COMPANY PRESENTATION KD Blansko SMALL HYDRO, s.r.o. is a member of JSC Tyazhmash group COMPANY HEADQUARTERS Gellhornova 1, 678 18 Blansko, Czech Republic www. ckdsh .cz HISTORY KD Blansko is ranked among most traditional Czech engineering

SLIDE 1

ČKD Blansko SMALL HYDRO, s.r.o. is a member of JSC Tyazhmash group

COMPANY PRESENTATION

SLIDE 2

COMPANY HEADQUARTERS

Gellhornova 1, 678 18 Blansko, Czech Republic

www.ckdsh.cz

SLIDE 3

HISTORY

www.ckdsh.cz

ČKD Blansko is ranked among most traditional Czech engineering companies. 1698 – Origins of engineering manufacture 1904 – Origins of water turbines manufacture 1985 – New Hydraulic Laboratory has been put into operation 2007 – ČKD Blansko Small Hydro foundation 2010 – Integration to the JSC Tyazhmash Group

SLIDE 4

COMPANY ORGANIZATION CHART

www.ckdsh.cz

SLIDE 5

BASIC INFORMATION

www.ckdsh.cz

Number of Employees by 2013 Technical and Commercial Employees 32 Basic Design Dpt. 6 Detail Design Dpt. 9 Sales & Project Management Dpt. 7 Shop Workers 54 Total 86 Financial Indicators [EUR] [2009] [2010] [2011] [2012] [2013] Turnover 4.9 mil. 3.4 mil. 8.5 mil. 13.8 mil. 12.8 mil. Contracted Amount 4.5 mil. 11.8 mil. 20.2 mil. 2.6 mil. 4.4 mil.

SLIDE 6

DESIGN DEPARTMENT

www.ckdsh.cz

STRUCTURE OF TECHNICAL SECTION

Managing and Administration
Development and Design of Water Turbines
Development and Design of Closing Valves
Development and Design of Governors
FEM Computation
Production Technology
Special Technology
Jigs Design Department

INTERNAL SUPPORT

Basic Design Department
Research and Development of Water Turbines
Hydraulic Laboratory

SOFTWARE - SolidWorks

3D Design

SolidWorks Professional SolidWorks Premium SolidWorks DWGeditor

FEM Computation

SolidWorks Simulation

CNC Machinery

SolidCAM

Data management

SolidWorks Enterprise PDM

SLIDE 7

DEPARTMENT OF APPLIED MECHANICS

www.ckdsh.cz

Strength, stiffness and fatigue structural calculations (water turbines, valves, hydromechanical structures). Finite Element Method (SolidWorks Simulation Premium) is used to determine structural stress and strain. Methods of fracture mechanics are used for evaluation of strength and fatigue life.

SLIDE 8

WATER MACHINERY RESEARCH INSTITUT

www.ckdsh.cz

Development of turbine hydraulic profiles Hydraulic testing laboratory Calibration of flow meters

SLIDE 9

TESTING LABORATORY

www.ckdsh.cz

SLIDE 10

Q/H DIAGRAM

www.ckdsh.cz

SLIDE 11

KAPLAN TURBINES

www.ckdsh.cz

Head: 2 – 40 [m] Output: 200 – 10 000+ [kW] Diameter: 500 – 3 000+ [mm]

SLIDE 12

FRANCIS TURBINES

www.ckdsh.cz

Head: 10 – 300 [m] Output: 200 – 40 000+ [kW] Diameter: 400 – 1 700+ [mm]

SLIDE 13

PELTON TURBINES

www.ckdsh.cz

Head: 70 – 800 [m] Output: 300 – 40 000+ [kW] Diameter: 500 – 1 500+ [mm]

SLIDE 14

HYDRO-MECHANICAL EQUIPMENT

www.ckdsh.cz

SLIDE 15

INVESTMENTS IN TECHNOLOGY

www.ckdsh.cz

In operation: February 2011 Machine: CNC Floor Type Machining Centre FU – 150

SLIDE 16

CNC Floor Type Machining Center FU-150

www.ckdsh.cz

Technical Parameters: Working travel x: 7 000 [mm] y: 1 500 [mm] z: 3 000 [mm] Clamping Surface 3 400 x 4180 [mm] Capacity 25 000 [kg]

SLIDE 17

MANUFACTURE

www.ckdsh.cz

WELDING SHOP

SLIDE 18

ASSEMBLY AND SHOP TESTS

www.ckdsh.cz

SITE ERECTION

SLIDE 19

www.ckdsh.cz

FRONHAS HEPP

Country: Portugal Commissioned: 2008 Type of Turbine: Horizontal Francis Total Output: 1 x 750 kW Country: Indonesia Commissioned: 2009 Type of Turbine: Horizontal Francis Total Output: 2 x 1 500 kW

RANTE BALLA HEPP AMPELGADING HEPP

Country: Indonesia Commissioned: 2010 Type of Turbine: Vertical Francis Total Output: 2 x 5 000 kW

SLIDE 20

www.ckdsh.cz

PATIKARI HEPP

Country: India Commissioned: 2007 Type of Turbine: Horizontal Pelton Total Output: 2 x 9 459 kW Country: Peru Commissioned: 2009 Type of Turbine: Horizontal „S“ Kaplan Total Output: 2 x 5 000 kW

POECHOS 2 HEPP ČESKÉ ÚDOLÍ HEPP

Country: Czech Republic Commissioned: 2012 Type of Turbine: Horizontal „S“ Kaplan Total Output: 1 x 233 kW

SLIDE 21

www.ckdsh.cz

LABSKÁ HEPP

Country: Czech Republic Commissioned: 2009 Type of Turbine: Vertical Kaplan Total Output: 1 x 500 kW Country: Armenia Commissioned: 2011 Type of Turbine: Horizontal Pelton Total Output: 2 x 3 082 kW

TRGI 2 HEPP ARCO IRIS HEPP

Country: Mexico Commissioned: 2013 Type of Turbine: Vertical Pelton Total Output: 2 x 4 700 kW

SLIDE 22

www.ckdsh.cz

CABULIG HEPP

Country: Philippines Commissioned: 2012 Type of Turbine: Horizontal Francis Total Output: 2 x 4 700 kW Country: Slovakia Commissioned: (2013) Type of Turbine: Horizontal „PIT“ Kaplan Total Output: 1 x 995 kW

TEKOV HEPP ORTACAG HEPP

Country: Turkey Commissioned: 2013 Type of Turbine: Vertical Pelton Total Output: 1 x 13 280 kW

SLIDE 23

www.ckdsh.cz

TAHTAKORPU HEPP

Country: Azerbaijan Commissioned: (2013) Type of Turbine: Horizontal Francis Total Output: 3 x 10 627 kW Country: Turkey Commissioned: (2014) Type of Turbine: Vertical Francis Total Output: 2 x 5 661 kW

KAVSAKBENDI HEPP KANDIL-1 HEPP

Country: Turkey Commissioned: 2013 Type of Turbine: Horizontal Francis Total Output: 1 x 4 719 kW

SLIDE 24

www.ckdsh.cz

ARAKLI-4 HEPP

Country: Turkey Commissioned: 2013 Type of Turbine: Horizontal Pelton Total Output: 2 x 4 564 kW Country: Greece Commissioned: (2013) Type of Turbine: Horizontal Francis Total Output: 1 x 4 200 kW

ILARION HEPP CUCUMACAYAN HEPP

Country: El Salvador Commissioned: (2013) Type of Turbine: Vertical Francis Total Output: 2 x 2 940 kW

SLIDE 25

MAIN SUB-SUPPLIERS

www.ckdsh.cz

Inlet Equipment – Main Inlet Valves Hydraulic Governing and Lube-Oil Units Generators

Czech Republic Czech Republic Spain Czech Republic Brazil, India Czech Republic Czech Republic Czech Republic Germany Hungary

SLIDE 26

www.ckdsh.cz

THANK YOU FOR YOUR ATTENTION

ČKD Blansko SMALL HYDRO, s.r.o. Gellhornova 1 678 18 Blansko Czech Republic E-mail: smallhydro@ckdblansko.cz Tel.: +420 516 402 724
