Variable-kinematics shell model: Application to delamination analysis Aewis Hii, Luiz Kawashita, Alberto Pirrera ACCIS CDT Conference 2019 2 Introduction Methodology: Variable-kinematics models. Variable-order cohesive segment


slide-1
SLIDE 1

Variable-kinematics shell model: Application to delamination analysis

Aewis Hii, Luiz Kawashita, Alberto Pirrera ACCIS CDT Conference 2019

slide-2
SLIDE 2

Introduction

2

16th April 2019

Variable-kinematics shell model

  • Reduce model size by

selective refinements.

  • Minimal user inputs.

Goals: Methodology:

  • Variable-kinematics models.
  • Variable-order cohesive

segment method.

slide-3
SLIDE 3

Variable-kinematics shell model

16th April 2019

Variable-kinematics shell model

3

In-plane order (n) Through-thickness order (m)

Model order N,M

… … … …

Based on the Unified Formulation. Independently defined/refined in- plane and thickness kinematics.

`Tune-able’ model kinematics

slide-4
SLIDE 4

Analysis-specific model kinematics

16th April 2019

Variable-kinematics shell model

4

Twisted composite shell with variable thickness

For iterative design analyses

Modal analysis 3D Stresses

Parametric study for model kinematics

Large deformation analysis

Variable-kinematics model

  • Model settings for

iterative analyses.

  • Accurate stresses for

higher-order variants.

5 × 10 elements 10 × 20 elements 20 × 30 elements

3D stress analyses Stiffness analyses

In-plane displacement field Through-thickness displacement field

. . . . . .

𝜏33 𝜏12 𝜏23 3D-FEM

slide-5
SLIDE 5

Variable-order cohesive segment method

16th April 2019

Variable-kinematics shell model

5

No pre-defined crack path

Damaged state Elastic

2 × Nth order 2Nth order Nth order

𝐯𝑞 = 𝐯𝑢 𝜖𝐯𝑞 𝜖𝐲 ≠ 𝜖𝐯𝑢 𝜖𝐲

Features:

  • Complex crackfront geometry.
  • Low model size due to adaptive refinement.
  • Large element size.

Oscillation-free crack initiation and ‘partial cracking’ Kinematics blending/mapping

slide-6
SLIDE 6

Model size Simulation time Model size comparison

Application to delamination analysis

6

Displacement Force

Full model Adaptive model

Relaxing mesh size requirements

Regular elements Transition elements Padding elements Delamination

‘Peeling’ of a laminate with pre-crack Elements are split `on-the-fly’ Curved crack front with rectangle mesh

1st order element 3rd order element Experiment Analytical

Pure Mode I: Double Cantilever Beam

Adaptive model for complex crackfront

16th April 2019

Variable-kinematics shell model

Structural response

Full model Adaptive model

slide-7
SLIDE 7

Acknowledgements

16th April 2019

Variable-kinematics shell model

7

The authors would like to acknowledge Rolls-Royce plc for their support of this research through the Composites University Technology Centre at the University of Bristol, UK

slide-8
SLIDE 8

Thank you!
