Terminals and Lugs 2018 Presentation
INNOVATIVE SOLUTIONS TO ELECTRIC CONNECTION MATTERS! EGI è produttore di terminali a compressione EGI is leader in Italy and Europe for the leader in Italia e in Europa dal 1973 production of terminals and lugs since 1973 Beyond being the most innovative company in the electric fiels, EGI boasts the largest and most complete range of products in the market, with wire range from 0,25 up to 1.000 mm².
HIGHLIGHTS FROM RAW MATERIAL INCOMING TO FINAL CUSTOMER DELIVERY: The productive process which allows EGI to achieve the Europe leadership in terminals production. 1. Study, design and realization of moulds to obtain products more and more innovative to face any kind of electric connection matters. 2. Incoming raw material – copper ETP 99,9 – is divided and prepared to be processed. 3. Rough products obtained are subjected to protective treatment through electrolytic tinning and annealing. 4. Final product is packaged in blister and stocked in warehouse to be shipped to final customer.
HIGHLIGHTS HIGH QUALITY! � EGI products are manufactured using mainly copper ETP 99,9 � Protective treatment is obtained with electrolytic tinning � For insulation is used special PVC. � EGI has updated the Certified Quality Management Syste CSQ-UNI ISO 9011:2015 � All terminals are compliant to CEI-EN 61238-1 rules � Compliant to brand � Compliant to brand � Compliant to Rhos (200295CE) directive and following updating
HIGHLIGHTS SPECIAL PRODUCTS ON REQUEST EGI production has the possibility to manufacture, in short time and with low costs, special products out of catalogue ,or make changes to standard products, following the particular needs of every single customer. DELIVERY TIME Standard material is always in stock, so that we can reduce delivery time RELIABILITY AND EXPERIENCE More than 40 years of experience in the electric sector, together with quality, innovation and skills make EGI leader both in Italy and abroad.
INSULATED TERMINALS RED, BLUE AND YELLOW wire range from 0,25 up to 6 mm² � RINGS The only ones in the market with rectangular shape which is a guarantee of Italian production and which gives functionality advantages: 1. Possibility of introduction in limited spaces 2. Terminal auto-balancing 3. Better electrical connection Made with tinned copper ETP 99,9 � FORKS With anti slip groove , which provides a better connection on screw. Made in tinned copper ETP 99,9 � RAPID CONNECTION - Male and female totally or partially insulated - Male+female - Male and female socket - Butt connectors - Round and flat pin terminals
NOT INSULATED TERMINALS WIRE RANGE from 0,25 up to 6 mm² � RINGS made in tinned copper ETP 99,9 � FORKS made in tinned copper ETP 99,9 with anti slip groove � ROUND AND FLAT PIN TERMINALS made in tinned copper ETP 99,9 � RAPID CONNECTION TERMINALS - Female – Tinned brass OT67 - Male – tinned copper ETP 99,9 - Male, female, male+female, sockets open terminals – Not tinned brass OT 67 � QUICK CONNECT MALE BRASS TABS
END FERRULES Certified CSA-US for U.S.A. and Canadian markets COLOUR COMPLIANT TO DIN 46228/4 MATERIAL: tinned copper ETP 99,9 The range of end ferrules wire range from 0,25 up to 150 mm² includes: � INUSLATED END FERRULES � TWIN WIRE INSULATD END FERRULES � INSULATED END FERRULES REEL SERIES � NOT INSULATED END FERRULES
POWER TERMINALS Materiale: tubo rame stagnato TINNED COPPER ETP 99,9 RANGE FROM 1,5 TO 1.000 mm²: - STANDARD SERIES - LONG BARREL DOUBLE CRIMPING SERIES - REDUCED CONNECTIONSERIES - DIN COMPLIANT SERIES - FORCELLE DI POTENZA - POWER FORK TERMINALS SERIES - DOUBLE HOLE TERMINALS SERIES - MEDIUM TENTION SERIES
POWER TERMINALS ON REQUEST ALL POWER TERMINALS CAN BE BENT TO 90°, 45° or 30° TYPE C (bent) OR FOLLOWING THE SINGLE NEEDS OF CUSTOMERS
POWER TERMINALS ALL THE POWER TERMINALS SERIES CAN ALSO BE PRODUCED IN INOX STEEL On request of each customer also in small quantities and in short time
SOFT SLEEVES FOR POWER TERMINALS MATERIAL: soft PVC ADVANTAGES OF SOFT SLEEVES � Type P tube is suitable for cold use (it is not heat shrink sleeve) � It is not necessary to keep double stock of insulated and not insulated power terminals � Possibility to obtain a TOTAL INSULATION only with the application of the soft sleeve � Usually supplied in black colour, the sleeve can be realisezalso in 10 DIFFERENT COLOURS with wire range from 1 up to 1.000 mm2 NEW! STARTING FROM 2018 AVAILABLE ALSO IN ORANGE
POWER JOINTINGS AND CONNECTORS Materiale: tubo rame ETP 99,9 stagnato Material: tinned copper tube � BUTT CONNECTORS � PARALLEL CONNECTORS Butt connectors are made with copper tube to the same dimensions as the power terminals and they have smoothed on both end sides for an easy cable entry. � “C” CONNECTORS � FLEXIBLE BRAIDS � MEDIUM TENSION BUTT SPLICES
ALUMINIUM-COPPER BIMETALLIC POWER TERMINALS AND CONNECTORS Material: copper and aluminiumo - RING BIMETALLIC TERMINALS SUITABLE FOR ALUMINIUM CABLES Ring in copper ETP 99,9 Barrel in aluminium 99,5% - BIMETALLIC PIN TERMINALS SUITABLE FOR ALUMINIUM CABLES Pin in copper ETP 99,9 Barrel in aluminium 99,5% - ALUMINIUM TERMINALS Aluminium 99,5% - ALUMINIUM JOINTING SLEEVES FOR ALUMINIUM CABLES Aluminium 99,5% - ALUMINIUM JOINTING SLEEVES WITH DIFFERENT WIRE RANGE
CABLE CLAMPS Material: Nickel AC brass - CABLE CLAMPS TERMINALS 2 bolts or 4 bolts - CLAMP TERMINALS 1 bolt or 2 bolts - CLAMPS FOR EARTHING DERIVATION Aluminium boisy and nickel steel bolt - DERIVATION CABLE CLAMPS Type U – 2 screws Type T – 3 screws - SINGLE END TERMINAL BLOCK Terminal shell of Polycarbonate Insert of brass and screw of zinc plated steel. Suitable for terminal blocks for derivations in embedded and external boxes
CABLE GLANDS Material: nickel brass, nylon and plastic CABLE AGLANDS AND HEXAGONAL LOCK NUTS IN NICKEL BRASS - GAS thread – IP 54 - PG thread – IP 54 - Metric thread (stress relief with lock nut included) – IP 68 NYLON STRESS RELIEF CABLE GLANDS WITH LOCK NUT INCLUDED - PG thread – IP 68 - Metric thread – IP 68 - Series with strain relief and lock nut included - Bent to 90° CABLE GLANDS, LOCK NUTS AND BLINDING PULGS - PG thread – IP 54
CABLE TIES Material: UL Approved Nylon 66 Colour: white and black - STANDARD CABLE TIES - RING CABLE TIES - MARKER TIES - SELF-ADHESIVE TIE MOUNT - CABLE TIES WITH BLOCK SYSTEM, HIGH STRENGTH FOR EXTERNAL USE - NYLON CABLE CLAMPS - BINDING BONDS
CRIMPING TOOLS ART.60 Ratchet tool for insulated terminals from 0,25 up to 6 mm² - DOUBLE CRIMPING - TAPERED HEAD TO AID INSERTION IN TIGHT SPACES - LENGTHENED GRIP FOR EASY CRIMPING CONTROL QUALITY PUNCHING The punching quality control function alerts the operator when the crimping of the cable is complete. Each wire range correspond to a specific letter: Yellow=E - Blue=G – Red=I During the crimping phase on the PVC tube a letter, which correspond to the cross section, will be printed on the PVC. The crimping is accepted once the letter is clearly readable, if the letter is unreadable, it notifies the operator of failed crimp.
CRIMPING TOOLS - TOOLS FOR INSULATED AND NOT INSULATED END FERRULES FROM 0,5 TO 150 mm² - TOOLS FOR INSULATED TERMINALS FROM 0,25 TO 6 mm² - MANUAL RATCHET TOOLS FOR NOT INSULATED TERMINALS (hexagonal and punch crimping) - TOOLS FOR OPEN TERMINALS - MANUAL HYDRAULIC TOOLS - FOOT LEVER HYDRAULIC TOOLS - OLEODYNAMIC HEADS - WIRE STRIPPER - CABLE CUTTER - CABLE STRIPPER - CABLE TIES TOOLS - PNEUMATIC CRIMPING TOOLS
INNOVATIVE PRODUCTS AND SPECIAL PRODUCTS We can produce innovative new products studied and realized by our design office or following the connection needs of every single customer. Innovative products and special products are always updated in the NEWS section of our website www.egisrl.it
SOME EXEMPLES OF INNOVATIVE ITEMS… FIVE HOLES POWER TERMINAL - 1.000 mm² On request we can produce also for other wire range/axe distance/screw holes HEXAGONAL HOLE POWER TERMINAL for earth wire and short circuit. The hexagonal hole allows to connect and disconnect the cable without remove the locking bolt. From 35 to 150 mm² DOUBLE BUTTONHOLE POWER TERMINAL of which 1 hole M8 and 1 buttonhole. Wire range realizable from 16 to 50 mm². Axe distance 12
SECTOR EXHIBITION IN ITALY AND ABROAD
TALKING ABOUT US…
EGI AND SPONSORSHIP…
THANK YOU FOR THE ATTENTION Via Gobetti 44 20090 Fizzonasco di P.ve Emanuele – Milano Tel. 02 90721944 – Fax 02 90724646 info@egisrl.it www.egisrl.it
