W e l c o m e t o t h e w o r l d o f a d a p t a b i l i t y 2 0 1 7 THE CHAMELEON! Just like the chameleon, Chameleon Lighting can adapt to its surroundings! What is Chameleon Lighting? High performance LED lighting systems From
SLIDE 2
SLIDE 3
Just like the chameleon,
Chameleon Lighting can adapt to it’s surroundings!
SLIDE 4
SLIDE 5
What is Chameleon Lighting?
- High performance LED lighting systems
♦ From 1,000 lumens to over 14,000 lumens ♦ Over 100 LPW delivered lumens in all systems ♦ Variety of beam spreads
- Variety of mounting options from the same fjxture
♦ Surface ♦ Cable ♦ Stem ♦ Wall
- Wide variety of shapes available to create a beautiful space
without compromising light output or style
- Wide variety of fjnishes
♦ Current ofgering is over 20,000 options!
- Interchangeability
- Custom capabilities
SLIDE 6
- Ability to change an existing light source’s color temperature
♦ 2200K – 6500K
- Lighting for proper circadian rhythm
- Lighting for SAD
- Lighting for healthcare, senior living and Alzheimer’s facilities
♦ Improves sleep patterns ♦ Reduces anxiety ♦ Improves cognitive skills
- Lighting for classrooms and boardrooms
♦ Cooler temperatures improve focus on detail ♦ Warmer colors reduce tension
- Lighting for multifunction spaces as well as restaurants
♦ Fast paced environments are best matched with cooler color temperatures ♦ Relaxed, subdued and romantic settings go best with warmer color temperatures
What is Color Tunable lighting, and why is it important?
SLIDE 7
P59 Series
- Up to 14,000 delivered lumens
- Down light beam spreads: 39, 64 and 90 degree
- 3000 lumen side light option to illuminate outer shade
(IL-30-P59)
- Standard 0-10V dimming for each lighting component
- 1% dimming available
- EM option available
- Full 5 year warranty
- Wide variety of styles and fjnishes
- Pre-wired with 20’ of cord (IL-30-P59 comes with 10 ft cord)
- Ability to add or change to difgerent cladding kits
(interchangeable shades) after installation
SLIDE 8
Ps Series
- Cord mounted medium base socket rated for 25 watt LED lamp*
- White, Black and Silver fjnishes available
- 10’ cord (fjeld adjustable)
- Multitude of cladding kit options. Some match P59 ofgerings
- VE option for style without high lumen package
* Lamp supplied by others
SLIDE 9
SV2 Series and WC8 Series
- 1000 lumen to over 5000 lumen packages
- Color tunable options from 2200K – 6500K
- 0-10V dimming or wireless dimming options down to 1% (WC8 has triac and 0-10V
dimming capabilities standard)
- 8” diameter to 36” diameter cladding kits
- Wall, suspended or ceiling mounting
- Damp location rated
- EM option for 3000 and 3500K fixed CCT (SV2 Series)
- 8” WC8 fjxture can be converted to take cladding kits up to 36” using adapter plates
- Three size available
♦ 6” 750 lumen package or 1,500 lumen package ♦ 14” 3,000+ lumen package ♦ 24” 5,000+ lumen package
- Color tuning option
♦ Change intensity as well as color temperature down to 1% of total light output ♦ Time clock and programming options via smartphone and smart wall control with fade rate up to 24 hours ♦ Preset levels of color temperature and light level
SLIDE 10
HMI and APP for SV2-CT series
- Change color temperature
- Change intensity from 0 -100%
- 3 HMI presets
- 3 additional App presets
- 3 time clock functions with adjustable fade rate up to 24 hours
- 5 time clock functions with immediate change
- Over 100 fjeld selectable zones
- Password protection
- Virtually unlimited number of fjxture control
- Optional 0-10V and DMX interface
SLIDE 11
Just a few of our installations!
