A D A M O A K S E N E R G Y , L L C Adam Oaks Energy, L.L.C. ( AOE ) is a company that provides high quality technical engineering services and products to its clients. AOE began operations on July, 2013 Our Vision is the commitment to


slide-1
SLIDE 1

A D A M O A K S E N E R G Y , L L C

slide-2
SLIDE 2
  • Adam Oaks Energy, L.L.C. (AOE) is a company that provides high quality

technical engineering services and products to its clients. AOE began

  • perations on July, 2013
  • Our Vision is the commitment to customer satisfaction, providing high quality

products and timely deliveries, AOE has built an excellent global distribution network and the capability of providing value added services to end users.

  • At AOE we are O&G single source and single point of contact solutions

providers, working on a global scale. With a base of operations in the O&G capital of the world — Houston, Texas USA

slide-3
SLIDE 3

KEY BENEFITS OF PRODUCT OR SERVICE

Services that Depend on Project Scope Worldwide Database Competitive intelligence data Pricing analysis Products sold and accepted by all major US and worldwide customers All our products go thru a rigorous quality control and inspection process in place conforming to API 5CT specifications (last edition).

slide-4
SLIDE 4

HYDRAULIC WELLHEAD DRIVE /PCP – REF:54-AOE

  • Compact enclosed gearbox

with a long service life

  • Zero maintenance stuffing box
  • Double lip seals and high

strength alloy shafts

  • Accepts ”C” mount hydraulic

motors and capable of 1250 ft- lb torque

  • H. Belt Drive
slide-5
SLIDE 5

HYDRAULIC PUMP UNIT – REF: 53-AOE

MODEL 53-AOE-800 GENERAL SPECIFICATIONS Structure Capacity 80,000 lbs Stroke Length 360 in System Horsepower Options (Maximum SPM) 100 HP – SPM 2.1 125 HP – SPM 2.8 150 HP – SPM 3.0 CRN.CSA Approved

slide-6
SLIDE 6

HYDRAULIC PUMPING UNIT – REF: 50-AOE

  • Specifications:
  • Direct mount to wellhead
  • Load rating of 18,000 lb
  • Stroke length of 0" to 120"
  • Variable stroke speed of 0 to 8 spm.
  • Benefits:
  • Low set-up cost vs. pump jack /cement pad
  • Minimal ground disturbance
  • No guide anchors required
  • Set up time 2 hrs. on location with 1-ton

picker/crew

  • Applications for:
  • Remote areas
  • De-water gas wells
  • Oil production wells

Unit: 50-AOE-1800

slide-7
SLIDE 7

HYDRAULIC SKID – REF: 50-AOE

Features:

  • 9' x 5' Enviro-Pan
  • 360 liter hydraulic tank
  • 1" Hoses, 4000 PSI
  • Adjustable engine rails
  • Full gauge panel
  • Heat trace
  • Bug screen
  • 100 gpm in-tank filter system (3 micron)
  • Rexroth 71cc, 35 gpm, 4000 PSI MAWP
  • Open style engine, GM 5.7L or 4.3L
  • Oil drain to edge skid
  • Luber-Finer system
  • Exhaust guards
  • Remote oil fill
  • Belt guard
slide-8
SLIDE 8

PERMANENT MAGNET MOTOR DRIVE – REF: 55 - MOM

  • Motor Drive safe and secure
  • No exposed moving parts, no belts
  • r sheaves, no external braking
  • PMMD Can reduce energy

consumption by 35+% Vs Induction motors

  • Requires minimum manpower and

maintenance

slide-9
SLIDE 9

ROD CLAMPING BOP – REF: 55 - MOM

  • The ROD CLAMPING (BOP). When in

the closed position the rams seal and clamp around the polished rod sealing

  • ff

the well bore and secures the rod string. The clamping action enhances safety and reduces work over costs.

  • Universal top connection can be

used with any drive head (studded

  • r flanged connection)
  • Suitable for sour applications.
slide-10
SLIDE 10

SURFACE TUBING SPINNER – REF: 55-MOM

  • The SURFACE TUBING SPINNER

reduces production costs, extending the life of the production tubing by allowing the entire inside circumference to wear evenly. The rotator becomes part of the well head assembly as it sits between the well head and blow out

  • preventer. The rotator is designed

to work with both; a progressing cavity pumping system and rod pumping system.

slide-11
SLIDE 11

DRILLING & WELL CONTROL SCHOOLS – REF: 8-FLA

17 more courses available for O&G operations IADC/WCI/IWCF certification Included

slide-12
SLIDE 12

INFLATABLE PACKERS – REF: 4-CHI

Applications:

  • Cementing Assurance
  • Preventing of gas migration behind Casing
  • Reduce the formation damage
  • Casing centralizer on Horizontal sections
  • Slotted Liner / Steam Injection (600F)
  • Multi- Stage Frac segmentation
slide-13
SLIDE 13

OIL / WATER SWELLABLE PACKER – REF: 3-WRS

  • Applications:
  • Cementing Integrity
  • Multistage Frac - Segmentation
  • Sand Control Screen – Segmentation
  • Extra-Annular Barrier for Liner Hanger
  • Cement replacement in critic zones
slide-14
SLIDE 14

HYDRAULIC PACKER – REF: 2-FTX

The patented 2-FTX-5 is a hydraulic set packer double grip, designed for injector and production wells It can be used for variety of casing zones. This packer is specifically designed for multi-zone injection wells, its main advantage is safety; Several devices prevent release and accidental setting during running operations, ideal for deviated wells. Easy for setting and release (just ¼ turn). This Packer resist high differential pressure Once at final depth it can be left with weight, tension or neutral. Differential pressure or Temperature Does not affect packer condition.

slide-15
SLIDE 15

Contact: Diego Robles-Silva 42 Meadowridge Pl. The Woodlands, TX 77381 USA

  • Mobile: (+1) 832 948 3404
  • Email: drobles@aoakse.com
