Speed Flexibility Efficiency Adaptability Value Proposition An [PDF]

SLIDE 1

Flexibility Efficiency Adaptability Speed

SLIDE 2

Value Proposition

An LED luminaire developed specifically for the target market – warehousing/logistics. Builds on Holophanes optical control philosophy and incorporates PrismaLED technology. Modular system that is flexible, simple and easy to install. Product that can be specified ‘up’ to incorporate unique features (rotating optic, IP65, controls and emergency).

SLIDE 3

Additional .HE option with 378 x SAMSUNG 301B LEDs using full board space for maximum efficacy. Key benefits of .HE version are:

Efficacy circa 176lm/W at 9000lms.
HE efficacy at 20,000lms – 176lm/W vs standard at 142lm/W.
Higher outputs, up to 40,000 lumens, achievable with 2 drivers in double module version.
Available in 4000K, 80CRI.

Highest Efficacy & Higher Output for all Versions

Overview of Update

Note: Higher efficacy boards cannot be used with .HI option.

New Single Module

New extrusion with improved aesthetics – Low profile, variety of cable entry options that delivers:

More competitive option.
Higher efficacy for enhanced ROI.
Adaptable and flexible mounting (electrically and mechanically)

to third party trunking.

Solution that targets applications such retail and logistics.

SLIDE 4

1 Product Variations

SLIDE 5

Product Variations – Single Module

3000 to 9000 lumens with STD boards.
3000 to 20000 lumens with HE boards.
Sealed to IP65 when configured with option code

.IP65.

Rotatable optics.
Available with emergency (up to 20k lumens).
Available with all mounting options.
3000 to 9000 lumens with STD boards.
3000 to 12000 lumens with HE boards.
Standard product with IP40 rating.
Non rotatable optics.
Available with mounting options .SUS, .TK1, .TK2.
Emergency available as separate unit (HEL.EM3).

NEW

SLIDE 6

Product Variations – IP40 Single Module

NEW

Extruded aluminium body housing driver and LED boards. Utilises existing PrismaLED optics Plastic moulded endcaps with additional knockouts for control devices. Supplied with flying lead from the top of the luminaire housing. Can be suspended or mounted to 3rd party trunking using

ption .TK1 or .TK2.

SLIDE 7

Product Variations – Double Module

12000 to 20000 lumens with STD boards.
22000 to 40000 lumens with HE boards.
Sealed to IP65 when configured with option code

.IP65.

Rotatable optics.
Available with emergency (up to 25k lmns).
Available with all mounting options.
12000 to 20000 lumens with STD boards.
15000 to 40000 lumens with HE boards.
Standard product with IP40 rating.
Non rotatable optics.
Available with emergency (up to 25k lmns).
Available with all mounting options.

NEW

SLIDE 8

Product Variations – IP40 Double Module

NEW

Existing PRS extruded aluminium gear housing. Utilises existing PrismaLED optics Rigid plastic moulded endcaps with additional knockouts for control devices. Available with all mounting options. Existing PRS extruded aluminium LED housing.

SLIDE 9

Lower Specification Version

IP40
No Rotating optics
Single optic version not available with HEL trunking.
Integrated emergency not available with single optic

version.

Available with standard and high efficacy boards

Higher Specification Version

Sealed to IP65
Rotating optics (patented)
Available as a complete solution with HEL trunking.
Integrated emergency available with single optic version.
Available with standard and high efficacy boards
Configurable using option code .IP65.

Logistics/Warehouse Luminaires

NEW NEW

SLIDE 10

2 Mounting Options

SLIDE 11

Luminaire Mounting Options

.SUS

Suspended using the kit supplied

.TK

Trunking mount for HEL trunking system

.TK1

Fully adjustable for trunking sizes 50x50mm up to 85x100mm. Only one nut & bolt to fasten horizontally in each side.

.TK2

M20 conduit & universal mount to OEM trunking brackets or hangers via Ø7mm hole

SLIDE 12

.SUS .TK .TK1 .TK2

Single IP40 Single IP65 Double IP40 Double IP65

Luminaire Mounting Options

NEW NEW

SLIDE 13

3 Emergency Options

SLIDE 14

Integrated Emergency

Self contained 1hr (.EM1) or 3hr (.EM3) maintained emergency battery and invertor (delivering c.500 lumens) available in following product configurations:

All lumen versions (L0348 to L2048)

Single IP65 Version Double IP40 Version

Available with L1248, L1548, L1848, L2048, L2248 & L2548

Double IP65 Version

Available with L1248, L1548, L1848, L2048, L2248 & L2548

SLIDE 15

Standalone Emergency

Holophane standalone self-contained, self –test, IP65 emergency unit (delivering c.350 lumens) available for all Prismaspace versions. Will require its own suspension/mounting point and power supply.

Customer Benefits: Flexibility on projects to ‘fine-tune & optimise’ the positioning of the emergency units. Standalone emergency units can be easily maintained and replaced without affecting the luminaires.

Illustration of PRS single IP40 version alongside standalone emergency unit.

SLIDE 16

Standalone Emergency Options

HEL.EM1/EM3.TK

Self contained 1 or 3 hour emergency (delivering c.350 lumens) ready to mount directly to Holophane trunking.

HEL.EM1/EM3.TK1

Self contained 1 or 3 hour emergency (delivering c.350 lumens) supplied with universal trunking mount adaptor.

HEL.EM1/EM3.SUS

Self contained 1 or 3 hour emergency (delivering c.350 lumens) supplied with 6m wire rope suspension.

HEL.EM1/EM3.TK2

Self contained 1 or 3 hour emergency (delivering c.350 lumens) supplied with universal plate with provisions for M20 conduit & 7mm hole for hanger brackets Note – All available as accessory items.

SLIDE 17

4 Controls Options

SLIDE 18

Option Code Daylight Sensor Default Setting PIR Default Setting Max Detection @ Optimal Height Max Mounting Height NOTES .PIRA YES 500 lux at sensor level YES Dims to ‘off’ when no

ccupancy after

20 minutes. 40m @ 15m mounting height 20m Default setting can be adjusted using accessory item HEL.PRO or HEL.PRO.25 .PIRN NO N/A YES Dims to ‘off’ when no

ccupancy after

20 minutes. 19m @ 10m mounting height 12m Not ‘Sensor Ready’ the H3D Controls system will ‘manage’ luminaire. Will control up to 12 drivers (master & slave). Luminaire with .PIRN is master. .WI

Integrated wireless node that can be used in conjunction with H3D. Luminaire with this option is ‘Sensor Ready’.

Integrated Controls Devices

T3 T3 T2

SLIDE 19

Accessory Code Description Max Detection @ Optimal Height Max Mounting Height Compatibility Notes HEL.PIRA PIR for 360º, aisle and end

f aisle.

40m @ 15m mounting height 20m Ready to mount on Holophane trunking and suitable for up to 20 drivers. Default setting as per .PIRA

ption. Can be changed

using PIRA.PRO or HEL.PRO.25 HEL.PIR.D4 PIR for 360º, aisle and end

f aisle.

40m @ 15m mounting height 20m Can be suspended and will control up to 10 x DALI drivers. Default setting as per .PIRA

ption. Can be changed

using PIRA.PRO or HEL.PRO.25 HEL.PRO.25 Infrared programming handset Range of up to 25m 25m Can be used to adjust setting on .PIRA, HEL.PIRA, HEL.PIR.D4 HEL.PRO Infrared programming handset Range of up to 7m 7m Can be used to adjust setting on .PIRA, HEL.PIRA, HEL.PIR.D4

Standalone Control Devices

SLIDE 20

5 Launch Plan

SLIDE 21

New high efficacy board options (.HE) and higher lumen options configurable on ENVISION & photometry released. New IP40 double version available on ENVISION (when PRS.D is selected you will automatically get the IP40 version) and photometry released. Configurable with 12 weeks lead time and deliverable in March. All controls options (.PIRN, .PIRA & .WI) available on ENVISION.
