COMPANY PRESENTATION

General Introduction

We support businesses through our expertise in Manufacturing and deliver value-added services that enable companies to manage, improve and grow their businesses.

years of supporting engineers and companies in making parts and products in China

• riginal founders still

form a back-bone of the company, but now surrounded by team of dedicated professionals

• ffice in China and

Worldwide Reach

• f our clients are

international companies

12 3 15+ 1

awards been won by

• ur clients with

products that we assisted them to manufacture

98%

Service Available

Strategic Sourcing:

Supplier research and customer involvement at early stage Right supplier solutions and new opportunities will be proposed to each product requirements

Sales Support:

Professional and quick quotations work with many technical and logistic alternatives Assist communication for visit to the manufactures Day to day customer’s sales services in English or in your language

Engineering Support:

Technical advices to customer’s engineers at development stage Technical translations in English or Chinese if necessary

Logistical Support:

We assure the on-time delivery and the requested delivery documents INCOTERMS from FOB to DDU are available Group shipment of small quantities to decrease transport costs

Quality Control:

High quality level guaranty thanks to our strong suppliers’ survey system All our suppliers are at least ISO 9000 certified Outgoing quality inspection before sample and special deliveries On-site intervention upon request to solve quality issue as soon as possible All suppliers are used to work in compliance with all the highest international quality standard

Service Available

Working Flow Chart

01 02 03 04

DISCOVERY + INSIGHTS SEARCH + PRICE DEVELOPE + EVALUATE DELIVER + MONITOR Product requirement definition Design and materials

analysis Application analysis & insights Product manufacturing strategy & road maps Target cost Locate suitable vendors Obtain quotes Quotes review with client Shortlist and engage vendors Work out suitable manufacturing process Produce working prototypes Prototype testing & verification Tooling design and engineering Off-tool samples inspection, testing & verification Finalise production documentation Production process implementation Manufacturing quality control Packaging and logistics management Ongoing improvements Back up vendors management

Customer Distribution

60% 30% 5% 5%

Australia USA Europe Others

Metal Fabrication

Laser cutting

Up to 6000mm x 3000mm; Max 8mm aluminum and 12mm steel

Welding service

MIG / TIG / ARC (Stick) Welding / Gas or Oxy Acetylene Welding

CNC punch & bend

Metal Fabrication

Hard Tooling design & production

Single die & Progressive dies & Deep-drawing die

Precision Stamping service

Up to 500Ton stamping machine Max 1500x1200mm un-folded size High precision: +/-0.005mm Min

Material & Finish

Steel / Stainless steel / Aluminum / Copper or brass… All kinds of plating / anodizing / powder coating / painting

HeatSink & HeatPipe

Aluminum Extrusion Profile

Max section width: 500mm

Heat Sink

By Extruded / Bonded / cold forged / stamped / casted With all kinds of Aluminum / copper Advanced with additional machining work Anodizing / powder coat / e-coating / plating

Heat Pipe

Diameter from 1mm upper to 26mm Wall thickness from 0.1mm to 5mm Thermal analysis available All kinds of brass / copper

CNC Machining

CNC Machining & milling

High precision machining / milling / grinding / Turning

Tolerance: +/-0.005mm Max size: 2000x1500mm All kinds of material: aluminum, steel, brass/copper… All kinds of finish: anodizing, powder coat, plating, painting… From 1 prototype to hundreds / thousands of productions

Casting Products

Die-casting / Investment Casting / Sand Casting

Casting production Material: Zinc / Aluminum / Steel / Magnesium Finish: powder coat / painting / plating Up to 7.5kilos at size of 1000mm Secondary machining / tapping / drilling available Used at Auto / Medical / Telecom / Lighting industries

Plastic Mould and Parts

Plastic Mould

• Standard plastic injection Mould
• Blow Mould
• Die Casting Mould

Plastic Parts

• Materials: PA66, PA6, PE, POM, PC, ABS…
• Thin walls, transparent parts, high precision parts...
• Over Moulding with 2 materials
• Double Injection parts with 2 colors
• Finish: Painting, Plating, Laser etching, Printing,

In Mould Decoration (IMD), Serigraphy

• Application: Automotive, Electronics,

Medical Industries

• Wire Harness
• PCB Assembly
• Multi-technology projects

Electronic Solutions

• Power supply
• Transformer & Coil
• LCD
• LED
• Touch Panel

Transformers & Inductors

High Frequency Transformer:

Different shapes of transformers including:

• EE, EI, EF Transformer
• ER, ETD, PQ Transformer
• EFD, EP, EPC Transformer
• POT, RM Transformer
• Toroidal Transformer

Transformers & Inductors

Low Frequency Transformer:

• Toroidal Transformer (power range: 5W-10000W)
• Power Transformer
• Audio Line Matching Transformer

Transformers & Inductors

Toroidal Inductor & Choke DR Inductor & Air coil Filter

LCD, LED, Touch Panels

Monochromatic Display:

• TN, HTN, STN, FSTN, CSTN LCD types
• Size: 1/2” (12mm) to 6” (52mm)
• Pin and Zebra Paper connectors

Polychromatic Display:

TFT Modules:

• Size: 2.1” (5cm) to 8” (200mm)
• COB, COG, COF types

LED Panel: Characters and pictures display Touch Panel: Capacitive and Resistive Type Light Box & LED Lighting letters

Wire Harness

Custom-Made Wire Harness

• Mono-Core and Multi-Core wires
• PVC, Silicon Rubber, Teflon Insulation
• A/V cables, Ribbon Cables
• SMT connectors/Ethernet Connectors

RJ jack/ USB plug

Power Cord

• AC type
• Multinational certificates
• Different colors and designs

RF Cable

• Coaxial cable
• Connector types: F, BNC, N, SMA, SMC, BNC, C, TNC

PCBA Products

Component Assembly

• SMT Mounting
• Reflow Soldering

Special Technology Available

• BGA assembly
• Flexible PCB assembly
• Chip on board assembly
• Aluminum PCB assembly

Finished or semi-finished products:

• PCB plus cables
• PCB plus metal parts
• PCB plus plastic parts
• Assembly of finished products

PCB Capability

ITEM Technique available Layer count： Rigid: 2-12 layers; Flexible: 1~2layers Raw material： FR-4 , FR4+High Tg ,CEM-3, Rogers, Polyimide, Polyester Metal substrate (Aluminum) Surface treatment: HASL / Lead Free HASL Immersion Gold, Flash Gold, OSP Gold Finger (Gold thickness up to 30u") Carbon ink, Peel able mark,

• Min. hole size：

0.25mm

• Min. track width& space: 0.1/0.1mm
• Min. board thickness：

4Layer:0.4mm; 6Layer:0.6mm; 8Layer:0.8mm; 10Layer:1.2mm

• Max. board thickness

5.2mm

• Max. working size：

530mm x 610mm Aspect Ratio 12:1 Impedance control ±10%

• Max. Copper thickness

3 oz (inner layer)；4 oz (outer layer) Remark Prototype service available

Hong Kong Office: Address: Unit 2508A, 25/F, Bank of America Tower, 12 Harcourt Road, Central, Hong Kong Mainland Office: Address: #403, Business Center, Jing DuHui Hotel, ChangAn Town, Dong Guan City, Guangdong Province, P. R. China www.pa-international.com; www.papcb.com; www.patransformers.com;

CONTACT US
