UDT 2020 ASW using LWTs from Submarines ORUWA / Thomas Petersson 2020-02-25 COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1 ASW Using LWTs from Submarines Background ASW The

slide-1
SLIDE 1

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

UDT 2020

ORUWA / Thomas Petersson 2020-02-25

ASW using LWTs from Submarines

slide-2
SLIDE 2

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

ASW Using LWTs from Submarines

  • Background
  • ASW – The Challenge
  • ASW from Surface Units
  • ASW from Submarines
  • LWTs on Submarines
  • Current Swedish LWTs
  • Summary

2

slide-3
SLIDE 3

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Background – HWTs in Sweden

3 3

Operational

slide-4
SLIDE 4

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Background – LWTs in Sweden

4 4

Operational and New

slide-5
SLIDE 5

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Background – LWTs in Sweden

5

Surface Ship Craft of Opportunity Aircraft Submarine

slide-6
SLIDE 6

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

ASW – The Challenge

  • In blue waters:
  • Few problems exist with hydro acoustic disturbances

caused by reverberation and other sources of noise.

  • When a target is detected, the possibilities to

escape are limited.

  • A fire-and-forget torpedo can be used effectively.

The launch trajectory and the time required to enter a controlled and stable run are less critical.

  • A torpedo must be dimensioned to sustain the water

pressure when combating deep sea targets.

  • In shallow waters:
  • Reverberation from the surface and from the seabed,

and other sources of noise, are frequent.

  • Influence from sound-velocity gradients are generally

larger, meaning that significant refraction occurs.

  • A submarine can hide near or on the seabed,

in areas where seabed reverberation is high.

  • The systems must be designed for shallow waters

and a complex hydro acoustic environment.

6

X Y Z

X Y

In deep waters the distance to the target can be in the same order of magnitude as the water depth. This can be generalised into a three dimensional scenario (X-Y-Z volume). In shallow waters the combat- and detection ranges can be much greater than the depth. Here the majority of actions take place over a horizontal area. This can be generalized into a two dimensional scenario (X-Y plane).

slide-7
SLIDE 7

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

ASW – The Challenge

7

Sound Velocity

Shadow Zone

Distance from the transmitter Sound Velocity Distance from the transmitter

Baltic Sea - Winter Conditions

Distance from the transmitter Sound Velocity

Shadow Zone

Shadow Zone Sound Velocity Distance from the transmitter

Baltic Sea - Summer Conditions

slide-8
SLIDE 8

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

ASW from Surface Units

  • In Anti-Submarine Warfare (ASW) from a surface unit

there is an asymmetry between hunter and target:

  • The detection range for a Hull Mounted Sonar (HMS)
  • r a Dipping Sonar (DS) can be extremely reduced.
  • The submarine takes advantage of

hydro-acoustic shadow zones.

  • The surface units may be affected by adverse weather

conditions and hostile activities.

8

slide-9
SLIDE 9

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

ASW from Submarines

  • In Anti-Submarine Warfare (ASW) from a submarine the

asymmetry between hunter and target is reduced:

  • The detection ranges for the submarine sensors

(FAS and CAS) are comparable.

  • Both submarines can utilize hydro-acoustic shadow zones

to their advantage.

  • Both submarines operate in the same environment and are

not affected by the sea state and weather conditions.

9

slide-10
SLIDE 10

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

LWTs on Submarines – Dedicated Tubes

10

VGD Class Arrangement 6 x HWT Tubes 3 x LWT Tubes (x 2 Torpedoes) Total: 6 + 6 Torpedoes (RTF) GTD Class Arrangement 4 x HWT Tubes 2 x LWT Tubes (x 2 Torpedoes) Total: 4 + 4 Torpedoes (RTF)

slide-11
SLIDE 11

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

LWTs on Submarines – 53 cm Tubes

11

For integration of LWTs

  • n submarines equipped

with HWT tubes.

A tube insert that can be handled as a unit load is used to adapt the existing 53 cm torpedo tubes to the LWTs.

slide-12
SLIDE 12

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

LWTs on Submarines – Dedicated Tubes

12

Torpedoes are taken

  • nboard using the same

systems and methods as used for HWTs.

slide-13
SLIDE 13

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

LWTs on Submarines – Logical Integration

13

GTD Class Arrangement 4 x HWT Tubes 2 x LWT Tubes (x 2 Torpedoes) Total: 4 + 4 Torpedoes (RTF)

slide-14
SLIDE 14

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Current Swedish LWTs

14

Torpedo 45 Torpedo 47

ASW/(ASuW) ASW/(ASuW)

slide-15
SLIDE 15

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Current Swedish LWTs - Tp47 Overview

15

FLS Proximity Fuse Stator / Rotor / Duct Warhead Computer & Electronics Battery

(Lithium Iron Phosphate) Wire / Fibre Magazine

Connector Motor Servos / Rudders FLS Electronics SAI Torpedo 47 Key Features

  • Homing System Resolution
  • Communication by Wire
  • Wide Speed Range
  • Neutral Buoyancy
  • Endurance
  • Silent Run
slide-16
SLIDE 16

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

LWTs on Submarines – Benefits

  • From an operational perspective
  • Optimized solution using a submarine for ASW
  • Provides a secondary additional ASuW capability
  • Can be used as a self defence weapon
  • Evolutionary use as an Anti-Torpedo Torpedo (ATT)
  • From a logistics perspective
  • Weapon system with smaller on-board footprint
  • Increases the number of ready to fire torpedoes
  • From a design perspective:
  • Robust and can withstand higher shock-loads

16

slide-17
SLIDE 17

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Summary

  • LWTs on Swedish Submarines
  • Utilizes dedicated smaller torpedo tubes
  • Have been operational for decades
  • A Tube Insert can be used for integration
  • Can be handled as a unit load
  • Compatible with existing HWT handling systems
  • Flexible use of the fixed HWT tubes
  • Using LWTs from submarines
  • Smaller on-board footprint
  • Increased number of RTF torpedoes
  • Robust system
  • Additional self defense capability

17

slide-18
SLIDE 18

COMPANY RESTRICTED | NOT EXPORT CONTROLLED | NOT CLASSIFIED ORUWA / Thomas Petersson | Issue 1

Thank You

Thomas Petersson / ORUWA
