Integrated Tunable White Technology HOW DOES IT WORK? The LED board has 2 different colour LED chips : - 2700K - 6500K. All 2700K LEDs are on one circuit. All 6500K LEDs are on a different circuit. 2700K LED The current changes

SLIDE 1

SLIDE 2

Integrated Tunable White Technology

SLIDE 3

SLIDE 4

SLIDE 5

2700K LED 6500K LED

HOW DOES IT WORK?

The LED board has 2 different colour LED chips:

2700K
6500K.
All 2700K LED’s are on one circuit.
All 6500K LED’s are on a different circuit.

The current changes between the 2 circuits to get the required colour.

SLIDE 6

SLIDE 7

SLIDE 8

SLIDE 9

SLIDE 10

230VAC Supply to:

Each linear fitting
Dali Control Box

2500K – 6500K

LED drivers are installed inside the linear

DALI WIRING

Dali Control Box

SLIDE 11

Minimal setup / Out-of-box operation.
Capable of creating, storing and recalling four lighting scenes.
Fully DALI-compatible.
Hidden ‘cleaning’ button.
Supports:
DALI Type 8 colour temperature.
x-y colour presentation.
App control via SceneSet mobile app (iOS and Android).

INCASE YOU MISSED IT, YOUR PHONE CAN ACCESS THE CONTROL VIA BLUETOOTH!!!

HOW DOES IT WORK?

This device controls the % of each colour. Signal sent via Dali.
