Columbus Collection and Treatment System Real Time Wet Weather Management Presenters Gary Hickman, JPWWTP Plant Manager Ed Heyob, CDM Smith Automation Engineer Collection System Control Locations on Trunk Sewers Rhodes Park Alum Creek WST

SLIDE 1

Columbus Collection and Treatment System Real Time Wet Weather Management

Presenters Gary Hickman, JPWWTP Plant Manager Ed Heyob, CDM Smith Automation Engineer

SLIDE 2

Collection System

SLIDE 3

Control Locations on Trunk Sewers

SWWTP FDS JPWWTP WST Alum Creek Storm Tanks Rhodes Park BIS

SLIDE 4

Major Conveyance Limitations

Whittier St.

STORM TANK 1 STORM TANK 2 STORM TANK 3

OSIS FDS

JPWWTP 150 MGD

OVERFLOW

SWWTP 330 MGD

Scioto River

OVERFLOW

BIG WALNUT INTERCEPTOR SEWER

DSR 83

DESHLER TUNNEL FRANKLIN MAIN WEST SIDE SEWERS

OSIS conveyance is limited by the DSR83

verflow, Berliner Park flood protection
r plant treatment capacity.

SLIDE 5

Whittier Street Regulator Gates

To Berliner Park From/to DSR83 Regulator Gates

SLIDE 6

Visualizing the Decisions

SLIDE 7

What is Real Time Data

Sample inputs 3x more than controlled action
Regulator gate movement effects noticed in

less than 5 minutes

Operations is accustomed to 1-2 second

updates within plant

Ideal monitoring around Whittier Street would

update at least every 30 seconds

SLIDE 8

Ability to Learn from Each Event

There are more

items than can be easily trended together

Trends loose some
f the dynamic

“feel” of watching the system behave

Historical replay example

Which trend line was that?

SLIDE 9

Constraints on the Leading Edge of Event

SLIDE 10

System Constraints Exceeded

SLIDE 11

System Draw Down After Event

SLIDE 12

So Close Together, but Different Responses

DSR83

1 foot difference

Downstream OSIS

SLIDE 13

Optimization of DSR83 Constraint

SLIDE 14

Further Constraint Management

Improvements

Berliner Park Level
Assisted or

Automatic control

f regulator gates
OARS Tunnel

SLIDE 15

Berliner Park Level Sensor

Solar Powered
Readings every 4 seconds
Intrinsically safe instrument
Low powered radio
Direct I/O on radio

SLIDE 16

Real Time Control Feasibility Study

Builds upon lessons

learned through efforts so far

Identify other

possible controls and monitoring

Evaluate how to

apply them to the collection and treatment system

SLIDE 17

OARS Tunnel

700 650 625 575 550 525 500 725 600 675

UPPER OARS TUNNEL SIMPLIFIED PROFILE

560.91 550.87 546.48 714.85 707.60 698.57 702.57 710.57 692.3 696.3 709.7 706.6 STORM TANKS WEIR WHITTIER STREET 704.6 OARS SHAFT #6 OARS SHAFT #5 OARS SHAFT #4 OSIS OSIS OSIS OARS TUNNEL OARS TUNNEL 531.01 542.35 566.48 720.85 530.89 715.1 FLOOR 715.6 SLAB 700 686.6 500.6 505.6 SHAFT #3 CAPPED OFF OARS TUNNEL OVERFLOW TO RIVER 705.0 MAX DESIGN WATER LEVEL FLAP GATE FLAP GATE OARS GRIT PUMPS OARS PUMPS OARS SHAFT #1 (ODS) OARS SHAFT #2 (OSS) OARS SCREEN 691.14 689.34 719.75 FLOOR DOWN STREAM LEVEL OSIS 700 DSR 83 699.0 BERLINER PARK PROJECTION OSIS TO FDS REGULATOR GATES EMERGENCY SHUT OFF GATES

LOWER OARS TUNNEL SIMPLIFIED PROFILE

TO JP INFLUENT 703.3 MAX DESIGN WATER LEVEL UP STREAM LEVEL 530.85 702 704.5 54" 678.60 FDX 12' 12' TO FDS 701.30 710 GRAVITY FLOW 511.64 551.97 553.09 556.14 565.84 698.48 697.54 OARS PUMPING: 72.39 MGD

OARS Tunnel and pump station adds many more options for managing constraints

SLIDE 18

The End Questions

Gary Hickman JPWWTP Plant Manager Ed Heyob CDM Smith Automation Engineer
