Titan Blue™ Grease

Technology for Extreme Lubrication Environments

• Micro Technology

–

Pressure activated tiny microencapsulated particles deliver a protective barrier preventing metal to metal contact. “Its there if you need it”

–

Superior to moly and graphite

• Exceptional friction reducer/heat dissipater
• Remarkable protection against the most extreme loads
• Exceptional corrosion protection- even in saltwater!
• Lithium Sulfonate complex thickener system

–

All the pumpability and compatibility of a Lithium and the extreme corrosion protection of a Sulfonate in one grease

–

Compatible with most all Lithium based greases

• Maintains pumpability and film strength at the same time
• Less wear, lower friction and longer life for your equipment

Titan Blue™ With Micro Technology

Titan Blue™ Micro Encapsulated Particles Deliver 1000 cSt Performance

220 cSt base

• il common

in greases 1000 cSt microencapsulated

• il separates metal

surfaces far better EP Additives work here by forming a sacrificial metal layer- controlled wear

Coefficient of Friction- Titan Blue™ μk – .025 Ice on ice μk – .03

Titan Blue™ Slicker Than Ice!

Coefficients of Friction Digital Block-on-Ring, ASTM D2509 Modified Low Speed/High Load

TitanBlue ™ Reduces Friction by 50% or more!

Friction Control Significantly Lowers Operating Temperatures

Titan Blue™

Moderate Load Test- Load Wear Index, Four Ball Method

56.7 79.7 53.8 80.4 55.8 156.2 50 100 150 LWI Axis Title Valvoline Cobalt Competitor E Competitor D Competior C Competitor B Competitor A

HIGHER IS BETTER GCLB .

Titan Blue™ reduces wear by up to 50% at moderate loads

Titan Blue™

Comp B Comp C Comp D Comp E Comp A Extreme Wear Protection/Friction Reduction, Line Contact Block-on-Ring, ASTM D2509 Modified Low Speed/High Load

High Load Test- Extreme Pressure Performance

Titan Blue™

EHL- Load Wear Scars (200kg/1770rpm/10 sec) (3.2x magnification)

B 1.474 mm D 1.256 m mm A 1.626 m mm C 2.374 m mm E 2.026 m mm

1.087 087 mm

Reduces wear by 20-50% compared to leading competitors

Titan Blue™

Corrosion Prevention, 100% Synthetic Seawater ASTM D5969

Titan Blue™

Road Salt!!!

• Micro Technology

–

Pressure activated tiny microencapsulated particles deliver a protective barrier preventing metal to metal contact. “Its there if you need it”

–

Superior to moly and graphite

• Exceptional friction reducer/heat dissipater
• Remarkable protection against the most extreme loads
• Exceptional corrosion protection- even in saltwater!
• Lithium Sulfonate complex thickener system

–

All the pumpability and compatibility of a Lithium and the extreme corrosion protection of a Sulfonate in one grease

–

Compatible with most all Lithium based greases

• Maintains pumpability and film strength at the same time
• Less wear, lower friction and longer life for your equipment

Titan Blue™ With Micro Technology

Titan Blue™
