Electric Shock Drowning 07/22/2015 Ed Lethert Electric Shock - - PowerPoint PPT Presentation

07/22/2015 Ed Lethert

Electric Shock Drowning

07/22/2015 Ed Lethert

Electric Shock Drowning

Thanks to Gary Hughes Greg Nybeck LMCD Board

2

07/22/2015 Ed Lethert

Electric Shock Drowning

Edward "Ed" Lethert

Electric Shock Drowning Safety Specialist

New Hope, MN elethert@gmail.com www.electricshockdrowningmn.com

3

Background Lakeshore Weekly News Article

07/22/2015 Ed Lethert

Electric Shock Drowning

Lake Minnetonka Boater

4

Member: Minnetonka Power Squadron

07/22/2015 Ed Lethert

Electric Shock Drowning

5

ELECTRIC SHOCK DROWNING PREVENTION ASSOCIATION

07/22/2015 Ed Lethert

Electric Shock Drowning

6

AWARENESS PREVENTION

07/22/2015 Ed Lethert

Electric Shock Drowning

This evening's presentation

• Non-Technical
• A subset of the complete ESD

Presentation (approx 1½ hours)

• The full presentation can be made to

interested entities upon request

7

Thanks

07/22/2015 Ed Lethert

Electric Shock Drowning

8

Questions

Questions and comments are welcome and encouraged immediately following the presentation Presenter will also be available after the meeting to address additional questions

07/22/2015 Ed Lethert

Electric Shock Drowning

9

Thanks to Capt. David Rifkin and Kevin Ritz for permission to use some of their material.

07/22/2015 Ed Lethert

Electric Shock Drowning

10

Of all the people I have spoken with, almost no

• ne appears to have heard of Electric Shock

Drowning Recent Question to Lakeshore Property Owner:

"Is the circuit that powers your electrically operated boat lift protected by a Ground Fault Circuit Interrupter?"

Response:

"I have no idea."

07/22/2015 Ed Lethert

Electric Shock Drowning

Objectives … To Answer the Following

• What is Electric Shock Drowning?

(also known as "ESD")

• What conditions can cause ESD?
• Can water leakage currents or voltage

gradients be detected or measured?

• Are there serious danger thresholds?
• Are there standards, policies and

procedures for minimizing the risk of ESD?

11

07/22/2015 Ed Lethert

Electric Shock Drowning

Applicable Installations/Facilities

• Marina Facilities
• Private Docks *
• RV Parks, Campgrounds, etc.
• Swimming pools, spas, ponds, etc.
• Submersible Pumps
• Agricultural – Irrigation Canals
• Manhole covers – (New York City - "Street Zaps")

12

07/22/2015 Ed Lethert

Electric Shock Drowning

This subject material applies directly to ANY environments where electric circuits and equipment operate in, on, or near a body of water

13

07/22/2015 Ed Lethert

Electric Shock Drowning

Why Cause for Concern?

• Increase in use of electrically operated

equipment in and around recreational (and non-recreational) waters

• Increase in Do-It-Yourself electrical work by

unqualified individuals

• Lack of inspections by the Authority Having

Jurisdiction (electrical inspections)

• Less caution exercised by the public
• More litigious culture

14

07/22/2015 Ed Lethert

Electric Shock Drowning

15

ESD Victims

07/22/2015 Ed Lethert

Electric Shock Drowning

16

Lost to ESD

Comment: Samantha Chipley Article

07/22/2015 Ed Lethert

Electric Shock Drowning

17

Marcus Colburn, age 21, died as a result of ESD

• n Father’s Day, June 21st, 2015

Lost to ESD

Comment: Circuit Breaker

07/22/2015 Ed Lethert

Electric Shock Drowning

18

James D. Shafer and Capt. David Rifkin (USN, Ret) have compiled a database of known ESD incidents going back as far as the mid-1980s It's the only known list of its kind It is updated by Capt. Rifkin as each new ESD related incident becomes known

07/22/2015 Ed Lethert

Electric Shock Drowning

19

It is believed that the actual number of ESD fatalities is much higher than known or reported as paralysis due to small electric currents passing through the body is not recognizable post- mortem as the cause of the drowning

07/22/2015 Ed Lethert

Electric Shock Drowning

20

Electrical Safety Around Water

07/22/2015 Ed Lethert

Electric Shock Drowning

21

This goes without saying

07/22/2015 Ed Lethert

Electric Shock Drowning

22

As does this … I hope

07/22/2015 Ed Lethert

Electric Shock Drowning

23

07/22/2015 Ed Lethert

Electric Shock Drowning

24

07/22/2015 Ed Lethert

Electric Shock Drowning

25

The possibility of an in-the-water shock hazard exists wherever shore-powered AC electrical equipment is located in the water, over the water, or near the water Awareness of and mitigation of in-water shock hazards (the cause of ESD) is of vital importance

07/22/2015 Ed Lethert

Electric Shock Drowning

26

National Electrical Code 90.1 Purpose. (A) Practical Safeguarding. The purpose

• f this Code is the practical safeguarding
• f persons and property from hazards

arising from the use of electricity. …

2014 NEC (NFPA 70)

07/22/2015 Ed Lethert

Electric Shock Drowning

27

"practical safeguarding of persons"

• Standards — Laws — Regulations

WV, TN, KY , MO, etc. MN?

• Quality and Skilled Workmanship
• Inspection by Competent Authority
• Ongoing Monitoring and Inspection
• EDUCATION OF THE PUBLIC

Comment: Legislative actions MN DLI Electrical Inspections Div

07/22/2015 Ed Lethert

Electric Shock Drowning

28

Electric Shock Drowning

07/22/2015 Ed Lethert

Electric Shock Drowning

29

Electric Shock Drowning (ESD) is a unique form of drowning caused by waterborne alternating currents (AC) These currents can produce dangerous voltage gradients in the water The voltage gradients can cause an electrical current to flow through the body of an individual in the water

07/22/2015 Ed Lethert

Electric Shock Drowning

30

The thru-body current produced by the voltage gradient, if sufficiently high, can paralyze the body's muscles, inhibiting

• ne's ability to swim, or even to move
• ne's limbs … or worse

The outcome in most ESD cases is that an

• therwise healthy individual drowns

(water in the lungs)

07/22/2015 Ed Lethert

Electric Shock Drowning

31

These thru-body currents, depending on their magnitude, can:

• Paralyze skeletal muscles
• Cause respiratory paralysis (shut down

the lungs)

• Initiate ventricular fibrillation
• Result in full cardiac arrest

07/22/2015 Ed Lethert

Electric Shock Drowning

32

ESD is not exactly the same as death by electrocution, which usually results from direct contact with energized metal

• bjects or surfaces

In-water electrocutions are included in the definition of ESD because they are caused by the same fault conditions that cause an ESD fatality

07/22/2015 Ed Lethert

Electric Shock Drowning

33

According to OSHA, an AC current as small as 6 mA through the body can begin to affect muscle control It is generally agreed that 10 mA of AC current flowing through the body (0.01 amperes) is the threshold at which the current could be considered potentially lethal

07/22/2015 Ed Lethert

Electric Shock Drowning

34

US Dept. of Labor: OSHA – "How Electrical Current Affects the Human Body" www.osha.gov/SLTC/etools/construction/electrical_incidents/ eleccurrent.html

07/22/2015 Ed Lethert

Electric Shock Drowning

35

Mechanism Typical AC Current Loss of arm/leg muscle control: Average female 10 mA Loss of arm/leg muscle control: Average male 16 mA Paralysis of breathing muscles 20 mA Heart fibrillation 100 mA

"Conduction of Electrical Current to and Through the Human Body: A Review" Richard M Fish, PhD, MD, FACEP and Leslie A Geddes, MS, PhD, DSc, Eplasty, v9(2009)

07/22/2015 Ed Lethert

Electric Shock Drowning

36

One 60 watt, 120 volt incandescent light bulb draws 500 milliamperes of current … 50 times more than the 10 mA that can paralyze an individual in the water

By way of comparison …

07/22/2015 Ed Lethert

Electric Shock Drowning

37

What about pets and other critters?

07/22/2015 Ed Lethert

Electric Shock Drowning

38

Animals are not immune to the effects of these water-borne currents ESD has claimed family pets that have entered these charged waters

and

Individuals have fallen victim to ESD when entering the water in an attempt to rescue their pets

Example – Irrigation canal deaths

07/22/2015 Ed Lethert

Electric Shock Drowning

39

A Monumental ESD Tragedy

Friday Aug 31, 2012 Track coach [woman], two men [one a relative], 1 dog [family pet] electrocuted in Idaho irrigation canal Another family member attempting a rescue was shocked but survived Police say: "The electrified canal could have killed more" They [canal experts] say it is virtually impossible to know if water is electrified by sight or sound Idaho Power shut off the power in the area so rescuers could recover the bodies

07/22/2015 Ed Lethert

Electric Shock Drowning

40

Solar Powered Boat Lift

07/22/2015 Ed Lethert

Electric Shock Drowning

41

Direct Current (DC) is generally not a concern, although it can be a fire or burn hazard under certain conditions It takes from 2 to 5 times as much direct current (DC) to cause the same bodily effect as alternating current (AC) 12 and 24 volt DC systems are not able to produce the water-borne currents or voltage gradients necessary to create an ESD hazard

07/22/2015 Ed Lethert

Electric Shock Drowning

42

Remember:

An in-the-water shock hazard can exist wherever shore-powered AC electrical equipment is located in the water, over the water, or adjacent to the water … regardless of its function

07/22/2015 Ed Lethert

Electric Shock Drowning

43

Water Leakage Currents

07/22/2015 Ed Lethert

Electric Shock Drowning

44

We know a whole lot more about ESD, water-borne leakage currents and voltage gradients thanks to the extensive and thorough investigative work of

• Capt. David Rifkin (USN, Ret) and James D. Shafer

07/22/2015 Ed Lethert

Electric Shock Drowning

45

This significant and ground-breaking work by David Rifkin and James Shafer, funded by the US Coast Guard, has provided us with a wealth of data on In- Water Shock Hazards and ESD David Rifkin's research is ongoing and this 150+ page work is one that your presenter references often

07/22/2015 Ed Lethert

Electric Shock Drowning

46

Available at www.qualitymarineservices.net

07/22/2015 Ed Lethert

Electric Shock Drowning

47

Kevin Ritz is a major and long-time contributor to ESD awareness, research and prevention. He lost his son of 8 years, Lucas Ritz, in 1999 as the result of Electric Shock Drowning

07/22/2015 Ed Lethert

Electric Shock Drowning

48

The research by David Rifkin and James Shafer has shown that ESD is a fresh water phenomenon This is due principally to the much lower conductivity (much higher resistance) of fresh water The greater part of the in-water current will flow through the human body with a lesser amount flowing around it

07/22/2015 Ed Lethert

Electric Shock Drowning

49

Water Current Water Current

Voltage Gradient = 23.8 Volts --- Very Lethal

Voltage Gradient 6 Ft

Fresh Water

Body Current

Current Source

Body current is large relative to water current

Current Source

07/22/2015 Ed Lethert

Electric Shock Drowning

50

Causes of Water Leakage Currents

07/22/2015 Ed Lethert

Electric Shock Drowning

51

To establish dangerous levels of leakage current flow in the water—and thus produce the resulting lethal voltage gradients—two conditions must be met

07/22/2015 Ed Lethert

Electric Shock Drowning

52

First …

There must be some form of electrical fault (hot to ground) at some point in the AC system (AC powered wiring or equipment) This will be a low level fault current as

• pposed to the high level of current that
• ccurs as the result of a short circuit

The low level fault current is not enough to trip a circuit breaker … so it remains continuous and undetected

07/22/2015 Ed Lethert

Electric Shock Drowning

53

Second …

There must be a failure in the shore power bonding (grounding) system … the equipment bonding/grounding path

• Total failure (open circuit)
• Very seriously

degraded wiring

• r connection

07/22/2015 Ed Lethert

Electric Shock Drowning

54

When these two conditions exist at the same time, any underwater metals— which are no longer bonded back to the AC source—become energized to lethal voltage levels The difference in voltage between these energized metals and the power source ground establishes dangerous currents and voltage gradients in the water

07/22/2015 Ed Lethert

Electric Shock Drowning

55

A person finding themselves in this "charged" water can experience a dangerous AC current passing through their body When this current is high enough, nominally in the range of 10 or more milliamps (that's thousandths of an ampere), paralysis is likely to occur, resulting in the inability to remain afloat, followed by drowning

07/22/2015 Ed Lethert

Electric Shock Drowning

56

07/22/2015 Ed Lethert

Electric Shock Drowning

57

07/22/2015 Ed Lethert

Electric Shock Drowning

58

07/22/2015 Ed Lethert

Electric Shock Drowning

59

Invitation to an ESD Incident

07/22/2015 Ed Lethert

Electric Shock Drowning

60

07/22/2015 Ed Lethert

Electric Shock Drowning

61

07/22/2015 Ed Lethert

Electric Shock Drowning

62

One of the 'HOT' conductors

07/22/2015 Ed Lethert

Electric Shock Drowning

63

07/22/2015 Ed Lethert

Electric Shock Drowning

64

07/22/2015 Ed Lethert

Electric Shock Drowning

65

07/22/2015 Ed Lethert

Electric Shock Drowning

66

07/22/2015 Ed Lethert

Electric Shock Drowning

67

07/22/2015 Ed Lethert

Electric Shock Drowning

68

07/22/2015 Ed Lethert

Electric Shock Drowning

69

Harbor Cove Marina, Duluth, MN

Which is why …

07/22/2015 Ed Lethert

Electric Shock Drowning

70

Minnetonka Power Squadron Island Facility, Lake Minnetonka

NO SWIMMING OFF OF BOATS OR DOCKS

07/22/2015 Ed Lethert

Electric Shock Drowning

71

When Is It "Safe" to Go Into the Water?

07/22/2015 Ed Lethert

Electric Shock Drowning

72

Safe is defined in Webster's 1828 Dictionary as

• 1. Free from danger of any kind
• 2. Free from hurt, injury or damage
• 5. Placed beyond the power of doing

harm

07/22/2015 Ed Lethert

Electric Shock Drowning

73

When is it "safe" to … ?

Careful consideration should be given to any use of the word "safe" when working

• r playing with or near electrically

connected equipment that is in, on or near the water

07/22/2015 Ed Lethert

Electric Shock Drowning

74

The term "safe" to enter the water is risky in itself and should never be used where and when shore power is installed and used, or in the context of water leakage currents

Example – BoatUS Article

07/22/2015 Ed Lethert

Electric Shock Drowning

75

The term "degree of risk" would be more suitable and excludes any inference that somehow absolute safety is guaranteed

07/22/2015 Ed Lethert

Electric Shock Drowning

76

So when is the risk of ESD "very low"? Opinions vary somewhat, but there is general agreement among experts that a minimum distance of between 150 feet and 300 feet from active AC electrical systems would reduce the danger of ESD to "very low risk" (and therefore acceptable?) levels for recreational activities

07/22/2015 Ed Lethert

Electric Shock Drowning

77

It could be considered "very low risk" to enter the water (for inspection, maintenance and repair purposes) where ALL nearby shore power is switched off AT THE POWER SOURCE This would include securing ALL nearby

• n-board generators and inverters

07/22/2015 Ed Lethert

Electric Shock Drowning

78

What about someone who falls into the water inadvertently (or is just plain careless regarding their well-being)? There are some visual checks and electrical tests that can be performed on a regular basis to reduce the risk of in- water shock for these individuals

07/22/2015 Ed Lethert

Electric Shock Drowning

79

It is never "safe" to enter the water in the vicinity of shore powered watercraft or equipment … for any reason … EVER! … while any nearby circuits are energized!

07/22/2015 Ed Lethert

Electric Shock Drowning

80

Checking the Shore System Wiring

07/22/2015 Ed Lethert

Electric Shock Drowning

81

When checking the shore system at the dock

• utlet, there is considerably more to it than

just checking for voltage and polarity

07/22/2015 Ed Lethert

Electric Shock Drowning

82

More information is required which means more sophisticated testing is required.

07/22/2015 Ed Lethert

Electric Shock Drowning

83

07/22/2015 Ed Lethert

Electric Shock Drowning

84

Checking for Leakage Current

07/22/2015 Ed Lethert

Electric Shock Drowning

85

07/22/2015 Ed Lethert

Electric Shock Drowning

86

Hioki 3283

Excellent for ESD work True RMS Very accurate Reads down to 0.01 mA Cost is ≈ 350.00

07/22/2015 Ed Lethert

Electric Shock Drowning

87

Prevention

07/22/2015 Ed Lethert

Electric Shock Drowning

88

NO SWIMMING OR WADING DO NOT ENTER THE WATER RISK OF ELECTRIC SHOCK

Signage

07/22/2015 Ed Lethert

Electric Shock Drowning

89

07/22/2015 Ed Lethert

Electric Shock Drowning

90

Ground Fault Protection

07/22/2015 Ed Lethert

Electric Shock Drowning

91

Class A GFCI Receptacle (5 mA Trip) Ground Fault Protection

07/22/2015 Ed Lethert

Electric Shock Drowning

92

Class A GFCI Breaker (5 mA Trip) Ground Fault Protection

07/22/2015 Ed Lethert

Electric Shock Drowning

93

Ground fault (GFCI protection required for 125V, 15 and 20 amp receptacle outlets:

• Swimming Pools (1971)
• Located Outdoors (1971) **
• Bathrooms (1973)
• Garages (1978)
• Spas and Hot Tubs – incl hardwired (1981)
• Boat Houses (1987) **
• Boat Hoists – incl hardwired (2005) **

07/22/2015 Ed Lethert

Electric Shock Drowning

94

Disconnect Switch at Accessible Location Ground Fault Protection

07/22/2015 Ed Lethert

Electric Shock Drowning

95

EPO Switch for Marinas ?

07/22/2015 Ed Lethert

Electric Shock Drowning

96

Codes and Standards

07/22/2015 Ed Lethert

Electric Shock Drowning

97

Marina Power Shore Cord

NFPA 70 National Electrical Code Article 555 Marinas and Boatyards Mandatory Compliance Required in Minnesota

Insure Compliance with Codes and Standards

07/22/2015 Ed Lethert

Electric Shock Drowning

98

ARTICLE 555 — Marinas and Boatyards [2014 NEC] 555.1 Scope. This article covers the installation of wiring and

equipment in the areas comprising fixed or floating piers, wharves, docks, and other areas in marinas, boatyards, boat basins, boathouses, yacht clubs, boat condominiums, docking facilities associated with residential condominiums, any multiple docking facility, or similar occupancies, and facilities that are used, or intended for use, for the purpose of repair, berthing, launching, storage, or fueling of small craft and the moorage of floating buildings.

Private, noncommercial docking facilities constructed or occupied for the use of the

• wner or residents of the associated single-

family dwelling are not covered by this article.

07/22/2015 Ed Lethert

Electric Shock Drowning

99

ARTICLE 555 — Marinas and Boatyards 555.1 Scope. This article covers the installation of wiring and

equipment in the areas comprising fixed or floating piers, wharves, docks, and other areas in marinas, boatyards, boat basins, boathouses, yacht clubs, boat condominiums, docking

facilities associated with one-family dwellings, two-family dwellings, multifamily dwellings,

and residential condominiums, any multiple docking facility, or similar occupancies, and facilities that are used, or intended for use, for the purpose of repair, berthing, launching, storage, or fueling of small craft and the moorage of floating buildings.

Proposed change in scope for inclusion in 2017 NEC

07/22/2015 Ed Lethert

Electric Shock Drowning

100

Typical ESD Event and Response

07/22/2015 Ed Lethert

Electric Shock Drowning

101

Typical ESD Scenario

• Victim enters the electrically charged water

… becomes partially or totally disabled

• Victim may or may not remain conscious
• Victim may not remain on surface
• Victim may or may not call for help
• Victim's situation can worsen when seeking a

"safe haven" (moves toward rather than away from the source)

07/22/2015 Ed Lethert

Electric Shock Drowning

102

Recommended Action for ESD Event The victim …

• should, if able, keep arms and legs close to

the body (this action reduces exposure to the voltage gradient)

• should, if able and possible, move back in

the direction from which they came — or

• therwise, move away from the presumed

current source

07/22/2015 Ed Lethert

Electric Shock Drowning

103

Recommended Action for ESD Event First responders/rescuers/bystanders …

• should, if at all possible, switch off all dock

electrical power at the source

• must fight the instinct to enter the water —

many well-meaning rescuers have died trying to help ESD victims

• must remember always to

Reach … Throw … Row … But Don't Go (into the water)

07/22/2015 Ed Lethert

Electric Shock Drowning

104

Recommended Action for ESD Event First responders/rescuers/bystanders …

• should throw life ring or other flotation

device, etc. to a conscious and able victim

• should not throw a line to the victim and

then pull the victim closer to the current source

• Should push the victim away from the

presumed source with an insulated pole

07/22/2015 Ed Lethert

Electric Shock Drowning

105

Recommended Action for ESD Event First responders/rescuers/bystanders …

• should attempt first aid/CPR where the

victim can be safely removed from the water

• should call for help immediately — Dial 911
• r call on VHF Channel 16 as appropriate
• should know that there is currently no known

portable test device available to quickly detect a hazardous condition in the water

07/22/2015 Ed Lethert

Electric Shock Drowning

106

Training Recommended ESD response training should be provided for the following (at a minimum)

• Law Enforcement
• Firefighters
• Emergency Medical Technicians
• Marina Staff
• Others?

07/22/2015 Ed Lethert

Electric Shock Drowning

107

In Summary

07/22/2015 Ed Lethert

Electric Shock Drowning

108

Remember:

An in-the-water shock hazard can exist wherever shore-powered AC electrical equipment is located in the water, over the water, or adjacent to the water

07/22/2015 Ed Lethert

Electric Shock Drowning

109

The Cardinal Rule:

Do not enter the water in the vicinity of shore powered watercraft

• r equipment … for any reason …

EVER! … while any nearby electrical equipment or circuits are energized!

07/22/2015 Ed Lethert

Electric Shock Drowning

110

Please Take a Brochure Take One for a Friend or Neighbor

07/22/2015 Ed Lethert

Electric Shock Drowning

111

More Information

07/22/2015 Ed Lethert

Electric Shock Drowning

112

ELECTRIC SHOCK DROWNING PREVENTION ASSOCIATION

www.electricshockdrowning.org/

07/22/2015 Ed Lethert

Electric Shock Drowning

113

Quality Marine Services, LLC

www.qualitymarineservices.net

07/22/2015 Ed Lethert

Electric Shock Drowning

114

ELECTRIC SHOCK DROWNING RESOURCE CENTER

www.boatus.com/seaworthy/ESD.asp

07/22/2015 Ed Lethert

Electric Shock Drowning

QUESTIONS ?

115

07/22/2015 Ed Lethert

Electric Shock Drowning

Thank You

116

07/22/2015 Ed Lethert

Electric Shock Drowning

Edward "Ed" Lethert

Electric Shock Drowning Safety Specialist

New Hope, MN elethert@gmail.com www.electricshockdrowningmn.com

117
