Automated Creation of Tests from CUDA Kernels

Oleg Rasskazov, Andrey Zhezherun, Antti Lamberg (JP Morgan) April 2016

2

GPUs in JP Morgan

 JP Morgan is extensively using GPUs to speed up risk calculations and reduce

computational costs since 2011.

 Speedup as of 2011 ~ 40x  Large Cross Asset Quant Library (C++, Cuda)

 Monte Carlo and PDEs  GPU code  Hand-written Cuda Kernels  Thrust  Auto-Generated Cuda Kernels  Hardest part in delivering GPUs to production  Bugs

3

Auto-generating GPU code

 Putting all of a Quant library to GPU is hard  Parts of the code change frequently, so need to be rewritten  Domain specific languages (DSL) could help

 Interpreted  Compiled  We auto-generate lots of GPU code  Auto-generator is simplistic, converting DSL to .cu file  We rely on CUDA compilers  For optimizations  For understanding our horrible auto-generated .cu code  We need a regression test harness around it

4

(Rare) Compiler issues

 Sources (ways to notice)

 Driver upgrades  SDK upgrades  Hardware upgrades  Mitigation  Hand written code  Modify the code to go around the issue  Auto-generated code  ???  Modifying “generator” is hard  Complex code  Performance ?  Backward compatibility ?  Share an extensive set of our regression tests with NVidia

5

Pointers that we have a compiler issue

 How to verify that issue is not your code bug

 May be it is, but  Different behaviour on different cards  Different behaviour with different versions of Cuda  CPU/GPU code match (in some cases)  Ptx inspection

 Assume the issue could be reproduced by run of a standalone kernel, e.g.

 No concurrent execution issues  Not related to special objects allocated by the driver  Streams data,  Local memory,  Etc  => Create a small reproducer

6

Creating standalone kernel tests/reproducers

 Capture

 kernel code  Auto-generated .cu file  kernel inputs  correct outputs  Capture current GPU memory that is being operated on by the Kernel  Memory state was created as a complex interaction of previous kernels and cpu calls  We would like to be very generic at that point  Replay  Restore the GPU memory  How? Cuda Malloc does not allow one to choose address range for newly alloc-ed memory  Compile and load kernel  Pass in parameters and Run  Compare the outputs

7

Why dump/restore memory is hard

 Dump an array from GPU memory  Restored Array can be allocated at different address

 Ok, as long as we know all the pointers to array and re-point them to new allocation  What if we had array of pointers to objects?  Complex data structures?  Ideally we want to snapshot/restore current state of GPU memory  No public API from NVidia  Problem is hard because there is “private” memory for the driver which depends on kernels loaded, local memory configurations, etc.  We came up with a set of tricks

8

32 bit GPU code: restoring / dumping memory

 Assume GPU memory fits into 2GB  Intercept GPU memory allocations in your code and replace with your custom allocator from

preallocated blob.

 Allocate 3GB block of GPU memory BB

 On 32bit we have 4GB address space  3GB block always has virtual address range 1GB-3GB  Custom allocate from range 1GB in BB  Dump all the custom-allocated memory from 1GB  Replay simply allocates 3GB and always guaranteed to have address range 1GB-3GB  So simply load the dump starting from 1GB address  All the internal data pointers guaranteed to work as addresses are exactly the same

9

64 bit GPU code: Dumping memory

 Assume GPU memory for the kernel fits into 1GB  Intercept GPU memory allocations in your code and replace with your custom allocator from

preallocated blob.

 Assume we do not store pointers back to CPU memory on the GPU  Run 1:

 Allocate 2GB block of GPU memory BB  BB has at least 1 ranges, M  starting from 1GB boundary  Of size 1GB  Use custom allocator starting from M, and before running kernel, dump GPU memory BB_M  Run 2:  Repeat run 1 but with 1GB address range starting from N, M!=N and dump GPU memory BB_N

10

64 bit GPU code: Restoring memory

 Allocate 2GB block of GPU memory, BB

 Find 1GB stride starting with 1GB memory, P  Assuming code path in run1 and run2 of the application are deterministic and are the same  Assume preallocated BB was set to 0 in both runs  Relocate BB_N’s addresses into P:  Unless non-linear address arithmetic was involved  Dumps BB_N and BB_M would only be different where GPU memory stores the addresses to GPU memory  Difference being N-M  Size of the difference can be used to validate our assumptions about dumps  Starting with BB_N dump, replace add the different bytes (e.g. addresses in Nth GB) with addresses to Pth GB  Now we ready to run the kernel.

11

Summary

 If many conditions are held  We can automatically create standalone cuda test cases out our auto-generated kernels  Surprisingly, preconditions hold for us say 99% of time  100GB worth of standalone tests from snapshot of our production (uncompressed)

 64 bit GPU codes  Based on hundreds of trades  Could be shipped outside of JPMorgan without sharing proprietary quant library  Refreshed tests are to be shipped to NVidia (pending internal clearance).
