(Towards) Programming Models for Jungle Computing

Jason Maassen

Computer Systems Group Department of Computer Science VU University, Amsterdam, The Netherlands

Requirements

(revisited)

• Resource independence
• Transparent / easy deployment
• Middleware independence & interoperability
• Jungle-aware middleware
• Jungle-aware communication
• Robust connectivity
• System-support for malleability and fault-tolerance
• Globally unique naming
• Transparent parallelism & application-level fault-

tolerance

• Easy integration with external software
• MPI, OpenCL, CUDA, C, C++, scripts, …

ComplexHPC Spring School 2011 2

Requirements

(revisited)

• Resource independence
• Transparent / easy deployment
• Middleware independence & interoperability
• Jungle-aware middleware
• Jungle-aware communication
• Robust connectivity
• System-support for malleability and fault-tolerance
• Globally unique naming
• Transparent parallelism & application-level fault-

tolerance

• Easy integration with external software
• MPI, OpenCL, CUDA, C, C++, scripts, …

ComplexHPC Spring School 2011 3

Where are we ?

ComplexHPC Spring School 2011 4

Introduction

• We now have everything we need to create and

run Jungle computing applications

• Creating such applications is still difficult!
• IPL is communication library (not programming model)
• Applications using IPL must implement their own:
• Work distribution
• Load balancing
• Fault tolerance
• ...

ComplexHPC Spring School 2011 5

Programming Models

• RMI (Object oriented RPC)
• Client – server
• Distributed system
• MPJ (MPI for Java)
• SPMD
• Homogeneous cluster
• Joris (Image processing)
• User transparent

parallelism (sequential)

• Homogeneous cluster

ComplexHPC Spring School 2011 6

• Satin (Divide & Conquer)
• User transparent

parallelism (recursive)

• Automatic

load-balancing and fault-tolerance

• Grids (heterogeneous

performance)

Satin

Divide&Conquer

• Nicely fits hierarchical grids

ComplexHPC Spring School 2011 7

job1

job2 job3

job4 job4 job5 job6 job7

cluster1 cluster2 cluster3 cluster4 job1

job2 job3

job4 job4 job5 job6 job7

What is Missing ?

• Support for heterogeneous hardware
• Many state-of-the-art systems use accelerators
• GPUs
• Cells
• FPGA
• Huge performance gain for certain algorithms
• Fastest NVidia GPU offers 1.5 TFlop/s!
• Examples: DAS-4, CIEMAT-CIE clusters

ComplexHPC Spring School 2011 8

Problems

• Accelerators typically require specialized tools to

program them

• CUDA, OpenCL, Verilog, etc.
• These tools are designed to create applications

for a single accelerator

• Not a set of similar accelerators
• Not mix of different accelerators

ComplexHPC Spring School 2011 9

What do we need ?

• A programming model that can combine

specialized accelerator codes with all the benefits of Ibis!

• Ibis/Constellation
• Inspired by the Many Task Computing model
• Task scheduling with match-making
• Ensures that each job is send to a machine that can actually

execute it.

ComplexHPC Spring School 2011 10

Many Task Computing

According to Foster, Raicu et al “High-performance computations comprising multiple distinct activities, coupled via file system operations or message passing. Tasks may be small or large, uni- processor or multi-processor, compute-intensive or data-

• intensive. The set of tasks may be static or dynamic,

homogeneous or heterogeneous, loosely coupled or tightly coupled. The aggregate number of tasks, quantity

• f computing, and volumes of data may be extremely

large.”

ComplexHPC Spring School 2011 11

• Applications are dynamic and heterogeneous

workflows / DAGs of tasks

MTC in the Jungle

• MTC has advantages for Jungle Computing
• Many distinct activities
• Can be implemented independently using the tools

and targeted to the HPC architecture, that best suit them

• Reduced programming complexity
• Complete applications are constructed using

sequences and combinations of activities

ComplexHPC Spring School 2011 12

Constellation Model

• Application: set of activities
• Loosly coupled (communicate using events)
• Size and complexity may vary
• Sub-second sequential jobs to large parallel

simulations that take hours

• Hardware: set of executors
• Capable of running activities
• May represent anything from a single core to

entire cluster, a GPU, etc.

ComplexHPC Spring School 2011 13

Constellation Model

• Both activities and executors can be tagged

using a context

• Simple application defined label
• Defines relationship between activites and executors
• Data dependencies
• Hardware requirements and capabilities
• Data and resource sizes
• ...
• Constellation RTS performs match-making

and load-balancing

ComplexHPC Spring School 2011 14

Constellation Example

ComplexHPC Spring School 2011 15

Early Experiments

• Supernova detection application
• Our winning entry in the 2008 Data Challenge
• Originally IPL + JavaGAT
• Ported to Constellation
• Analyse 1052 image pairs
• Varying resolution
• Test Constellation in

3 different scenarios

ComplexHPC Spring School 2011 16

Scenario 1

Data Locality

• Data distributed over

4 clusters (DAS3/4)

• Activity: entire application
• Executor: complete node
• Use context to express

data locality

• Locality aware task farming
• No change in application!
• Use constellation wrapper
• Adapt context to tune application

ComplexHPC Spring School 2011 17

Scenario 2

Executor Granularity

• Single 48 core machine
• Activity: entire application (a-c)

single task (d)

• Executor: [n]-cores
• No change in application

for experiment (a-c)

• Only change executor config.
• Completely ported

application in (d)

• Significant performance gain!

ComplexHPC Spring School 2011 18

Scenario 3:

Heterogeneous System

• 18 node GPU cluster
• 8 cores + 1 GPU per node
• Activity: single task
• Executor: 1 core (top)

1 core or 1 GPU (bottom)

• Replaced activity 7.2

with GPU version.

• Label activities and

executors accordingly

• Constellation takes care
• f rest!
• Significant performance gain.

ComplexHPC Spring School 2011 19

Conclusions

• Initial experiments show that Constellation works

well for a wide range of hardware configurations

• Allows integration of specialized accellerator codes
• Easy to extend and reconfigure applications
• Suitable basis for a Jungle Computing model

ComplexHPC Spring School 2011 20

Future Work

• More applications on wider range of hardware
• Integration of executor deployment into model
• Implement on top of Constellation:
• Domain specific languages
• Phyxis-DT (successor of Joris)
• User-friendly workflow models
• Existing programming models
• Satin

ComplexHPC Spring School 2011 21
