Tandem Laser Alignment Bee Line BEST PRACTICES 2018 Purpose Aligning tires on semi trailers Inspect Floors clean Brakes unlocked Air to trailer Wheel Cradle Attach wheel cradles underneath rear tires Brackets to the

SLIDE 1

Tandem Laser Alignment

Bee Line

BEST PRACTICES

2018

SLIDE 2

Purpose

 Aligning tires on semi trailers

SLIDE 3

Inspect

 Floors clean  Brakes unlocked  Air to trailer

SLIDE 4

Wheel Cradle

 Attach wheel cradles underneath rear tires  Brackets to the back

Wheel Cradle

SLIDE 5

Sub Frame Pendulum

 Attach center line sub frame pendulum

Center Line Sub Frame Pendulum

SLIDE 6

Operation

 Set laser bar on cradles  Turn laser on  Line up laser with slit in center line sub frame pendulum

Laser Bar

SLIDE 7

Laser Height

 Adjust laser height by turning black nob

Laser Height Adjustment Nob

SLIDE 8

Attach Pendulum

 Attach king pin pendulum  Unlock and wait for it to stop swinging (centers itself)

King Pin Pendulum

SLIDE 9

Find Center

 Line up laser with slit in both center line sub frame pendulum and

king pin pendulum to find center

Laser

SLIDE 10

Measure

 Use tram to measure distance between wheels on non adjustable

side of back axel

Tram

SLIDE 11

Make Adjustments

 Say its 1 inch off, adjust ½ inch and check the other side (adjusting

ne side has an effect on the other)

 Measure distance on adjustable side(drivers side) and find how

much it is off and needs to be adjusted

Adjustment Clamp

SLIDE 12

Tool Storage

 Turn off laser  Set wheel cradles on the side of the cart that they came off  Set pendulums back on rack  Move cart somewhere it won’t be damaged

SLIDE 13

Training

 https://www.flexiquiz.com/SC/N/61dd37b1-0bf3-4960-b993-

02ef3b0381a0

Training Quiz
