Coffee break 10:30-11:00 WOW SUCH DITA-OT Upgrade to better engine MUCH PREPROCESS #ditaotday TL;DR Vanity Slide Jarno Elovirta jarno@elovirta.com @jelovirt https://github.com/jelovirt Agenda DITA-OT at block level

slide-1
SLIDE 1

Coffee break 10:30-11:00

slide-2
SLIDE 2

Upgrade to better engine

SUCH DITA-OT WOW MUCH PREPROCESS #ditaotday

slide-3
SLIDE 3

TL;DR

slide-4
SLIDE 4

Vanity Slide

Jarno Elovirta jarno@elovirta.com @jelovirt https://github.com/jelovirt

slide-5
SLIDE 5

Agenda

  • DITA-OT at block level
  • Disassembling preprocessing
  • Expected work for 3.0
  • Questions
slide-6
SLIDE 6

Technology stack

  • DITA-OT is a DITA processor implemented in Java, Ant, and XSLT

JVM Ant XSLT Java

  • ther

Ant

slide-7
SLIDE 7

Processing modules and stages

  • Instead of a single operation, input is processed in consecutive stages
  • Preprocess step is common to all transtypes

preprocess base HTML HTMLHelp PDF HTML

slide-8
SLIDE 8

Preprocessing

  • Preprocessing prepares the content for transtype-specific processing
  • Handles most of the functional features of DITA, like keyref or conref
  • DITA spec doesn't mandate a processing order

TL;DR: Make complex DITA structures simple DITA structures

slide-9
SLIDE 9

Generate lists & debug and filter (1/2)

  • Initial processing steps that recursively read input

and linked resources

  • Collect file metadata what each DITA topic or map

contains

.job.xml

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-10
SLIDE 10

Generate lists & debug and filter (2/2)

  • Debug and filter step cleans, normalises, validates,

and serialises DITA into temporary directory

  • By default also filters DITA content
  • Since 2.4 copy-to processing has been split off
  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map

.job.xml

slide-11
SLIDE 11

Resolve map references

  • Resolves references from one DITA map to another
  • Creates a single map that contains all topicrefs and

reltables for all maps

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-12
SLIDE 12

Branch filtering

  • Filters topics using DITAVAL files defined in the map
  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-13
SLIDE 13

Copy related files

  • Copies non-DITA resources into output.
  • Which files are copies depends on transtype

configuration.

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-14
SLIDE 14

Resolve key references

  • Resolves keyrefs and conkeyrefs to populate link

URIs and text replacement. <xref keyref="x"> ↓ <xref href="foo.dita"> <p conkeyref="y/x"> ↓ <p conref="b.dita#b/x">

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-15
SLIDE 15

Copy topics

  • Makes a copy of original topic resources to new

resources defined by @copy-to attribute <topicref href="foo.dita" copy-to="bar.dita"> ↓ <topicref href="bar.dita">

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-16
SLIDE 16
  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map

Resolve content references

  • Processes both push and pull content references

<p conref="b.dita#b/x"> ↓ <p id="x">Resolved content</p>

slide-17
SLIDE 17

Filter conditional content

  • Removes content from topics and maps based on

DITAVAL or print attribute

  • Output can differ based on when filtering is done

<li audience="pro">duct tape<li> <li>cable tie</li> ↓ <li>cable tie</li>

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-18
SLIDE 18

Resolve topic fragments 1/2

  • Expands same topic fragments in URIs

<xref href="#./x"> ↓ <xref href="#b/x/>

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-19
SLIDE 19

Resolve code references 2/2

  • Expands coderef references in codeblock elements

<codeblock coderef="for.scala"/> ↓ <codeblock> for (i <- 0 to 10) { println(i) }</codeblock>

  • Adds some extensions to DITA spec

<coderef href="unicode.txt" format="txt; charset=UTF-8"/> <coderef href="lib.rs#token=XMPSTR,XMPEND"/>

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-20
SLIDE 20

Chunk topics

  • Breaks apart and assembles referenced DITA

content based on the chunk attributes in maps

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-21
SLIDE 21

Move map metadata to topics & pull content into maps

  • Cascades metadata in map and nested topicrefs
  • Pushes the map metadata into topics
  • Allows topic processing in isolation while retaining

all relevant metadata

  • Pulls metadata from referenced topics into maps
  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-22
SLIDE 22

Map-based linking

  • Collects links based on a map and moves those links

into the referenced topics

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-23
SLIDE 23
  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map

Pull content into topics

  • Pulls title and description content into xref and link

elements

  • Partially overlaps with transtype specific link

processing <xref href="o-sensei.dita"/> ↓ <xref href="o-sensei.dita" type="concept" >植芝 盛平</xref>

slide-24
SLIDE 24

Flagging

  • Evaluates the DITAVAL for flag action and adds

DITA-OT specific elements to topics when flags are active

  • Any extended transform type may use these hints to

support flagging without adding logic to interpret the DITAVAL

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-25
SLIDE 25

Clean-up map

  • Any elements and attributes that were added to files

to support preprocessing are removed

  • gen-list
  • debug-filter
  • mapref
  • branch-filter
  • copy-files
  • keyref
  • copy-to
  • conrefpush
  • conref
  • profile
  • topic-fragment
  • chunk
  • move-meta-entries
  • maplink
  • topicpull
  • flag-module
  • clean-map
slide-26
SLIDE 26

Future work

slide-27
SLIDE 27

Alternative work cache URIs

  • Change how source URIs are mapped to temporary files
  • Default implementation matches old behaviour, relative 1:1 mapping
  • Alternative implementations:

○ Hash: 0d23e72be0377ab0e899791a9cbf2f0613813c18.dita) ○ Full path: Users/jessicajones/Work/season2/script.dita)

  • Job configuration is used to store the mapping
slide-28
SLIDE 28

Map-first preprocess

  • Split preprocess into three phases:

○ Read maps and process as far as possible ○ Read topics and process as far as possible ○ Process map and topic relations

  • End result is the same as in old preprocess
  • Easier to reason about the process and clear separation of steps
  • Allows combining filter processing
slide-29
SLIDE 29

Alternative work caches

  • Support memory-based temporary storages
  • Support alternative storage formats
slide-30
SLIDE 30

Thank you
