SLIDE 1
Data Visualization The Good, the Bad, the Weird
Nam Wook Kim Mini-Courses — January @ GSAS 2018
Will Start at 2:35 pm Data Visualization The Good, the Bad, the - - PowerPoint PPT Presentation
Will Start at 2:35 pm Data Visualization The Good, the Bad, the - - PowerPoint PPT Presentation
Will Start at 2:35 pm Data Visualization The Good, the Bad, the Weird Nam Wook Kim Mini-Courses January @ GSAS 2018 Goal Rules of thumbs to critique visualization design 45 Ways to Communicate Two Quantities [Santiago Ortiz 2012]
SLIDE 2
SLIDE 3
Goal
Rules of thumbs to critique visualization design
SLIDE 4
SLIDE 5
SLIDE 6
SLIDE 7
SLIDE 8
SLIDE 9
SLIDE 10
SLIDE 11
45 Ways to Communicate Two Quantities
[Santiago Ortiz 2012]
SLIDE 12
Which one is the best and why?
SLIDE 13
There are numerous ways to draw even just two numbers…
SLIDE 14
Is there an ideal way to visualize a data set?
SLIDE 15
It depends on
Data types e.g., table, network, spatial, temporal Context of the data Tasks to perform e.g., identify trends, compare values Questions to answer Messages to deliver
SLIDE 16
But, is there at least a guide for visualization design?
SLIDE 17
Edward Tufte’s Design Principles
SLIDE 18
Graphical Integrity
SLIDE 19
SLIDE 20
Flowing data
SLIDE 21
Flowing data
Bar Chart should have a zero-baseline. Because you are comparing the lengths
SLIDE 22
Flowing data
Or comparing positions from the baseline.
SLIDE 23
Do we always need a zero-baseline?
SLIDE 24
SLIDE 25
Flowing data
Line Chart may not have a zero-baseline. Because you are comparing the angle
SLIDE 26
Line chart’s aspect ratios can matter too.
https://eagereyes.org/basics/banking-45-degrees
SLIDE 27
Line chart’s aspect ratios can matter too.
A rule of thumb is banking to 45 degrees to minimize errors in visual judgments of slope ratios.
SLIDE 28
Comes down to the message you want to deliver
SLIDE 29
SLIDE 30
RANDOM QUARTER
SLIDE 31
INCORRECT Y-SCALE 2 mil 172 pixels 138 pixels 4.5 mil
SLIDE 32
15 MIL JOB LOSS? MISLEADING TITLE
SLIDE 33
The truth is…
SOURCE: Worst chart I've seen all day, Jocelyn Fong (2010)
unemployed not job loss! stabilized after 2009
SLIDE 34
what is depicted in the previous one.
SLIDE 35
SLIDE 36
Partial data
http://www.motherjones.com/kevin-drum/2012/01/lying-charts-global-warming-edition/
SLIDE 37
Show data in context
SLIDE 38
Average Annual Global Temperature (℉) 1880-2015
SLIDE 39
Choose axis scales wisely.
SLIDE 40
Tell the Truth!
The representation of numbers … should be directly proportional to the numerical quantities measured. — Edward Tufte 1983
SLIDE 41
Lie Factor
SLIDE 42
Lie Factor = Size of effect in graphic Size of effect in data
SLIDE 43
Lie Factor = Size of effect in graphic Size of effect in data Size of effect = Percentage change | V1 — V2 | = | V1 |
SLIDE 44
Year Standard MPG
SLIDE 45
This line, representing 18 miles per gallon in 1978, is 0.6 inches long
SLIDE 46
This line, representing 18 miles per gallon in 1978, is 0.6 inches long This line, representing 27.5 miles per gallon in 1985, is 5.3 inches long
SLIDE 47
This line, representing 18 miles per gallon in 1978, is 0.6 inches long This line, representing 27.5 miles per gallon in 1985, is 5.3 inches long Lie Factor = (5.3-0.6) / 0.6 (27.5-18) / 18 = 14.8
SLIDE 48
SLIDE 49
This chart uses radius of the balloon to encode the data Doubling the radius (or data) increases the perceived area by four. Lie factor = (4-1)/(2-1) = 3.
SLIDE 50
The size of the balloon should be something like this.
SLIDE 51
Avoid Distortion!
SLIDE 52
Maximize Data-Ink Ratio
SLIDE 53
Data-Ink Ratio = Data-Ink Total Ink in Graphic
SLIDE 54
SLIDE 55
SLIDE 56
SLIDE 57
Stephen Few (2011)
SLIDE 58
Avoid Chart Junks
SLIDE 59
Chart Junks = Unnecessary visual elements in charts that distracts the viewer from the information
SLIDE 60
SLIDE 61
SLIDE 62
SLIDE 63
SLIDE 64
SLIDE 65
SLIDE 66
Are these chart junks?
SLIDE 67
Not all chart junks are the same.
SLIDE 68
Useful chart junks?
Source: Useful Junk? The Effects of Visual Embellishment on Comprehension and Memorability of Charts, CHI’10.
SLIDE 69
Not harmful in comprehension but more engaging & memorable
SLIDE 70
“The same ink should often serve more than
- ne graphical purpose. A graphical element
may carry data information and also perform a design function usually left to non-data-ink.” — [Edward Tufte 83]
Replace with an aesthetic function? SLIDE 71
Haroz et al. CHI’15
Contextual representation can be helpful
SLIDE 72
Pie Charts
SLIDE 73
[Schutz 2007]
Challenge: Find the biggest pie slice in each pie chart!
Ask the second choice SLIDE 74
[Schutz 2007]
SLIDE 75
Share of Coverage by Topic on TechCrunch
[http://www.storytellingwithdata.com/blog/2011/07/death-to-pie-charts]
SLIDE 76
Share of Coverage by Topic on TechCrunch Too many slices! Too many colors! Bad color contract!
[http://www.storytellingwithdata.com/blog/2011/07/death-to-pie-charts]
SLIDE 77
SLIDE 78
SLIDE 79
?!
SLIDE 80
Math fail?!
SLIDE 81
World’s Most Accurate Pie Chart
SLIDE 82
Some rules of thumb
- You're comparing the parts to the whole.
- There's a small number of slices.
- Sort the values.
- Start at 12 o’clock.
- Use alternatives (e.g., bar chart)
Source: https://eagereyes.org/pie-charts
Pie charts are space efficient though
SLIDE 83
Rainbow Colormap
SLIDE 84
[http://factmyth.com/factoids/visible-light-is-electromagnetic-radiation/]
The rainbow color map is based
- n the order of colors in the the
visible light spectrum.
SLIDE 85
SLIDE 86
Can you say which color represents a higher or lower value group?
SLIDE 87
How The Rainbow Color Map Misleads (Kosara 2013)
Luminance Hue
Lack of perceptual ordering
SLIDE 88
Example: How many low ESS regions found?
39% 71% 10.2 sec/region 5.6 sec/region
ESS: Endothelial shear stress [M. Borkin et al 2011]
SLIDE 89
Some rules of thumb
Qualitative (rainbow) scheme — categorical data. Sequential scheme — ordered categories or numerical data Diverging scheme — numerical data with a meaningful mid-point.
[Color Brewer]
SLIDE 90
3D charts
SLIDE 91
Perspective distorts information
2D is more accurate and efficient in identifying problematic regions.
71% 91% 2.4 sec/region 5.6 sec/region
[M. Borkin et al 2011]
SLIDE 92
Perspective distorts information
SLIDE 93
Can rotate, but still no picture at once.
Occlusion hides information
SLIDE 94
Exploring and Reducing the Effects of Orientation on Text Readability in Volumetric Displays (CHI 2007)
Tilted text isnʼt legible
SLIDE 95
Depth judgment is bad
Human underestimate depth! Actual intensity change vs Perceived Sensation
SLIDE 96
External cognition vs Internal cognition
SLIDE 97
Eyes beats memory
http://www.randalolson.com/2015/08/23/small-multiples-vs-animated-gifs-for-showing-changes-in-fertility-rates-over-time/
Harder to compare visible item to memory of what you saw Animation
SLIDE 98
Use external cognition over internal cognition
Eyes beats memory
Easy to compare by moving eyes between side-by-side views Small multiples
SLIDE 99
Tufte Principles Other Considerations
- Graphical integrity
- The lie factor
- Maximize data-ink ratio
- Avoid harmful chart junk
- Pie charts
- Rainbow colormap
- 3D charts
- Eyes beats memory
SLIDE 100
Subjective Dimensions
Aesthetics: Attractive things are perceived as more useful. Style: Communicates brand, process, who the designer is. Playfulness: Encourages experimentation and exploration. Vividness: Can make a visualization more memorable.
SLIDE 101
Subjective Dimensions
Aesthetics: Attractive things are perceived as more useful. Style: Communicates brand, process, who the designer is. Playfulness: Encourages experimentation and exploration. Vividness: Can make a visualization more memorable.
Important if you want others to look at your chart!
SLIDE 102
SLIDE 103
SLIDE 104
Where is a red circle?
Graphical Perception
Next
SLIDE 105
