems and power generation
  • Controlled electrical drives systems
  • Special motors and machines to customer specifications
slide-3
SLIDE 3

electrical engineering tradition

countries

with manufacturing facilities and subsidiaries countries on the export list motivated employees worldwide range of electrical drive systems, special motors and special machines Tonnes in motion production space

m²

about

million

turnover

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

since

  • ver

motors generators

up to

1886 8 90 1,500

0.06 kW – 60 MW 300 110,000

200

up to 90 MVA

slide-4
SLIDE 4

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Low voltage machines VEM motors VEM motors Thurm High voltage machines & Controlled drives VEM Sachsenwerk

VEM GmbH

Sales and technical support Austria, Belgium, Brazil, Canada, Chile, China, Czech Republic, Denmark, Egypt, Finland, France, Germany, Great Britain, Greece, Hong Kong, Hungary, Iceland, India, Indonesia, Iran, Iraq, Italy, Japan, Morocco, Mexico, Netherlands, Norway, Poland, Portugal, Romania, Russia, Saudi Arabia, Singapore, Slovakia, South Africa, Spain, Sweden, Switzerland, Thailand, Turkey, Ukraine, United Arab Emirates, USA, Yemen Production VEM Tschechien s.r.o. VEM Slovakia s.r.o.

Structure including subsidiaries

VEM Subsidiaries

slide-5
SLIDE 5

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

From the origins to the present day

Founding of the

  • riginal precursor
  • f VEM

Sachsenwerk GmbH

1886

Founding of „Sachsenwerk, Licht- und Kraft-AG“

1903

Founding of the

  • riginal precursor of

VEM motors Thurm GmbH Founding of the

  • riginal precursor
  • f VEM motors

GmbH Formation of VEM VVB as an association of nationally-owned enterprises in electrical engineering Development of mercury-arc converters by the company “Gleichrichterbüro Berlin- Schöneweide” Founding of VEM Trademark Association First stock corporation in Eastern Germany after German unification: VEM Antriebstechnik AG, with VEM Sachsenwerk GmbH, VEM Elektromotorenwerk Wernigerode GmbH and VEM Eletromotorenwerk Thurm GmbH Privatisation through acquisition

  • f the companies by

the Merckle family Acquisition of transresch Antriebssysteme Berlin GmbH Acquisition of VEM-group by the Wang family

1908 1938 1948 1949 1961 1990 1997 2011 2017

What began with a single factory in 1886 has since developed into a strong VEM Group, one of the branch‘s leading European manufacturers.

slide-6
SLIDE 6

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

VEM supplies the branches

Transportation Machine and plant engineering Steel and rolling mills Cement and mining industry Shipbuilding Chemical, oil and gas industry Water management Renewable energies Power plant technology Customer service

slide-7
SLIDE 7

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Sales and technical support worldwide

VEM has sales and service sites in North and South America, Europe, Africa and Asia.

slide-8
SLIDE 8

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Approvals and certificates

Quality, environmental and energy management

  • DIN EN ISO 9001, DIN EN ISO 14001, DIN EN ISO 50001
  • IRIS – International Railway Industry Standard

Equipment for use in areas subject to explosion hazard

  • Europe: ATEX Directive 2014/34/EU
  • China: NEPSI for motors for explosion protection types “n” (non-sparking)

to EN 60079-15:2010 and “ec” (increased safety) to EN 60079-7:2015

  • Russia (Customs Union): EAC Ex certificate

Approvals of international marine classification societies

  • Bureau Veritas (BV)
  • Det Norske Veritas·Germanischer Lloyd (DNV·GL)
  • Lloyd's Register of Shipping (LRS)
  • Russian Maritime Register of Shipping (RMRS)
  • China Classification Society (CCS)
  • American Bureau of Shipping (ABS)
slide-9
SLIDE 9

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Approvals and certificates

Product-specific approvals and certificates for selected countries

  • EAC declaration for the Russian Customs Union
  • UL approval for low-voltage motors

Sizes 56 to 400 for the USA and Canada

  • CSA approval for low-voltage motors

Sizes 112 to 315 for Canada and the USA

  • CSA approval (EEV) for energy-saving motors

Sizes 112 to 315 (“Energy Verified”)

  • DoE approval (CC301B) for energy-saving motors

Sizes 112 to 315

  • CCC – China Compulsory Certificate
  • CEL – China Energy Label
slide-10
SLIDE 10

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Warenzeichenverband VEM e.V.

  • 1948: Existence of the brand name VEM
  • 1954: Use of the brand name as a trademark
  • 1961: Founding of the Trademark Association
  • 81 trademark registration in 67 countries.

The protection focuses on classes 7 and 9.

slide-11
SLIDE 11

VEM-Group

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Manufacturing sites

Low voltage machines VEM motors GmbH, Wernigerode (Germany) VEM motors Thurm GmbH, Zwickau (Germany) Sales 2018: 104 Mio. Euro Large drives systems – Electrical machines & Controlled drives VEM Sachsenwerk GmbH, Dresden (Germany) Sales 2018: 102 Mio. Euro Components VEM Slovakia s.r.o., Piešťany (Slovakia) VEM Tschechien s.r.o., Most (Czech Republic)

slide-12
SLIDE 12

www.vem-group.com

Large Drives

VEM location Dresden

slide-13
SLIDE 13

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Facts

  • Founded in 1903
  • Engineering, manufacturing and

sales of motors and generators (synchronous und asynchronous)

  • Power range: 60 kW – 60 MW
  • Custom and serial production
  • Planning, development and manufacturing of

drive systems and components

VEM Sachsenwerk GmbH

slide-14
SLIDE 14

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Application Machine type Power Industry Mill stand, edger, winders, rolling, mills, cement mills, mining, wood processing plants, pumps and compressors, fans, mixers, mills, crushers Three-phase synchronous and asynchronous motors in medium and high-voltage version, Controlled three-phase drives up to 60 MW Power plants – including units, pumps and fans Three-phase asynchronous motors auxiliary plant machines in medium and high-voltage version up to 20 MW up to 18 MW Conveyor and transport systems, Cranes and excavators, Lifting equipment Three-phase synchronous and asynchronous motors in medium and high-voltage version up to 25 MW

Product range large drives

slide-15
SLIDE 15

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Application Machine type Power Ship building Offshore and barge building Three-phase synchronous and asynchronous motors in medium and high-voltage version Three-phase synchronous generators POD drives up to 25 MW Energy Power plants including Aggregates, pumps and fans Three-phase asynchronous motors auxiliary machines in medium and high-voltage version up to 20 MW up to 18 MW Wind power Wind power generators 1.5 – 7 MVA Generators Synchronous generators up to 90 MVA

Product range large drives

slide-16
SLIDE 16

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Application Machine type Power Transportation Mainline and industrial locomotives of all tractions Three-phase asynchronous traction motors Three-phase synchronous traction and machines mains generators up to 1,600 kW up to 3,000 kVA Multiple units

  • electric
  • diesel-electric
  • diesel-hydraulic

Three-phase asynchronous traction motors Three-phase synchronous traction generators Three-phase synchronous machines mains generators up to 600 kW up to 1,000 kVA up to 300 kVA Rapid transit railway, Trams, Monorails, Trolley buses, hybrid busses, Mining trucks Three-phase asynchronous drive motors Three-phase asynchronous drive motors Three-phase asynchronous drive motors Three-phase asynchronous drive motors Three-phase synchronous traction generators up to 250 kW up to 130 kW up to 125 kW up to 250 kW up to 4,000 kVA

Product range large drives

slide-17
SLIDE 17

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Products for industry

Synchronous and asynchronous motors

  • Steel and rolling mills
  • Cement and mining industry
  • Engineering and plant construction
  • Paper and cellulose industry
  • Water management

Asynchronous motor

slide-18
SLIDE 18

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Reference steel and rolling mills

Alstom Power Conversion GmbH, Böhler Kapfenberg, Austria

Type: DMMYZ 3860-20V Rolling mill drive 6,000 kW, 2,850 V, 35/100 r.p.m.

SMS Demag AG, MMK5000, Russia

Type: DMMYZ 3867-20V, Rolling mill drive 12,000 kW, 3,000 V, 60 r.p.m.

slide-19
SLIDE 19

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References cement and mining industry

FLSmidth A/S, Obajana, Nigeria

Type: DSRAS 8031-6WF Cement mill drive 3,000 kW, 11,000 V, 994 r.p.m.

FLSmidth A/S, Kokshe, Kazakhstan

Type: DSRCJ 8031-6WF Mill drive 3,316 kW, 6,000 V, 995 r.p.m.

OAO Severnyj Gorno-Obogatitjel, Sevgok, Ukraine

Type: DBKAJ 9030-8WF Fan drive 4,500 kW, 6,000 V, 744 r.p.m.

slide-20
SLIDE 20

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Products for ship building

Synchronous and asynchronous motors, synchronous generators

  • Passenger ships
  • Service ships
  • Megayachts
  • Specialist ships
  • Ferries
  • Cargo ships

Synchronous motor

slide-21
SLIDE 21

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References cruise liners and yachts

Siemens AG, AIDA Cruises, Hamburg Germany

Type: DTMSZ 3352-16YS Propeller drive 12,500 kW, 3,200 V, 131 r.p.m.

Wärtsilä SAM Electronics GmbH, Lürssen shipyard, Megayacht, Bremen, Germany

Type: DKMEF 1241-16V Propeller drive 6,000 kW, 4,160 V, 250 r.p.m. Type: DTMSZ 3466-16YS Propeller drive 18,000 kW, 4,300 V, 133 r.p.m.

Wärtsilä SAM Electronics GmbH, Fincantieri shipyard, Princess Cruises 1, Italy

slide-22
SLIDE 22

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References ferries and cargo ships

Schottel GmbH, „Fjord“, shipyard Norway

Type: DKWUZ 7131-8U Propeller drive 2,700 kW, 675 V, 800 r.p.m.

Wärtsilä SAM Electronics GmbH, container ship for Hapag Lloyd HHI shipyard, Korea

Type: DGMUX 1645-16W Shaft generator 5,000 kVA, 6,400 V, 65 – 94 r.p.m.

slide-23
SLIDE 23

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Products for the energy sector

Synchronous and asynchronous motors for

  • Chemical, oil and gas industry
  • Power plant technology

Synchronous and asynchronous generators

  • Wind power
  • Hydro-electric

Asynchronous generator

Ignition protection categories Ex n (Non sparking), Ex e (increased safety) Ex d (flameproof enclosure), Ex p (pressurised enclosure)

slide-24
SLIDE 24

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References chemicals, oil and gas

Siemens AG, Tasnee, Saudi-Arabia

Type: DTKVY 4344-36WS Piston compressor drive (hyper) 27,500 kW, 10,000 V, 200 r.p.m. Ex p

Salzgitter Anlagenbau GmbH, „285-LDPE-Anlage“ Basell, France

Type: DTKVY 4937-30W Piston compressor drive (hyper) 23,500 kW, 11,000 V, 200 r.p.m. Ex p

Burckhardt Compression, „Reliance“, LDPE plant in Jamnagar, India

Type: DTKVY 4356-30WS Compressor drive 30,000 kW, 11,000 V, 200 r.p.m. Ex p

slide-25
SLIDE 25

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References power plant technology

RWE Industrie-Lösungen GmbH, REA Cottam, U. K.

Type: DKKES 1040-8WE Induced-draft fan drive 8,000 kW, 11,000 V, 745 r.p.m.

E.ON Kraftwerke GmbH, Kraftwerk Datteln, Germany

Type: DKKGU 1040-4WE Feed water pump 14,500 kW, 10,000 V, 1,484 r.p.m.

Cegelec-AEG Berlin, Power plant Opole, Poland

Type: DKKAB 8033-8U Induced-draft fan drive 4,500 kW, 2x 800 V, 747 r.p.m.

slide-26
SLIDE 26

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References wind power generators

Senvion S. A. (formerly REpower Systems SE) 5M – 5.4 MW

Wind park alpha ventus

Senvion S. A. (formerly REpower Systems SE) Wind park „Thornton Bank“, North Sea

5.4 MW, 950 V, 1,170 r.p.m. 6.5 MW, 6,600 V, 1,170 r.p.m.

Senvion S. A. (formerly REpower Systems SE) Wind park „Nordsee Ost“, North Sea

slide-27
SLIDE 27

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References hydro-electric generators

Vattenfall, pumped-storage power station, Goldisthal, Germany

Power (G) 331 MVA 340.4 MVA Power (M) 261 MW 300 MW/351.6 MVA Voltage 18.0 kV 18.0 kV Speed 333.3 r.p.m. 300.0 – 346.6 r.p.m.

Vattenfall, pumped-storage power station, Germany

Power (G) 50 MVA Power (M) 40 MW Voltage 10.5 kV Speed 250 r.p.m.

slide-28
SLIDE 28

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Products for traction

Traction motors as well as main and auxiliary generators

  • Mainline and industrial

locomotives of all tractions

  • Multiple units
  • Rapid transit railway
  • Trams
  • Monorails
  • Trolley buses, hybrid buses
  • Mining trucks

Traction motor

slide-29
SLIDE 29

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References suburban trains and trams

Bombardier Transportation, Flexity Swift, Docklands LRT, London

Type: DKOBZ 0610-4B AC traction motor 130 kW, 1,781 r.p.m.

PESA Bydgoszcz, Poland, Tram Swing, Szeged, Hungary

Type: DKCBZ 0211-4FA AC traction motor 105 kW, 1,777 r.p.m.

slide-30
SLIDE 30

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References electric multiple units and locomotives

ELIN EBG Traction, Austria

Multiple-unit train E-Talent, Rh 4024 Type: DKLBZ 0911-4A AC traction motor 340 kW, 1,963 r.p.m. Type: DKCBZ 0211-4FA AC traction motor 105 kW, 1,777 r.p.m.

Asynchronous traction motors

slide-31
SLIDE 31

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References hybrid buses and mining trucks

Vossloh Kiepe, Düsseldorf, Hess Hybridbus, Dresden/Leipzig

Type: DKLBZ 0309-4 AC traction motor 160 kW, 1,466 r.p.m.

Siemens Energy & Automation, USA, Komatsu 960E, 3650HP

Type: DRLDZ 5013-8L Synchronous main alternator 2,506 kVA, 1,800 r.p.m.

slide-32
SLIDE 32

www.vem-group.com

Controlled Drive Systems

VEM location Dresden

slide-33
SLIDE 33

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Product range controlled drives systems

Component Power Drive systems for DC and Three-phase installations with Thyristor converters for DC drives 100 kW – 28 MW LV frequency converters 380 V – 690 V 4.5 kW – 4.5 MW MV frequency converters 2.3 kV – 6.9 kV 315 kW – 27 MW Subsynchronous converter cascades (SCC) 500 kW – 12 MW Excitation devices for synchronous machines Automation systems Development of complete automation systems for primary industry (metallurgy/cement) Reconstruction of old systems based on PLC and visualisation systems (SIMATIC S7, SIMATIC TDC, WinCC) Other services Commissioning and support worldwide Certification of explosion-protected drive systems

slide-34
SLIDE 34

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

  • 2 AFE frequency converters LC 690 V, 600 kW incl. feeder cubicle 1,200 A
  • Installed in a 20-foot marine container, insulated, climate-controlled
  • Configuration with sine-wave filter and EMC filter for first environment
  • Completion within 9 weeks

References pump drives for drilling test stand

Pump drives for drilling test stand

slide-35
SLIDE 35

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

  • Replacement of drive systems and automation while retaining the existing motors,

transformers, power cables and operating points: NEW DRIVE

References and products

Cable entries, motor (location identical to existing drive) Cable entry, mains (location identical to existing drive) Cable entry, mains (location identical to existing drive)

Customer: Abu Dhabi Polymers (BOROUGE)

slide-36
SLIDE 36

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

  • Converter-fed drive: 2,400 kW, 690 V, 12-pulse
  • Drive for the main fan of the vertical mill

References and products

Customer: Kordestan Cement

slide-37
SLIDE 37

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References and products

Customer: Storengy – Project: Peckersen natural-gas cavern storage

  • Converter-fed drive: 2,800 kW, 690 V, 12-pulse
  • Frequency converter for piston compressor

motor EEXE

  • Replacement of drive system while retaining

the existing motors, transformer

  • Power cables and operating points
slide-38
SLIDE 38

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References and products

Subsynchronous converter cascade (SCC) For the speed regulation of asynchronous slip ring motors, for motor outputs of 500 kW up to 12 MW

Principle

Retrofit of water supply, Saudi-Arabia

Reference Retrofit of water supply in Saudi Arabia, for an output of 11,5 MW Special feature Design dimensions of SCC as for old system

slide-39
SLIDE 39

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References and products

Power converters for DC roll stand drive Reference: Hoesch Spundwand und Profil GmbH Output: 2 x 2,500 kW

Water-cooled power sections

slide-40
SLIDE 40

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References and products

Compressor drive Start up converter Type: MV converter ACS6000 (ABB) Natural gas storage Staßfurt 5,200 kW, 3,160 V, 597 r.p.m. Type: LCI (Load Commutated Inverter) For polyethylene (LDPE) plant/high-pressure process For synchronous motor 23,000 kW, 11,000 V, 200 r.p.m.

slide-41
SLIDE 41

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References Drive application “Pelletizing plant”

Challenge/application

  • Outotec Oberursel
  • Output: 750 – 6,000 kW, 6 kV
  • Motors: Asynchronous motors, SWD
  • Integration into existing process

automation

  • Emergency and local operation
  • Operator: Gol-E-Gohar, Iran

Solution/scope of supply

  • Frequency converter: CKD 7-level
  • Converter – motor – near-drive

control

  • Stand-by converter with bypass
  • Transformers – converter – motor

Customer benefit

  • Unambiguous responsibility for the

drive system

  • Consistent system for all drive

tasks

  • Prepared for integration into

process automation

  • Local operation possible
  • Unambiguous commissioning

assignments/responsibility

slide-42
SLIDE 42

www.vem-group.com

Low Voltage

VEM locations Zwickau and Wernigerode

slide-43
SLIDE 43

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Facts

  • Founded in 1908
  • Manufacturer of single-phase and three-phase

asynchronous machines

  • mounting dimension 56 – 132
  • 0.06 – 9.0 kW

VEM motors Thurm GmbH, Zwickau

slide-44
SLIDE 44

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Facts

  • Founded in 1947
  • Manufacturer of three-phase asynchronous

machines

  • mounting dimension 132 – 450
  • 5.5 – 1,000 kW

VEM motors GmbH, Wernigerode

slide-45
SLIDE 45

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Series for the field of low voltage

  • Energy saving motors
  • Permanent-magnet synchronous motors
  • Compact drives
  • Single-phase motors
  • Special motors
  • Standard motors in grey cast iron design
  • Explosion-protected motors
  • Roller table motors
  • Brake motors
  • Traction motors
  • Single-phase motors
  • Die-cast aluminium motors
  • Circular saw motors
  • Extruded aluminium motors
  • Reluctance synchronous motors
  • Pole-changing motors
  • Built-in motors

Series of low voltage

slide-46
SLIDE 46

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Product range

Low-voltage machines for outputs 0.06 – 1,000 kW Low-voltage machines in 2-, 4- and 6-pole versions as energy-saving motors for outputs 0.75 – 375 kW in efficiency classes IE2 or IE3 acc. to IEC 60034-30/IEC60034-2-1 Asynchronous motors 0.06 – 1,000 kW Standard motors acc. to IEC/DIN with squirrel cage rotor (IE2, IE3) Mounting dimension 56 – 315, protection type IP 55 3,000, 1,500, 1,000, 750, 600, 500, 375, 300, 250 r.p.m. and pole-changing combinations 0.06 – 160 kW Transnorm motors acc. to IEC with squirrel cage rotor (IE2, IE3) Mounting dimension 315 – 450, protection type IP 55 3,000, 1,500, 1,000, 750, 600, 500, 375, 300, 250 r.p.m. and pole-changing combinations 200 – 1,000 kW Three-phase motors for marine operation (IE2, IE3) Protection against seawater in accordance with the requirements of important international classification societies: Det Norske Veritas·Germanischer Lloyd (DNV·GL), Bureau Veritas (BV), Lloyds Register of Shipping (LRS), American Bureau of Shipping (ABS), Russian Maritime Register of Shipping (RMRS), Registro Italiano Navale (RINA), Polski Rejestr Statkow (PRS), Chinese Classification Society (CCS) 0.06 – 710 kW

slide-47
SLIDE 47

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Product range

Customer-specific motors, unclassified and pole-changing combinations 3,000, 1,500, 1,000, 750, 600, 500, 375, 300, 250 r.p.m. 0.06 – 1,000 kW Standard motors acc. to IEC/DIN with squirrel cage rotor IE4 Mounting dimension 280 3,000, 1,500 r.p.m. 75 – 90 kW Transnorm motors acc. to IEC with squirrel cage rotor Mounting dimension 315 – 355 3,000, 1,500 r.p.m. 110 – 400 kW Modifications

  • base and flange design
  • attached brake
  • attached star-delta switch
  • with thermal winding protection
  • with external fan
  • pole switching
  • voltage switching
  • memory version (RFID transponder)
  • with incremental encoder (IGR) or tachogenerator

Possible cooling types

self-ventilated, IC 41; force-ventilated, IC 416; force-ventilated, IC 418; not ventilated, IC 410; water-cooled, IC 71W (IC 31W)

slide-48
SLIDE 48

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Product range

Three-phase motors with slip-ring rotor Mounting dimension 132 – 315, protection type IP 54, IP 55 Speeds 1,500, 1,000, 750, 600, 500 r.p.m. 2.2 – 315 kW Explosion-protected motors acc. to 2014/34/EU (ATEX) in the protection types

  • Increased safety “e” (“eb”)
  • Flameproof enclosure “d/de” (“db/db ec”)
  • Non-sparking “n” (increased safety “ec”) Zone 2
  • Protection by enclosure “tb” zone 21
  • Protection by enclosure “tc” zone 22
  • Efficiency classes up to IE3

0.12 – 320 kW 0.12 – 630 kW 0.06 – 710 kW 0.06 – 710 kW 0.06 – 710 kW Three-phase compact motors (efficiency classes up to IE5) 0.55 – 22 kW Variable speed three-phase drives 0.75 – 710 kW Three-phase brake motors (IE1, IE2, IE3) 0.12 – 710 kW

slide-49
SLIDE 49

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Product range

Three-phase motors for use in mechanical smoke and heat extraction equipment (DIN EN 12101 – 3:2015) For stress temperatures of 200 ºC, 300 ºC and 400 ºC Efficiency classes up to IE3 0.12 – 710 kW Drive solutions for the steal and rolling mill industry

  • Three-phase rolling mill motors
  • Three-phase gear rolling mill motors
  • Three-phase motors for cranes in metallurgical plants
  • Efficiency classes up to IE3

0.5 – 710 kW 0.4 – 450 kW 4.8 – 315 kW Permanent magnet synchronous motors for converter-fed operation

  • Ultra-premium-efficiency-motors acc. to IEC 60034-30/IEC 60034-2-3
  • High power motors

0.12 – 75 kW 0.18 – 315 kW Three-phase asynchronous generators 5.5 – 710 kVA Built-in motors 0.06 – 710 kW Single-phase motors 0.06 – 2.2 kW

slide-50
SLIDE 50

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Chemical parks in Germany Explosion protected motor in ignition protection type increased safety “e”

References chemical and petrochemical industry

Three-phase motors with squirrel cage rotor, explosion protected Type of protection „e“, „n“, Ex „d/de“ About 1,000 motors/year, mounting dimension 63 – 450

Explosion protected motor Exll2G ExllT4 mounting dimension 100 S

slide-51
SLIDE 51

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

BAB 17 – tunnel Dresden-Coschütz, Germany

Reference smoke venting motors

Delivery of three-phase motors with squirrel cage rotor Type: K10R, 45 kW, 400 V D, 50 Hz IM B14, 60 pieces

Fan motor Fire gas motor

mounting dimension 200 45 kW, 230/400 D/Y, 1,450 r.p.m., IM B5, 50 Hz mounting dimension 90, F400 1.1 kW, 400 V, 1,470/2,940 r.p.m., IM B3, 50 Hz

slide-52
SLIDE 52

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Motor after fire gas test in field of SystemAir (in use there for more than 10 years)

Reference smoke venting motors

Type: IE2-W22R 355 M4 300 kW, 415 V, 1,495 r.p.m., IM B3, 50 Hz

slide-53
SLIDE 53

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Airport Heathrow, London, Great Britain

Reference materials handling

Delivery of three-phase motors for lifts, forced-ventilated design with brake

Brake motor

Types: K21F 160 L4 B21F 250 M4 K21F 180 L4 B21F 280 M4 Type: BU1R 250 M4 B HB IGR PRE PT SL HW; 55 kW, 690 V Y, 1,475 r.p.m., IM B3, 50 Hz

Foto: Heathrow Airports Limited

slide-54
SLIDE 54

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Hot rolling mill for wide steel strips EKO Stahl GmbH, Germany

References steel industry, pulp and paper industry

Geared roller table motor Frame size 225 with “Bauer-Getriebe AG“ 39 motors Geared roller table motor Frame size 200 with “Bauer-Getriebe AG” 154 motors

Paper machine PM 4, Leipa, Germany

900 pieces three-phase motors with squirrel-cage rotor For frequency converter and mains operations Output range: 0.55 – 500 kW Mounting dimension: 80 – 355 Drives for pumps, centrifuges, rollers, fans, drying groups, dispergers, blowers

slide-55
SLIDE 55

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Virgin Trains, U. K.

Reference rail transport

Motors in the air conditioning unit

  • f high-speed trains.

Used as bypass fan Used as condenser fan

High speed train “Frecciarossa 1000“, Trenitalia, Italy

Variable-speed drive system for the cooling

  • f the traction motor
slide-56
SLIDE 56

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

References cranes and hoists

  • drives for main hoists, boom hoists,

trolleys and gantrys

  • design principle permits add-on mounting of

components such as:

  • encoders
  • tachos
  • brakes
  • forced ventilation units to solve customer’s

individual control tasks

  • robust and low-vibration motor design with

grey cast iron housing characterized by high mechanical strength

  • paint system guarantees very high level of

proven corrosion protection

  • brand-name products “Made in Germany”
  • tradition and experience

Customer-tailored VEM applications: Our VEM product portfolio for the most diverse applications

slide-57
SLIDE 57

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Technical data:

· Three-phase asynchronous motors with squirrel-cage rotor, suitable for mains and converter-fed operation · Sizes: 63 to 450 acc. to IEC · Number of poles: 2- to 8-pole (higher pole numbers on request) · Output range: 0.12 to 1 000 kW · Frequency: 50/60 Hz · Voltage: up to 690 V · Efficiency classes: IE2 to IE4 acc. toIEC/EN 60034-30-1, and IE5 · Type of protection: up to IP 66 acc. to IEC/EN 60034-5 · Type of construction: IM B3, IM B35, IM B5, IM V1 and derived types acc. to IEC/EN 60034-7 · Self-ventilated, forced ventilation and non-ventilated · Quality, environmental and energy management acc. to DIN EN ISO 9001, DIN EN ISO 14001 and DIN EN ISO 50001 The proven range of VEM products also includes slip-ring motors in crane and steelworks versions for short-time and intermittent duty S2, S3 and S4.

References cranes and hoists

slide-58
SLIDE 58

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Three-phase asynchronous motor with electromagnetic spring-set brake and incremental encoder, type of protection IP 55 Three-phase asynchronous motor in non-ventilated version with electromagnetic spring-set brake and incremental encoder, type of protection IP 66 Three-phase asynchronous motor with slip-ring rotor for intermittent duty

VEM – three-phase asynchronous motors for main hoist applications: Technical data:

· Three-phase asynchronous motors with squirrel-cage rotor, suitable for converter-fed operation · Sizes: 355 to 450 acc. to IEC · Frequency: 50/60 Hz · Voltage: up to 690 V · Type of protection: IP 23 acc. to IEC/EN 60034-5

IP23

References cranes and hoists

slide-59
SLIDE 59

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

AIDA Cruises, Meyer Werft, Papenburg, Germany

References shipbuilding and offshore facilities

Amongst others, supply of the entire range of LV motors from 0.37 kW to 160 kW (approximately 250 motors for each ship)

Offshore and production platform (offshore units)

Use of VEM motors on platforms like “Stena Don”

  • r the oil platform “Oseberg 7”
slide-60
SLIDE 60

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

  • Product range from single drive to entire

drive systems

  • Internal design and development for

tailor-made solutions

  • Flexibility due to a high level of vertical

integration

  • Quick response times
  • Worldwide customer service
  • 24h-delivery service of stock motors

(online stock)

  • 1,500 highly motivated and qualified

employees Made in Germany

  • Durable, robust under extreme conditions
  • Environmentally friendly and highly energy

efficient

  • Low “life cycle costs”

Good reasons to buy from VEM

slide-61
SLIDE 61

Longstanding customers of VEM

www.vem-group.com VEM – ELECTRIC DRIVES FOR EVERY DEMAND

Longstanding customers of VEM
