The Cosmic Microwave Background as a Probe of the Early Universe and Novel Physics

David Spergel Philadelphia March 16, 2012

Friday, March 16, 2012

Overview

What can we measure? Past Present Future

Friday, March 16, 2012

Measuring the Initial Conditions: Simple Version

Friday, March 16, 2012

Complexities

Friday, March 16, 2012

What do we want to measure?

Initial conditions produced during the first moments of the universe Scalar, (Vector), and Tensor fluctuations Power spectrum Non-Gaussian features (bispectrum to bubble collisions)

Friday, March 16, 2012

WMAP Spacecraft

MAP990422

thermally isolated instrument cylinder secondary reflectors focal plane assembly feed horns back to back Gregorian optics, 1.4 x 1.6 m primaries upper omni antenna line of sight deployed solar array w/ web shielding medium gain antennae passive thermal radiator warm spacecraft with:

• instrument electronics
• attitude control/propulsion
• command/data handling
• battery and power control

60K 90K

300K

Friday, March 16, 2012

W - 94GHz

Friday, March 16, 2012

Friday, March 16, 2012

FOREGROUND CORRECTED MAP

Friday, March 16, 2012

FOREGROUND CORRECTED MAP

Friday, March 16, 2012

FOREGROUND CORRECTED MAP

Friday, March 16, 2012

What Have We Learned?

 Simple model fits a wide

range of data (only 5 numbers)

 Age of universe:13.7 Gyr  Composition:

 Atoms: 4%  Matter: 23%  Dark Energy: 73%

 Scale Invariant

Fluctuations seed growth

• f galaxies

 First Stars formed ~200

Myr after the big bang

With WMAP7, we have narrowed the constraints on the six-dimensional parameter space by 30,000 from pre-WMAP CMB

Friday, March 16, 2012

Today’ s Universe (Sloan Digital Sky Survey)

Friday, March 16, 2012

THlozek et all. 2011

Friday, March 16, 2012

All of the pieces seem to fit….

 Supernova distances  Hubble Constant  Age of Universe  Cluster Properties  Gravitational Lenses  Nuclear Abundances  Lyman alpha forest  Galaxy Velocities

Friday, March 16, 2012

The Universe is Simple?

 Fluctuations are accurately as Gaussian, Random Phase  No evidence for spatial variations in fluctuation properties  No evidence for interaction terms  No sign of global topology

Friday, March 16, 2012

ACT

Led by Lyman Page. Devlin (Penn) leads much of the instrumental effort. 80 scientists on 5 continents 6-meter telescope on Cerro Tocco (5190 m) in the Atacama Desert. Observing the sky at 148, 218 and 277 Ghz

Friday, March 16, 2012

Sudeep Das for the ACT collaboration

/SPT

ACT and SPT probe smaller scales

Friday, March 16, 2012

Friday, March 16, 2012

Improving Detectors

ACT: Observed 2008-2010; Analysis Underway ACTPOL: First light in May 2012. Survey starts in July 2012. Wide (6000 sq deg) + Deep (150 sq deg) surveys Advanced ACTPOL: Proposed next generation detectors

Friday, March 16, 2012

ACT 148 GHz map

Radio Source Cluster Incomplete Sky Coverage Data released on lambda.gsfc.nasa.gov soon 3% of data 5 degrees

Friday, March 16, 2012

NGC 1055

Friday, March 16, 2012

IRAS ACT 220 GHz

Friday, March 16, 2012

ACT Sky Coverage

2008 ACT Stripe from Marriage et al. (2011)

2009+2010

Friday, March 16, 2012

ACT Sky Coverage

2008 ACT Stripe from Marriage et al. (2011)

2009+2010

El Gordo

Friday, March 16, 2012

Seven or more acoustic peaks

Dunkley et al. 2011

Friday, March 16, 2012

Early universe physics

Dunkley et al. 2011

Neutrinos: More species, longer radiation domination, changes equality redshift, suppress early acoustic oscillations and adds phase shift. SPT+WMAP: N=3.86 ± 0.42 Helium: Usually assume YP=0.24, predicted by BBN More helium decreases electron density, increasing damping. Yp= 0.30 ± 0.03 (SPT+WMAP). ρrel = 7 8 4 11 ⎛ ⎝ ⎜ ⎞ ⎠ ⎟

4 /3

Neff ⎡ ⎣ ⎢ ⎤ ⎦ ⎥ ργ

Friday, March 16, 2012

Clusters as Cosmological Probes

SZ signal measures integrated pressure in cluster SZ signal is redshift- independent, so an SZ- selected cluster sample should be a mass-selected sample. Potentially, number counts could be an important dark energy probe. Key step: lensing calibration Subaru Image: Takada, Miyatake, et al.

Friday, March 16, 2012

Clusters

Measurements of N(M,z) have the potential to probe the growth rate of structure and detect non-Gaussianiaties Challenge is to convert observable to mass and be sure that it doesn’ t evolve with redshift. Eddington bias: most massive clusters are likely lower mass objects with large observational

• scatter. (Need to know the error distribution

in the 2-sigma tail)

Friday, March 16, 2012

“El Gordo”

 Detected ¡in ¡2008 ¡ACT ¡maps ¡of ¡ Southern ¡Strip ¡(Menanteau ¡et ¡al. ¡2010, ¡ Marriage ¡et ¡al. ¡2011)

• Strongest ¡SZ ¡decrement ¡over ¡755 ¡

deg2 ¡(South ¡+ ¡Equator) ¡  OpIcal ¡follow-­‑up: ¡89 redshifts!

• Imaged ¡(griz) ¡at ¡SOAR/SOI ¡
• VLT/FORS2

 Chandra X-ray Observations

• ACIS-I, 60 ks
• Spitzer IRAC warm-phase

follow-up

• Imaged ¡at ¡3.6 ¡µm ¡and ¡4.5 ¡µm

Friday, March 16, 2012

A Remarkable Bullet-like Cluster at z~0.87

“El Gordo”

Menanteau et al. (2011, arXiv:1109.0953)

Friday, March 16, 2012

A Remarkable Bullet-like Cluster at z~0.87

“El Gordo”

Menanteau et al. (2011, arXiv:1109.0953)

Friday, March 16, 2012

A Remarkable Bullet-like Cluster at z~0.87

“El Gordo”

Menanteau et al. (2011, arXiv:1109.0953)

Friday, March 16, 2012

A Remarkable Bullet-like Cluster at z~0.87

“El Gordo”

Menanteau et al. (2011, arXiv:1109.0953)

Friday, March 16, 2012

A Remarkable Bullet-like Cluster at z~0.87

“El Gordo”

Menanteau et al. (2011, arXiv:1109.0953)

Friday, March 16, 2012

“El Gordo” is Hot and Luminous!!

Core-excised Integrated spectrum

Compared with Markevitch et al. (1998)

kT = 14.5 ± 0.1 keV LX = 2.19 × 1045 erg s−1 Lbol = 1.36 × 1046 erg s−1

Friday, March 16, 2012

“El Gordo,” Chandra Imaging

Friday, March 16, 2012

“El Gordo,” Chandra Imaging

Wake! Cometary shape (even 2 tails!) 20-40% surface brightness suppression ≈35”x60”

Friday, March 16, 2012

“El Gordo,” Chandra Imaging

Wake! Cometary shape (even 2 tails!) 20-40% surface brightness suppression ≈35”x60”

Low entropy, bright,

• ffset peak

Friday, March 16, 2012

“El Gordo,” Chandra Imaging

Wake! Cometary shape (even 2 tails!) 20-40% surface brightness suppression ≈35”x60”

Low entropy, bright,

• ffset peak

Steep brightness gradient

β model profile

Friday, March 16, 2012

Rarity of ACT-CL J0102-4915 - Based

• n its exceptional mass
• Area of survey:

M200 = (2.16 ± 0.32) × 1015 h−1

70 M⊙

• Combined Mass from optical

+X-ray+SZ:

• Mortonson et al. (2011)

exclusion curves for ΛCDM and quintenssence parameter distribution.

• Cluster is unlikely in the ACT survey area alone (3σ), but is not a

highly unlikely occurrence in the ACT+SPT sky region if its mass is 1- σ or more below the nominal mass. No tension with ΛCDM, since the cluster is not unexpected in the entire sky. ACT: 755 deg2 ACT+SPT: 2800 deg2

Falsify ΛCDM All Sky

L i k e l y Unlikely

Friday, March 16, 2012

Intervening large-scale potentials deflect CMB photons and distorts the CMB. The rms deflection is about 2.7 arcmins, but the deflections are coherent on degree scales.

Gravitational Lensing of the CMB

Friday, March 16, 2012

ACT Lensing Detection

Lensing deflects photons and produce non-Gaussian signal: Non-trivial 4-pt function Lensing power spectrum is a meausure of the amplitude of fluctuations along the line of sign

Das et al. arXiv 1103.0419

Friday, March 16, 2012

Direct Detection of Dark Energy from the CMB

Friday, March 16, 2012

This is just the beginning of CMB Lensing Studies

Planck ACTPOL

Friday, March 16, 2012

E + B modes

Scalar fluctuations generate E-modes. They produce TT, TE and EE correlations Tensor fluctuations generate equal amounts of E and B

• modes. They produce TT, EE

and BB correlations Gravitational lensing rotate polarization and converts E modes into B modes.

Figure from Dodelson et al. NAS White Paper astro-ph/0902.3796

Friday, March 16, 2012

Next Step: ACTPOL

Funded by NSF for 2011-2016 Camera now under construction... 25 times faster survey speed and polarization sensitivity First light in 2012 Wide survey (~4000 sq. degrees) Deep survey (5 x 25 sq degree fields)

Friday, March 16, 2012

Why Measure High l Polarization?

More modes/more sky coverage leads to more accurate parameters. New discovery space (another e-fold of inflation) Sensitive to ionization history New Lens sheet: BB power spectrum (directly related to the convergence power spectrum) has a signal/noise of 3000 in an all-sky 0.1 uK2

Friday, March 16, 2012

Friday, March 16, 2012

The New Frontier

Full sky polarization survey to l = 5000 would have 6 times the number of modes as Planck

Friday, March 16, 2012

ACTPol’ s Discovery Space

1000 2000 3000 4000 20 40 60 80 100 PLANCK DEEP WIDE II

Text k = 0.2-0.4 Mpc

Friday, March 16, 2012

es in nt nd

• n

y in .

• n

rons. ld drupole net

PIXIE

Survey the whole sky at 300 frequency channels

• ver 2.5 orders of

magnitude in frequency Sensitive to better than r~0.001 Also able to detect y and mu distortions.

Friday, March 16, 2012

Fig D.1.2 Chemical potential µ as a function of the

• Adiabatic fluctuations in

the early universe are dissipated into heat.

• Energy input at z > 106 is

completely thermalized

• Energy input at 106 >z >

103 produces a μ distortion.

• Energy input at 106 >z >

103 produces a y

μ Distortions

Friday, March 16, 2012

Future

How well can we do with large-scale structure? Far more modes than CMB. Calibrate with lensing. Undo non-linearities. Lyman Alpha Forest: Need to push to z > 30. Lunar science?
