FOG; COMPOSITING

OUTLINE

2

• Fog
• Compositing
• Blending
• Transparency
• Clipping
• 3D Textures
• Noise

FOG

• Atmospheric haze
• Provides more realism in a scene
• Also provides more sense of scene depth
• Simple (and effective) approach is to blend fog color with pixel color dependent on depth
• Can be done in the fragment shader

FRAGMENT SHADER

#version 430 in vec3 vertEyeSpacePos; in vec2 tc;

• ut vec4 fragColor;

uniform mat4 mv_matrix; uniform mat4 proj_matrix; layout (binding=0) uniform sampler2D t; // for texture layout (binding=1) uniform sampler2D h; // for height map void main(void) { vec4 fogColor = vec4(0.7, 0.8, 0.9, 1.0); // bluish gray float fogStart = 0.2; float fogEnd = 0.8; // the distance from the camera to the vertex in eye space is simply the length of a // vector to that vertex, because the camera is at (0,0,0) in eye space. float dist = length(vertEyeSpacePos.xyz); float fogFactor = clamp(((fogEnd-dist)/(fogEnd-fogStart)), 0.0, 1.0); fragColor = mix(fogColor,(texture(t,tc)),fogFactor); }

FOG RESULT

COMPOSITING

COMPOSITING

• Pixel operations use the z-buffer
• Until now, we only used this to determine which fragments were visible or not
• Depth buffer – hidden surface removal
• But we can do more than this
• First, color vectors (vec4) have the alpha component
• alpha = 1, totally opaque
• alpha = 0, totally transparent
• Second, we can use glBlendEquation() and glBlendFunc() to specify how to treat
• verlapping pixels
• This has to be done in the Java/JOGL code – this step is not programmable

COMPOSITING

• How it works:
• Source and destination pixels are multiplied by the source and destination factors

specified to glBlendFunc(src, dest)

• The operation specified in glBlendEquation is used to combine the source and

destination pixels

• Also use glEnable(GL_BLEND) OR glDisable(GL_BLEND)
• Tables for these constants are in the next slides
• Default are GL_ONE for source, GL_ZERO for destination
• Default operation is GL_BLEND

GLBLENDFUNC() PARAMETERS

GLBLENDEQUATION() PARAMETERS

Constant Operation GL_FUNC_ADD result = source + destination GL_FUNC_SUBTRACT result = source – destination GL_FUNC_REVERSE_SUBTRACT result = destination – source GL_MIN result = min(source, destination) GL_MAX result = max(source, destination)

TRANSPARENCY

• Picture on left has alpha = 1 in pyramid
• Picture on right has alpha = 0.8 in pyramid
• Sufficient for flat transparent objects, but maybe not for 3D objects

TRANSPARENCY

• Just disabling back face culling doesn’t have the effect we really want
• Artifacts occur based on the order of rendering
• One simple approach is to render non-transparent objects first, but that doesn’t fix

this particular situation

• In this case, a two pass approach in rendering first front faces and then back faces works
• Need to flip normal vectors for lighting to appear correct on back faces

USER DEFINED CLIPPING PLANES

• You may want to slice an object at some point (who wouldn’t?)
• Can define a clipping plane with the equation:
• ax + by + cz + d = 0
• (a, b, c) is the normal to the plan
• d defines its distance from the origin
• Can use the “built-in” GLSL variable gl_clip_distance[ ] in the vertex shader
• e.g.: gl_clip_distance[0] = dot(clip_plane.xyz, vertPos) + clip_plane.w
• … assuming you have defined clip_plane to hold your (a, b, c, d) values

THE RESULT

• Making macaroni from a torus…
• Not ideal – inside faces are not drawn

RESULT OF A TWO PASS PROCESS

• Now back faces are shown as well
• As before, winding order needs to be reversed, and normals need to be flipped so

that lighting works correctly

3D TEXTURES

• Unlike 2D textures, these are usually generated procedurally
• Can conceptualize this as an object being carved out of a 3D block of material

CODE TO GENERATE STRIPE

void generate3Dpattern() { for (int x=0; x<texHeight; x++) { for (int y=0; y<texWidth; y++) { for (int z=0; z<texDepth; z++) { if ((y/10)%2 == 0) tex3Dpattern[x][y][z] = 0.0; else tex3Dpattern[x][y][z] = 1.0; } } } }

CAN APPLY THIS TO ANY OBJECT

CODE TO GENERATE CHECKERBOARD

CHECKERBOARD DRAGON

NOISE

• Many natural materials can be modeled with various noise patterns
• Construct your 3D pattern with random numbers
• You can then fill an array with the noise and a function to create different patterns

NOISE

• Same “granite” cube as before, but with different levels of resolution

SMOOTHED NOISY PATTERNS

• Again, same “granite” pattern with smoothed noise – based on texel distance from each
• ther, shown at different resolutions

TURBULENCE

• Combining smoothed levels to create a more random looking “turbulent” pattern

MARBLE PATTERN

• Start with stripe pattern – this starts out diagonal
• Sine function produce the blurry edges
• Add varying level of noise to perturb the stripes
• Can include lighting to make it look realistic

“MARBLE” STANFORD DRAGON

“WOOD” 3D TEXTURE

• Start with striped texture, but arranged in rings
• Can both perturb the stripes, as with marble, and “rotate” the texel coordinates a bit for

more enhancement

“WOOD” DOLPHIN

“CLOUDS”

• Use the turbulence map from the cube we looked at previously
• Change the color
• Stretch it to fit the half sphere
• Voila – looks like clouds

MODIFIED TURBULENCE

• By adding a logistic / sigmoid function to the texture, can get clouds with more distinct

boundaries

DRIFTING CLOUDS – AND SLIGHT CHANGE

• Make the z variable of the texture change gradually over time

SPECIAL EFFECTS

• Dissolve effect
• Command in the GLSL language – discard

void main(void) { float noise = texture(s,originalPosition/2.0+.5).x; if (noise > t) { fragColor = texture(e,tc); } else { discard; } }

SUMMARY

33

• Fog
• Compositing
• Blending
• Transparency
• Clipping
• 3D Textures
• Noise
