The FOG generator range

Why FOGGY?

• When regular alarm system are not sufficient:

– Recidivist theft, robbery or aggression

• Clients that have been victims 2 or 3 consecutive times

– Remote places – Small or/and elevated value of the goods

• diamonds, perfume, gold
• glasses, electronics, computers, mobile phones

FOGGY : business opportunity

• High margin sales
• Impulsive and immediate purchase

– immediate need purchase

• Demonstration to make to final clients
• Protection definitive formula
• New solution by innovative product
• Subsidary

– For tobacco shops

• 7 min  robbery lasting time
• … compared to private police

intervention time :  15 min

• 2nd robbery probabilities > 1st

robbery probabilities

• 3rd robbery probabilities > 2nd

robbery probabilities

• A regular alarm system doesn’t

stop the intruders

• The sirens and the phone calls

do not physically stop the intruders

Why wasn’t it working first?

FOGGY : how is that working

• FOGGY fills up:

– 100 m3, 200…. 600…. –  Up to 1600 m3 in few seconds

• With a completely harmless fog
• The fog is safe
• Its density doesn’t allow the
• rientation thanks to the view
• The intruder is not able to continue its

approach

• It just can escape

FOGGY : the markets

• Jewelers
• Perfume shops
• Tobacco shops
• Glass shops
• Individual remote houses
• High value goods warehouse
• Banks, exchange shops
• Rooms presenting high value goods

(painting)

• Car parks / garage
• ….

FOGGY : it works

• Fog lasts for 20 to 30 min

when doors and windows are open

• Private police has enough

time to arrive

• Intruders are in an

uncomfortable position

FOGGY : consequences…

• NONE!!!!

►Gas is absolutely safe

• For pets
• For person (except mother in law)

►Gas that leaves no dust

• Solution that fits all situation

• A tank contains the liquid:
• Normal temperature
• Airless keeps liquid

characteristics

• In case of alarm:
• It is drained and breezes in the

300° heater

• The high temperature changes

it directly in gas

FOGGY : the functioning

FOGGY : performances

Working time Filled volume 10’’ 100 m3 20 ‘’ 200 m3 40 ‘’ 400 m3 60 ‘’ 600 m3 Up to 1600 m3

FOGGY : capacities

Back up battery for 60 min autonomy

Working time Numbers of runs with the 1,3 liters tank 20 seconds 35 times 60 seconds 11 times

FOGGY : installation

• With a regular control panel:

– With one or 2 inputs

• Without control panel :

– With a direct panic button – With a simple remote control

FOGGY : the board

USB port GSM plugin Information LEDS Local display Programming Dip-switches Inputs/outputs

FOGGY : inputs/outputs

• Inputs:

– System arming

• Follow control panel arming/unarming  blocks/unblocks FOGGY

– Primary alarm

• Control panel general alarm  FOGGY prealarm

– Secondary alarm

• Stand alone sensor alarm / Panic button fog run

– Total block  no emission – Fire system block no emission except tamper

• Outputs:

– Running – Tamper – Liquid level – Technical problems

• No power . Battery level – battery problem – pump problem -. Board Temperature – board Temperature

FOGGY : programming

• dip-switches
• computer

– USB – GSM

FOGGY : manutention

• Easy tank change
• 2 liquid level alerts when on reserve
• Numerous technical information by outputs

and on display :

– Heater and board temperature….

• USB port :

– Programming – Information – Firmware update

• Optional GSM for SMS information

FOGGY 30

• FOGGY 30 (White, Grey, Anthracite)
• Tank Volume : 1 liter
• Initial warming consumption: 600 Watt
• Consumption in rest mode: 60 W – 120 W
• Warming time : 12 min
• Warming time after shot: 3 minutes max
• Dimensions (mm) : 358 x 264 x 166
• Weight : 16 kg

Time of activation Filled Volume 10’’ 100m3 20’’ 200m3 30’’ 300m3 30’’ + pulsed mode: Up to 1300m3 Expulsion time expulsion/refill Nb 10’’ 50 30’’ 16

FOGGY 50

• FOGGY 50 (White, Grey, Anthracite)
• Tank Volume : 1,3 liter
• Initial warming consumption:1000 Watt
• Consumption in rest mode: 60 W – 200 W
• Warming time: 20 minutes
• Warming time after shot: 5 min max
• Dimensions (mm) : 480 x 353 x 166
• Weight : 22 kg

Expulsion time expulsion/refill Nb 20’’ 35 60’’ 11 Time of activation Filled Volume 20’’ 200m3 40’’ 400m3 60’’ 600m3 60’’ + pulsed mode: Up to 1600m3

FOGGY : optionnals

• Nozzles:

– 10 cm extension  false ceiling PRL10 – 3 nozzles for different spray direction

FOGGY : optionnals

• Multi-installation mounting kit

– Weight from 22 kg  4 kg

• Demo trolley:

– One FOGGY – One trolley with wheels – One remote control

• Remote control Bip

– Arming – Disarming – Starting – stopping

FOGGY : « the plus »

• Large tank long autonomy
• Reduce consumption
• Wall and ceiling mounting
• Airless and normal temperature tank
• USB port
• Remote control wireless receiver integrated
• RS485 integrated port  XTREAM direct connection
• Integrated GSM plug in / optional GSM board
• 3 years complete and non conditional warranty
• Immediate worldwide damage insurance
• EN50131-8 norm

– Conform

• see now instruction manual

– Certified : EN50131-8 certification phase

• generator EN50131 certified
• VdS : certification phase

–

• nly worldwide fog generator VdS certified
• 100% Italian product

FOGGY : tobacco shops

• FOGGY is conform to EN50131-8
• tobacco shops consider FOGGY as the better

prevention system against robbery

• tobacco shops can pretend for subsidiaries for

FOGGY installation.

Ideas

• Monitoring stations:

– FOGGY leasing solution

• Easy to determine the right clients
• Distributors:

– FOGGY DEMO lending for demo to final client

The confidence
