slide-1
SLIDE 1

1 Acronis Training and Certification – Authorized Use Only

ACRONIS BACKUP SETUP AND INSTALLATION

Setting up and installing Acronis Backup and Acronis Backup Cloud

slide-2
SLIDE 2

2 Acronis Training and Certification – Authorized Use Only

Module Outline

  • 1. Onboarding Acronis Backup Cloud
  • 2. Onboarding Acronis Backup
  • 3. Installing Components
slide-3
SLIDE 3

3 Acronis Training and Certification – Authorized Use Only

Onboarding Acronis Backup Cloud

How to setup Acronis Backup Cloud (for Service Providers)

slide-4
SLIDE 4

4 Acronis Training and Certification – Authorized Use Only

  • 1. Onboarding Acronis Backup Cloud

‒ Service Providers can setup and customize Acronis Backup Cloud to suit their needs ‒ Depending on the implementation model chosen, additional actions may be required:

▪ Hybrid: Setup cloud storage ▪ SP Hosted: Setup cloud storage and cloud management

‒ Additionally, if automation integration is required, obtain the Acronis Backup Cloud package/module from the respective vendor sites (such as APSSTANDARD or WHMCS marketplace) and install/configure ‒ Alternatively, obtain the RESTful API documentation from Acronis for customized integration

slide-5
SLIDE 5

5 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Onboarding Steps

Signs SP agreement with a Cloud Reseller or Acronis Re-brand UI and links as per corporate preferences Setup Scheduled Reports Perform backups Charge Partners and/or Customers Hybrid or SP Hosted? Setup Cloud Storage and/or Cloud Management Get Administrator Account from CR

  • r Acronis

Login to Backup Console Create Groups and Accounts for Partners and/or Customers Send Account details to Resellers or Customers Managed

  • r Self-

Service Backup Install Agents on Customer machines and devices Setup Backup Plans Yes No Self-Service Managed

slide-6
SLIDE 6

6 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Login

1. Service Providers will receive their Administrator account credentials via email together with the URL for the Backup Console: https://cloud.acronis.com 2. They can then log in and optionally, proceed to rebrand Acronis Backup Cloud according to their corporate preferences 3. Thereafter, they can start to create and configure new groups and accounts for partners (if any) and for customers 4. They can also set up scheduled reports and if they are providing managed services, install agents and configure backup plans or for self-service customers, send account credentials to them via email

slide-7
SLIDE 7

7 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud User Groups

User Group Hierarchy Add new Account

slide-8
SLIDE 8

8 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud User Groups

‒ Partner

▪ Top of the hierarchy, represents Service Providers that provides backup services to resellers and direct end-customers, can create other Partner- level and Customer-level groups

‒ Customer

▪ Middle of the hierarchy, represents an end- customer company, can create Unit-level groups

‒ Unit

▪ Optional, used to represent a sub-unit of an end- user’s company such as a department, physical location or group of devices

slide-9
SLIDE 9

9 Acronis Training and Certification – Authorized Use Only

  • 1. Creating A New Group

1. Fill in the following:

▪ NAME: Name of partner or end-user company ▪ IDENTIFIER: Identifier if any, such as a customer number ▪ TYPE: Select between Partner, Customer or Unit ▪ MODE [Customer only]: Select between Trial and Production ▪ DEFAULT LANGUAGE: Select from the languages available for the default language for notifications, reports and agent software to be used within this group ▪ STORAGE [Customer Only]: Select from the storage and/or datacenter available ▪ PRICING PARAMETERS [Customer Only]: When enabled, select currency and enter desired price per GB per month to show pricing in monthly report

slide-10
SLIDE 10

10 Acronis Training and Certification – Authorized Use Only

  • 1. Creating A New Group

▪ QUOTAS: Set quotas for number of machines, storage capacity and available backup locations ▪ CONTACT INFORMATION: Provide contact information of the relevant company ▪ Click CREATE to create the new group

slide-11
SLIDE 11

11 Acronis Training and Certification – Authorized Use Only

  • 1. Quotas

‒ Partner Group Quotas

▪ QUOTAS (soft) are available for number of machines that can be backed up, amount of cloud storage that can be used and backup locations available to child groups ▪ When the quota is exceeded, an email notification will be sent to the group administrators and administrators of the parent group

‒ Customer Group Quotas

▪ QUOTAS and Overage (hard) available with Overage being the amount that can be exceeded from the quota ▪ Exceeding the quota will generate an email notification ▪ Exceeding the Overage will cause subsequent backups to fail ▪ Setting the both quota and Overage to 0 will disable the corresponding functionality

slide-12
SLIDE 12

12 Acronis Training and Certification – Authorized Use Only

  • 1. Quotas

‒ Types of quotas:

▪ Physical workstations: Physical machine(s) running Windows desktop or Mac OS ▪ Physical servers: Physical machine(s) running Windows or Linux OS ▪ Virtual machines: Virtual machine(s) running on type 1(bare-metal) or 2 (hosted) hypervisor or on cloud (Azure or EC2) ▪ Mobile devices: Mobile device(s) running iOS or Android ▪ Office 365 mailboxes: Microsoft Office 365 mailbox ▪ Websites: Website (via SFTP or SSH) and linked databases hosted on MySQL servers ▪ Storage quotas: Amount of cloud storage capacity ▪ Backup locations: Cloud only (Acronis or partner cloud storage) and Local and cloud backups

slide-13
SLIDE 13

13 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Accounts

Add new Account Account List

slide-14
SLIDE 14

14 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Accounts

‒ There are 2 types of account: Administrator and User

▪ Administrator: Available for all group types ▪ User: Only available for Customer and Unit group

‒ At least 1 Administrator or User account must exist within a Customer or Unit Group for Agent installation and backup management purposes ‒ Administrators at Customer and higher levels can limit access to their groups:

▪ Disable Inherit administrator accounts from parent group setting on the Administrators tab of the root (target) group ▪ When inheritance is disabled, parent group administrators can modify group properties but cannot see accounts and child groups

Partner

Partner Admin

Customer

User Account Cust. Admin

Customer Unit

Partner Admin Cust. Admin Unit Admin Unit Admin User Account

slide-15
SLIDE 15

15 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Accounts

‒ The following table summarizes the operations that can be performed by Administrator and User accounts:

Operation Customer & Unit Group Partner Group Administrator Account User Account Administrator Account

Create groups No Yes Yes Create accounts No Yes Yes Create usage reports No Yes Yes Download and install Agents Yes Yes No* Manage backups Yes Yes Yes Manage recovery Yes Yes No*

* Partner Administrator account credentials cannot be used for Agent installation and recovery as they are mainly used for Group and Account management. In situations when a Partner Admin needs to install Agents and perform recovery, create a Customer-level account as a surrogate

slide-16
SLIDE 16

16 Acronis Training and Certification – Authorized Use Only

  • 1. Acronis Backup Cloud Accounts

‒ Accounts are used within a Group to manage and group machines to be backed up:

▪ Agent installation on a machine requires an account, hence there must be at least 1 live account within a Customer or Unit Group ▪ After the Agent is installed, the managed machine is assigned to the account used for installation ▪ If desired, multiple Unit Groups or multiple User accounts can be created to manage different groups of machines, i.e., create Unit Groups to represent different geographical locations or departments within the company and create Administrator or User account(s) within each group to manage backups for machines within the group ▪ Parent Group Administrators can supersede child Group accounts unless the Inherit administrator accounts from parent group setting is disabled

slide-17
SLIDE 17

17 Acronis Training and Certification – Authorized Use Only

  • 1. Adding A Partner Administrator Account

1. Fill in the following:

▪ Login: Username for login, must be unique ▪ Email: Email address for sending email notifications ▪ First name, Last name: Enter the first, last name of the user ▪ LANGUAGE: Select from the languages available ▪ BACKUP NOTIFICATIONS: Change the email notification level for backup success, warning and failure ▪ Send daily recap about active alerts: Clear to stop sending daily recap (sent at 10:00 datacenter time) about missed, failed backups and other problems ▪ BUSINESS NOTIFICATIONS: Disable to stop email notifications about exceeded quotas ▪ Add another: Tick to add another Administrator account

2. Click ADD ACCOUNT to create the new account

slide-18
SLIDE 18

18 Acronis Training and Certification – Authorized Use Only

  • 1. Adding A Customer Group Account

1. Fill in the following:

▪ Login: Username for login, must be unique ▪ Email: Email address for sending email notifications ▪ First name, Last name: Enter the first and last name of the user ▪ LANGUAGE: Select from the languages available ▪ ADMINISTRATOR PRIVILEGES: Enable to create an Administrator account ▪ AGENT AUTO UPDATE: Disable to stop Agents registered under this account from auto-updating when a new version is released ▪ QUOTAS: Set quotas for number of machines, storage capacity and available backup locations

slide-19
SLIDE 19

19 Acronis Training and Certification – Authorized Use Only

  • 1. Adding A Customer Group Account

▪ BACKUP NOTIFICATION: Change the email notification level for backup success, warning and failure ▪ Send daily recap about active alerts: Clear to stop sending daily recap (sent at 10:00 datacenter time) about missed, failed backups and other problems ▪ BUSINESS NOTIFICATIONS: Disable to stop email notifications about exceeded quotas ▪ Add another: Tick to add another Administrator account

2. Click ADD ACCOUNT to create the new account

slide-20
SLIDE 20

20 Acronis Training and Certification – Authorized Use Only

  • 1. Account Activation Email

‒ An activation email will be sent to the email address specified during account creation ‒ The email contains the following:

▪ Manage backups button: Button with link to cloud backup console ▪ Login name: Username to be used for login ▪ Activate account button: Button with link to set up the password and activate the account ▪ Support and user guide link: Link to customer support and Acronis Backup Cloud user documentation

slide-21
SLIDE 21

29 Acronis Training and Certification – Authorized Use Only

Installing Components

Installing components for Acronis Backup and Acronis Backup Cloud

slide-22
SLIDE 22

30 Acronis Training and Certification – Authorized Use Only

  • 3. Installing Components

‒ Acronis Backup and Acronis Backup Cloud uses similar Data Source components (Agents) for performing backup and recovery:

▪ For Acronis Backup cloud-based management and Acronis Backup Cloud, installable components can only be downloaded from the Add button on the Backup Console ▪ For Acronis Backup on-premise management, installable components can be downloaded from the Acronis Backup download page or from the Add button on the Backup Console after the on-premise Management Server has been installed

‒ Supported environments are similar for both Acronis Backup and Acronis Backup Cloud

slide-23
SLIDE 23

31 Acronis Training and Certification – Authorized Use Only

  • 3. Supported Environments

Component Acronis Backup Acronis Backup Cloud Supported Environment On-Prem Cloud

Management Server  Windows OS from Windows Server 2008, Windows 7 and above, x86 and x64, except for Windows 8/8.1 RT edtition and Windows 2016 Nano Server Linux OS with kernel 2.6.18 and above, glibc 2.3.4 and above, x86 and x64, including Red Hat Enterprise Linux, Ubuntu, Fedora, SUSE Linux Enterprise Server, Debian, CentOS, Oracle Linux and CloudLinux Storage Node  Windows Server 2008 (x64), Windows 7 and above Agent for Windows    Windows OS from Windows Server 2003, Windows XP Pro SP2 and above, x86 and x64, except for Windows 8/8.1 RT editions Agent for Linux    Linux OS with kernel 2.6.9 and above, glibc 2.3.4 and above, x86 and x64 including Red Hat Enterprise Linux, Ubuntu, Fedora, SUSE Linux Enterprise Server, Debian, CentOS, Oracle Linux, CloudLinux and ClearOS Agent for Mac    OS X 10.9 and above – Apple File System (APFS) not supported

slide-24
SLIDE 24

32 Acronis Training and Certification – Authorized Use Only

  • 3. Supported Environments

Component Acronis Backup Acronis Backup Cloud Supported Environment On-Prem Cloud

Agent for VMware (Virtual Appliance)  VMware ESXi 4.1 and above Agent for VMware (Windows)    Windows OS supported by Agent for Windows except 32-bit Windows OS, Windows XP, Windows 2003/2003 R2 and Windows SBS 2003/2003 R2 Agent for Hyper-V    Windows Server 2008 (x64), Windows 8/8.1 and above with Hyper-V Agent for Virtuozzo  Virtuozzo 6.0.10 Agent for Exchange    Microsoft Exchange Server 2007 and above Agent for SQL    Microsoft SQL Server 2005 and above Agent for Active Directory    Windows Server 2003 and above with Active Directory Domain Services

slide-25
SLIDE 25

33 Acronis Training and Certification – Authorized Use Only

  • 3. Supported Environments

Component Acronis Backup Acronis Backup Cloud Supported Environment On-Prem Cloud

Agent for Office 365    Windows Server 2008 (x64), Windows 8/8.1 and above SharePoint Explorer    Microsoft Windows SharePoint Services 3.0 SP2, Microsoft Office SharePoint Server 2007 SP2 and above iOS App   iOS 8 and above Android App   Android 4.1 and above

slide-26
SLIDE 26

34 Acronis Training and Certification – Authorized Use Only

  • 3. Supported Environments

Platform Supported Environment

VMware VMware vSphere 4.1 and above, vSphere Hypervisor (Free ESXi), VMware Server, Workstation, ACE, Player Windows Windows Server 2008 (x64) with Hyper-V and above, Windows 8/8.1 with Hyper-V and above except for Windows Server 2016 Nano Server, Microsoft Virtual PC 2004 and above, Windows Virtual PC, Microsoft Virtual Server 2005 Virtuozzo Virtuozzo 6.0.10 Citrix Citrix XenServer 4.1 and above (fully virtualized a.k.a HVM guests only) Red Hat and Linux RHEV 2.2 and above, KVM Parallels Parallels Workstation, Parallels Server 4 Bare Metal Oracle Oracle VM Server 3.0 and above, Oracle VM VirtualBox 4.x Amazon AWS EC2 instances Microsoft Azure Azure virtual machines

slide-27
SLIDE 27

35 Acronis Training and Certification – Authorized Use Only

  • 3. Supported Environments

Category Details

Network Ports (Inbound and Outbound) ‒ 443 and 8443: Accessing backup console, registering agents, downloading files from cloud storage ‒ 7770 – 7800: Agent communications with cloud Management Server ‒ 44445: Cloud backup and recovery data transfer ‒ 9877: HTTP port for on-premise web-based backup console access ‒ 9876: Component communications with on-premise Management Server Web Browsers ‒ Google Chrome 29 or above ‒ Mozilla Firefox 23 or above ‒ Opera 16 or above ‒ Windows Internet Explorer 10 or above, Microsoft Edge 25 or above ‒ Safari 8 or above Encryption Software ‒ Microsoft BitLocker Drive Encryption ‒ McAfee Endpoint Encryption ‒ PGP Whole Disk Encryption

slide-28
SLIDE 28

36 Acronis Training and Certification – Authorized Use Only

  • 3. Component Installation Cheat Sheet

What to back up What to install Where to install Disk Space

Disk, volumes and files on physical machines running Windows

Agent for Windows* On the machine that will be backed up 850 MB

Disk, volumes and files on physical machines running Linux

Agent for Linux 500 MB

Disk, volumes and files on physical machines running OS X

Agent for Mac 450 MB

VMware ESXi virtual machines and ESXi host configurations

Agent for VMware (Virtual Appliance) On the ESXi host 6 GB Agent for VMware (Windows) On a Windows machine that has network access to vCenter Server and to the virtual machine storage* 320 MB

Hyper-V virtual machines

Agent for Hyper-V On the Hyper-V host 320 MB

Virtuozzo virtual machines and containers

Agent for Virtuozzo On the Virtuozzo host 500 MB

* Typical RAM consumption is 350 MB above the OS and running applications with peak consumption reaching 2GB depending on the amount and type of data being processed

slide-29
SLIDE 29

37 Acronis Training and Certification – Authorized Use Only

  • 3. Component Installation Cheat Sheet

What to back up What to install Where to install Disk Space

VMs hosted on Microsoft Azure

The same as physical machines* On the machine that will be backed up Same as physical machines

VMs hosted on Amazon EC2 Citrix XenServer virtual machines** RHEV virtual machines & KVM** Oracle virtual machines** Exchange databases and mailboxes

Agent for Windows + Exchange On the machines running the Mailbox role of Microsoft Exchange Server If only mailbox backup is required, agent can be installed on any Windows with network access to the machine running Client Access role of Microsoft Exchange Server 950 MB

* A VM is considered virtual if it is backed up by an external agent. If an agent is installed in the guest system, the backup and recovery operations are the same as with a physical

  • machine. However, the machine is counted as virtual when you set quotas for the number of machines

**With Acronis Backup Advanced Virtual Host licenses, these virtual machines are considered as virtual (per host licensing is used). With an Acronis Backup Virtual Host license, these machines are considered physical (per machine licensing is used)

slide-30
SLIDE 30

38 Acronis Training and Certification – Authorized Use Only

  • 3. Component Installation Cheat Sheet

What to back up What to install Where to install Disk Space

SQL databases

Agent for Windows + SQL On the machine running Microsoft SQL Server 950 MB

Machines running Active Directory Domain Services

Agent for Windows + Active Directory On the domain controller 950 MB

Office 365 Mailboxes

Agent for Office 365 On a Windows machine that is connected to the Internet 500 MB

Mobile devices running iOS

Mobile app for iOS On the iOS mobile device 88 MB

Mobile devices running iOS

Mobile app for Android On the Android mobile device 30 MB

Recover SharePoint items

SharePoint Explorer On the SharePoint recovery farm or Front-End and Database server 12 MB

Enables users to monitor backups

Backup Monitor On a machine running Windows or OS X 10 MB

Provides command-line interface

Command-Line Tool On a machine running Windows or Linux 550 MB

slide-31
SLIDE 31

39 Acronis Training and Certification – Authorized Use Only

  • 3. Component Installation Cheat Sheet

Function What to install Where to install Disk Space

Manages Agents, provides web interface for management

Management Server* For on-premise deployment, on a machine running Windows or Linux. For cloud, no installation required 1.7 GB (Win) 0.6 GB (Lin)

Monitoring Service

Monitoring Service On the machine running the Management Server

  • Stores backup, required for

cataloging and deduplication

Storage Node On a machine running Windows 1.1 GB

Performs cataloging of backups on Storage Nodes

Catalog Service On a machine running Windows

  • Enables booting machines into

bootable media through the network

PXE Server On a machine running Windows

  • Creates bootable media

Bootable Media Builder On a machine running Windows or Linux 200 MB**

* A management server with one registered machine consumes 200 MB of memory. Each newly registered machines adds about 4 MB. Thus, a server with 100 registered machines consumes approximately 600 MB above the operating system and running applications. Max. number of registered machines is 900-1000. This limitation originates from the management server's embedded SQLite. This limit can be overcome by specifying an external Microsoft SQL Server instance during Management Server installation. With an external SQL database, up to 2000 machines can be registered with significant performance degradation. **Bootable media requires at least 1GB of RAM

slide-32
SLIDE 32

40 Acronis Training and Certification – Authorized Use Only

  • 3. Required Linux Packages

Linux distribution Package names How to install

Red Hat Enterprise Linux

kernel-devel gcc make The setup program will download and install the packages automatically by using your Red Hat subscription perl Run the following command: yum install perl

CentOS Fedora

kernel-devel gcc make The setup program will download and install the packages automatically perl Run the following command: yum install perl

Ubuntu

linux-headers linux-image gcc make perl Make sure RPM Package Manager is installed and run the following commands sudo apt-get update sudo apt-get install linux-headers-`uname -r` sudo apt-get install linux-image-`uname -r` sudo apt-get install gcc-<package version> sudo apt-get install make sudo apt-get install perl

slide-33
SLIDE 33

57 Acronis Training and Certification – Authorized Use Only

  • 3. Acronis Backup Cloud – Add Machines

Click to add machines

slide-34
SLIDE 34

58 Acronis Training and Certification – Authorized Use Only

  • 3. Adding Machines

‒ To add machines for backup, login to the Backup Console ‒ Click on the ADD button to start adding machines to be backed up:

▪ Installers for Agents for supported OS, virtualization platforms and applications can be downloaded for local installation on machines to be backed up ▪ For Acronis Backup on-premise management with a Windows-based Management Server, Remote Installation is also available in addition to downloading installers for local installation

slide-35
SLIDE 35

59 Acronis Training and Certification – Authorized Use Only

  • 3. Adding Machines

Select the machine type to download the installer or to perform remote installation

slide-36
SLIDE 36

60 Acronis Training and Certification – Authorized Use Only

  • 3. Adding Machines

For Acronis Backup Cloud and Acronis Backup cloud-based management, once a device type has been selected, instructions will be shown and download will start automatically

slide-37
SLIDE 37

62 Acronis Training and Certification – Authorized Use Only

  • 3. Adding Machines

‒ Ensure that the following requirements are met:

▪ Acronis Backup Cloud and Acronis Backup cloud-based management:

  • Internet connectivity for target machines
  • Allow inbound and outbound connections through firewalls and other network security system such as

proxy servers for TCP ports 443, 8443, 7770…7800 and 44445

  • Configure HTTP proxy server settings for target machines for agent installation and subsequent data

transfer

▪ For Acronis Backup on-premise management

  • On-premise Management Server (on a Windows or Linux machine) is installed
  • Allow inbound and outbound connections through firewalls and other network security systems similar to

Acronis Backup cloud management

slide-38
SLIDE 38

63 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

‒ The following Agents are available for installation on Windows:

▪ Agent for Windows, Exchange, SQL, Active Directory, Office 365, VMware (Windows), Hyper-V

‒ Select the corresponding Window-based platform from the ADD menu or download the offline installer (full installer) for Windows ‒ If installing on a domain controller, specify an existing user account for the Logon account for the agent service via Customize installation settings. (For security reasons, the installer does not automatically create new accounts on a domain controller)

slide-39
SLIDE 39

64 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

1. Log on as an administrator and run the installer 2. [Optional] To change the language, click Setup language 3. [On-premise] Select Install a backup agent (all applicable Agents will be installed) and specify the hostname/IP address of the Management Server. Optionally, click on Customize installation settings to change installation settings 4. [Cloud] Click on Install to install with default settings

  • r Customize installation settings to change

defaults and enter the credentials of the account to which the machine will be assigned to 5. Start the installation

slide-40
SLIDE 40

65 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

‒ The following Agent is available for installation on Linux:

▪ Agent for Linux

‒ Select Linux from the ADD menu to download the 64- bit installer ‒ To download the 32-bit installer instead, cancel the automatic download and click on the link for the 32-bit installer in the instructions shown after clicking ADD ‒ Ensure necessary Linux packages are installed on the target machines prior to installing Agents

slide-41
SLIDE 41

66 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

1. Log on As the root user, run the installer

▪ ./AcronisBackup_12_64-bit.x86_64 or ▪ ./AcronisBackup_12_32-bit.i686

2. Accept the terms of the license agreement 3. [On-premise] Clear the Acronis Backup Management Server checkbox and click Next to specify the hostname/IP address of the Management Server 4. [Cloud] Specify the credentials of the account to which the machine will be assigned to 5. Click Next to start the installation

slide-42
SLIDE 42

67 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

‒ The following Agent is available for installation on Mac:

▪ Agent for Mac

‒ Select Mac from the ADD menu to download the installer

slide-43
SLIDE 43

68 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

1. Run the installer (.dmg) and wait for the OS to mount the installation disk image 2. Double-click Install.pkg and click on Continue 3. If prompted, provide administrator credentials 4. [Optional] Click Change Install Location to change installation path 5. [Cloud] Specify the credentials of the account to which the machine should be assigned 6. Click Install to start installation

slide-44
SLIDE 44

69 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

‒ The following Agents are available for Acronis Backup

  • n-premise deployments:

▪ Agent for VMware (Virtual Appliance), Agent for VMware (Windows)

‒ The following Agent is available for Acronis Backup cloud deployment and Acronis Backup Cloud:

▪ Agent for VMware (Windows)

‒ Agent for VMware (Virtual Appliance) can be installed via remote installation (preferred) or by manually deploying as OVF template ‒ Agent for VMware (Windows) can be installed locally via the Windows installer or the ESXi web installer

slide-45
SLIDE 45

70 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Agents

1. Log on as an administrator and run the installer 2. [On-premise] Select Install a backup agent and specify the hostname/IP address of the Management

  • Server. Then click on Customize installation

settings and select Agent for VMware (Windows) under What to install 3. [Cloud] Click on Install to install with default settings

  • r Customize installation settings to change

defaults and enter the credentials of the account to which the machine will be assigned to. Then specify the hostname/IP address and access credentials of the vCenter Server or standalone ESXi host whose VMs will be backed up by the Agent 4. Start the installation

slide-46
SLIDE 46

71 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Mobile App

‒ The following mobile apps are available for mobile devices:

▪ Mobile app for iOS, Mobile app for Android

‒ The mobile apps can be installed by searching and downloading the app from the respective App Store ‒ For Acronis Backup, a valid Acronis Cloud Storage subscription license is required for backing up data on mobile devices

slide-47
SLIDE 47

72 Acronis Training and Certification – Authorized Use Only

  • 3. Local Installation – Installing Mobile App

1. Download and install the app 2. When the app is started for the 1st time, specify the credentials of the account to which the mobile device will be assigned to 3. Once signed-in, the following settings can be configured:

▪ Continuous Backup: Select from On, Only when charging or Off ▪ Backup Using: Select from Wi-Fi only or Wi-Fi and cellular connection

slide-48
SLIDE 48

79 Acronis Training and Certification – Authorized Use Only

  • 3. Deploying Agents Through Group Policy

‒ Windows-based Agents can be installed via Group Policy on machines that are members of an AD domain ‒ Requirements:

▪ AD domain with a domain controller running Windows Server 2003 or later ▪ User account that is a member of the Domain Admins group ▪ All agents for installation in Windows installer

‒ Steps:

▪ Create the .mst and .msi files for unattended installation via the installer and place them in a shared folder ▪ Create and configure the GPO for the OU containing the domain computers which will be installed with the Windows-based Agents

slide-49
SLIDE 49

80 Acronis Training and Certification – Authorized Use Only

  • 3. Updating Agents

‒ For on-premise management, update the Management Server and thereafter repeat the agent installation locally or via remote installation ‒ For Acronis Backup Cloud and Acronis Backup cloud-based management, Agents are updated as soon as a new version is released unless the Agent Auto Update setting for the User Account which the machines are assigned to is disabled ‒ Alternatively, to manually update an Agent, do the following:

▪ Click Settings > Agents, machines with outdated Agents will have an ! mark ▪ Select the machines that you want to update, machines must be online ▪ Click Update agent

slide-50
SLIDE 50

81 Acronis Training and Certification – Authorized Use Only

  • 3. Uninstalling

‒ Uninstalling components such as Agents will not remove them from the Backup Console ‒ Deleting machines from the Backup Console will not uninstall the Agents from machines, they must be manually uninstalled ‒ To uninstall, perform the following:

▪ In Windows, go to Control Panel > Programs and Features to uninstall Acronis Backup

  • As part of uninstallation, you can choose to select or clear the Remove the logs and configuration

settings check box

  • Keeping the setting will enable the machine to be re-associated with existing backups and backup plans

when Agents are reinstalled

  • Removing the setting will result in duplicates in the Backup Console upon re-installation of Agents
slide-51
SLIDE 51

82 Acronis Training and Certification – Authorized Use Only

  • 3. Uninstalling

▪ In Linux, run /usr/lib/Acronis/BackupAndRecovery/uninstall/uninstall

  • As part of uninstallation, you can choose to select or clear the Clean up all product traces (Remove the

product’s logs, tasks, vaults, and configuration settings) check box

  • Similar to Windows, keeping the setting will enabled the machine to be re-associated and removing the

setting will result in duplicates upon re-installation of Agents

▪ In Mac, double-click the installation file (.dmg), wait for it to be mounted and double-click Uninstall ▪ In VMware, log on to vCenter Server or the standalone ESXi with vSphere Client, right- click on the virtual appliance and select Delete from Disk

  • If the appliance is powered on, it must be powered off first
  • If locally attached storage is used as a backup destination and you wish to preserve the data, edit the

settings of the appliance and remove the disk with the storage from the appliance prior to deleting it. The disk will remain in the datastore and can be attached to another Agent for VMware (Virtual Appliance)

slide-52
SLIDE 52

83 Acronis Training and Certification – Authorized Use Only

LAB 1

▪Cloud.Acronis.com ▪User: acelatam1 ▪Pass: Acelatam1

slide-53
SLIDE 53

84 Acronis Training and Certification – Authorized Use Only

Questions?

slide-54
SLIDE 54

85 Acronis Training and Certification – Authorized Use Only

www.acronis.com New Generation Data Protection twitter.com/acronis blog.acronis.com facebook.com/acronis
