THINC: A Virtual Display Architecture for Thin-Client Computing Ricardo A. Baratto, Leonard N. Kim, Jason Nieh Network Computing Laboratory Columbia University isolation... ...connectivity Source: Internet Mapping Project
SLIDE 2
SLIDE 3
Source: Internet Mapping Project (http://research.lumeta.com/ches/map/)
...connectivity
SLIDE 4
dis-integration of the computer
network storage clusters and grid computing
SLIDE 5
remote display
display updates input
SLIDE 6
benefits
SLIDE 7
ubiquitous access
SLIDE 8
remote collaboration
SLIDE 9
- nline help
SLIDE 10
stateless client application processing and data secure server room
thin clients
SLIDE 11
existing systems
SLIDE 12
existing performance problem
0% 20% 40% 60% 80% 100% PC ICA RDP GoToMyPC X NX VNC Sun Ray
audio/video quality
LAN WAN
SLIDE 13
THINC
SLIDE 14
virtual display architecture high performance remote display transparent operation
SLIDE 15
- system architecture
- display protocol
- translation
- delivery
SLIDE 16
system architecture
SLIDE 17
applications window system device driver framebuffer
SLIDE 18
applications window system device driver framebuffer
high-level requests
interception and redirection
✗ stateful client hurts
mobility
✗ app – window system
synchronization
SLIDE 19
applications window system framebuffer device driver
raw pixels high-level requests
interception and redirection
✗ lose semantics:
difficult to encode
SLIDE 20
applications window system virtual device driver
display updates input events
virtual display architecture
SLIDE 21
Standard Interface
applications window system virtual device driver
benefits
SLIDE 22
Leverage existing technology
applications window system virtual device driver
benefits
SLIDE 23
virtual device driver
display updates
Simple, low-level protocol
benefits
SLIDE 24
virtual device driver
display updates input events
Simple, stateless client
benefits
SLIDE 25
display protocol
Inspired by Sun Ray protocol 2D Primitives
- copy
- solid and tile fill
- bitmap fill
- raw
Video
SLIDE 26
two key problems
how do we translate from application commands to the display protocol? how and when do we send display updates?
SLIDE 27
translation
use and preserve semantic information for efficient translation
SLIDE 28
- use semantic information when
doing translation
translation
SLIDE 29
use request semantics to generate update
req: fill window W, color C
application window system
req: fill [x,y,w,h] color C
THINC
update: solid fill [x,y,w,h] color C
SLIDE 30
✔use semantic information when
doing translation
- preserve semantic information
throughout the system
translation
SLIDE 31
preserving semantics:
- ffscreen rendering
draw
- ffscreen regions
abcde
copy
abcde
display
SLIDE 32
- ffscreen rendering (cont)
- ffscreen region
command log merge, clip, and discard commands as needed
SLIDE 33
using and preserving semantics: video
- reuse existing hardware acceleration
application interfaces
- YUV (luminance-chrominance) color
space
– format independence – client hardware acceleration (scaling
for free)
SLIDE 34
delivery
maximize interactive response of the system
SLIDE 35
delivery
- transmit updates as soon as possible
- merge, clip, and discard updates as
needed
SLIDE 36
shortest remaining size first scheduler
client buffer C1 C2 C3 ... Cn real time . . . queue 1 queue p cmd size
SLIDE 37
implementation
- X/Linux server
– ongoing: windows server
- X/Linux, windows, PDA, Java clients
SLIDE 38
experimental results
- web and video performance
– comparison to existing systems – Internet 2 sites around the globe
SLIDE 39
“ ”
LAN WAN 802.11g
SLIDE 40
web browsing performance
0.5 1 1.5 2 2.5 3 PC ICA RDP GoToMyPC X NX VNC Sun Ray THINC
per web page latency (s)
Desktop LAN Desktop WAN 802.11g PDA
SLIDE 41
a/v playback quality
0% 20% 40% 60% 80% 100% PC ICA RDP GoToMyPC X NX VNC Sun Ray THINC
audio/video quality
Desktop LAN Desktop WAN 802.11g PDA
SLIDE 42
NY MA PA MN NM CA
SLIDE 43
CA IE FI KR PR
SLIDE 44
Internet2 web browsing performance
0.5 1 1.5 2 ny pa ma mn nm ca can pr ie fi kr location page latency (s)
SLIDE 45
Internet2 a/v playback quality
0% 20% 40% 60% 80% 100% ny pa ma mn nm ca can pr ie fi kr location playback quality
SLIDE 46
demo
SLIDE 47
conclusions
THINC:
- virtual display architecture transparently
leverages existing display infrastructure
- efficient translation by using and preserving
semantic information from display request
- delivery mechanisms increase
responsiveness of the system
