Caledonian Maritime Assets Limited Colintraive and Rhubodach Slipways Reconstruction Caledonian Maritime Assets Limited Ramsay Muirhead Head of Civil Engineering Ruairidh Campbell Senior Civil Engineer 03 November 2014 Colintraive and

slide-1
SLIDE 1

Caledonian Maritime Assets Limited

Colintraive and Rhubodach Slipways Reconstruction

slide-2
SLIDE 2

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 2

Caledonian Maritime Assets Limited

Ramsay Muirhead Head of Civil Engineering Ruairidh Campbell Senior Civil Engineer

slide-3
SLIDE 3

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 3

  • Wholly owned by Scottish Government
  • Fully operational since 2006
  • Asset owning (33 ships, 24 ports)
  • Project management
  • Small highly skilled professional team
  • Focus on infrastructure NOT operations
  • Long term planning and sourcing funds
  • Continuity and development of the asset base

Who are CMAL?

slide-4
SLIDE 4

Caledonian Maritime Assets Limited

Colintraive and Rhubodach Slipways Reconstruction

slide-5
SLIDE 5

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 5

The Project

  • We are replacing the slipway’s at Colintraive and Rhubodach
  • The project will deliver new double width and longer slipway’s

– Access at all states of tide – Future maintenance will be carried out during the day

  • The project will also provide a new vehicle queuing area

– Capacity provided for 2 boat loads of cars and HGV’s

  • The ferry service will continue to operate throughout this project
slide-6
SLIDE 6

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 6

Marine Scotland - Pre-application

  • Marine Scotland

– Is a Scottish Government body – Its purpose is to manage Scotland's seas for sustainable development

  • Pre-application required under Marine (Scotland Act) 2010
  • To inform Statutory Consultees:

– Northern Lighthouse Board, Maritime and Coastguard Agency, Scottish Environmental Protection Agency, Scottish Natural Heritage

  • Hold a meeting locally (this evening’s meeting)

– Provides an opportunity to present this scheme and hold a Q&A session – This is also an opportunity to submit written comments via email or by post up to 7 days after the meeting (Deadline is 10th November 2014) – Details are on the posters in the Hall and Hotel Notice boards

slide-7
SLIDE 7

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 7

Marine Scotland - Application Process

  • Consenting / licencing process takes approximately 12 Weeks

and includes:

– Planning Permission from Argyll and Bute Council – Marine Construction Licence from Marine Scotland

  • During the Application process there will be:

– A notice in the local newspapers advertising the project drawings (Dunoon Observer & the Buteman) – Drawings will then be lodged in Colintraive village Hall for 28 days to allow viewings and any further written comments to be sent in

slide-8
SLIDE 8

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 8

Colintraive and Rhubodach Slipways Reconstruction

  • Slipways at end of Serviceable Life:
  • Settled significantly
  • Surfacing is continually breaking up
  • Reconstruct slipways to safeguard ferry

service

  • The ferry service will continue to operate

throughout this project

  • A number of restrictions will be placed on

the contractor including:

  • Construction sequence
  • Working hours
  • Traffic management
slide-9
SLIDE 9

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 9

New Slipway – Phase 2 New Slipway – Phase 3

Rhubodach Slipway

Existing Slipway Contractor’s Compound New Infill / Paved Areas Excavation Separation Structure – Phase 1

slide-10
SLIDE 10

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 10

Colintraive – Slipway Area

Excavation New Infill Area / Wall Removed New Slipway – Phase 2 New Slipway – Phase 3 Existing Slipway Site Traffic Entrance (Lane 3) Clear space (Old lanes 1 and 2) Cathodic Protection System to Steel Piles Separation Structure – Phase 1 Contractor’s Compound

slide-11
SLIDE 11

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 11

Colintraive Ferry Traffic Queuing

slide-12
SLIDE 12

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 12

Colintraive – Marshalling Area

Existing Access Track and Storage Area (Contractor’s Working Area) CalMac Parking Area CalMac Storage Area General Parking Area Car Marshalling Lane 2 Car Marshalling Lane 1 HGV / Bus Marshalling Area Access Ramp to Shore

slide-13
SLIDE 13

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 13

Community Amenity

General Parking and access ramp to foreshore provided by CMAL Design of Pontoon Access

  • n foreshore by CMAL.

This will then allow Community Trust to apply for construction funding

slide-14
SLIDE 14

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 14

Outline Programme

  • Completion of Design Winter 2014
  • Tender for Construction Spring 2015
  • Start Construction Spring/Summer 2015
slide-15
SLIDE 15

03 November 2014 Colintraive and Rhubodach Slipway Rebuild 15

Questions?
