SLIDE 1
SEPTEMBER 5 - 7, 2018
1
Todd Maersch Consultant Transmission Line Engineer American Transmission Co.
SEPTEMBER 5 - 7, 2018
2
Todd Maersch Consultant Transmission Line Engineer American - - PowerPoint PPT Presentation
Todd Maersch Consultant Transmission Line Engineer American - - PowerPoint PPT Presentation
Todd Maersch Consultant Transmission Line Engineer American Transmission Co. SEPTEMBER 5 - 7, 2018 1 Traditional Methods for Foundation Installation Traditional Vibratory Direct Bury SEPTEMBER 5 - 7, 2018 2 SEPTEMBER 5 - 7, 2018 3
SLIDE 2
SLIDE 3
SEPTEMBER 5 - 7, 2018
3
SLIDE 4
SEPTEMBER 5 - 7, 2018
4
Driving Innovation: How it Works
SLIDE 5
SEPTEMBER 5 - 7, 2018
5
Driving Innovation: How it Works
SLIDE 6
SEPTEMBER 5 - 7, 2018
6
Driving Innovation: How it Works
SLIDE 7
SEPTEMBER 5 - 7, 2018
7
Driving Innovation: Why it Works
- Less equipment
needed
- Drastically reduces set
up times
- Only two to three crew
members required
- Safety, environmental,
landowner, and cost benefits
SLIDE 8
SEPTEMBER 5 - 7, 2018
8
Direct Bury Traditional Vibratory Installation Solo-Driver™ Method Equipment Required
- Large digger
derrick
- Crane
- Dump truck
- Two cranes
- Flatbed truck
- Power pack
- Taglines
- One excavator
Crew Size 5 5 2-3 Overhead clearance 60-80 ft. 60-80 ft. 30-40 ft. Total Installation Time 150 minutes/structure 4 installations/day 75 minutes/caisson 8 installations/day 25 minutes/caisson 18 installations/day
Driving Innovation: Why it Works
SLIDE 9
SEPTEMBER 5 - 7, 2018
9
Driving Results: Improved Safety
- Hammer safety
interlock
- No foundations
suspended overhead
- No heavy umbilical
cables to lift and maneuver
SLIDE 10
SEPTEMBER 5 - 7, 2018
10 10
Driving Results: Environmental Stewardship
- Lighter Equipment – significantly reduced environmental
impact
- No spoils to remove
- No soil mixing
- No dewatering
- Minimal restoration
SLIDE 11
SEPTEMBER 5 - 7, 2018
11 11
Driving Results: Landowner Acceptance
- Return land to owner
faster
- Less soil compaction
- Minimal impact to
agriculture operations
- Less noise disturbance
SLIDE 12
SEPTEMBER 5 - 7, 2018
12 12
Driving Results: Costs
- Initial indications show Solo-Driver is poised to cut costs
significantly compared to traditional installation methods
– Reduced equipment costs – Reduced labor costs – Reduced project risk dollars due to smaller construction window
SLIDE 13
SEPTEMBER 5 - 7, 2018
13 13
Driving Results: Soil Type and Access
- Solo-Driver is more efficient than other methods, even when
navigating challenges that can slow any foundation installation project
– SOIL TYPE
- FAVORABLE: Sandy or loose soil 18-23 per day
- LESS FAVORABLE: Higher clay content 6-8 per day
- UNFAVORABLE: Rocks and cobbles
– ACCESS
- One unloading/reloading 15-23 per day
- Multiple unloadings/reloadings 7-9 per day
SLIDE 14
SEPTEMBER 5 - 7, 2018
14 14
- Began in 2001 as first multi-
state transmission only utility in U.S.
- $4.7B in assets
– 9,600 miles of transmission lines – 554 substations
- Committed to excellence and
innovation
Driving Excellence: About ATC
SLIDE 15
SEPTEMBER 5 - 7, 2018
15 15
atcllc.com/solo-driver
Driving Excellence
SLIDE 16
SEPTEMBER 5 - 7, 2018
16 16
