Sri Lanka EnerPHit Industrial Building NYPH PRESENTATION | 2017.06.16 - PowerPoint PPT Presentation

Mar 03, 2023 •241 likes •695 views

Sri Lanka EnerPHit Industrial Building NYPH PRESENTATION | 2017.06.16 Jordan Parnass AIA RIBA CHPD Lois B. Arena, PE Principal Director, Passive House Services Jordan Parnass Digital Architecture Steven Winter Associates Project Team New

  1. Sri Lanka EnerPHit Industrial Building NYPH PRESENTATION | 2017.06.16 Jordan Parnass AIA RIBA CHPD Lois B. Arena, PE Principal Director, Passive House Services Jordan Parnass Digital Architecture Steven Winter Associates

  2. Project Team New York and Colombo. Star Garments / Komar Brands Client Jordan Parnass Digital Architecture Passive House Designer Steven Winter Associates Energy Consultant 475 High Performance Building Supply Quantity Surveying Vinod Jayasingh Architects Architect URO Structural Structural Engineering Chandana Dalugoda Consultants HVAC Engineering K2 Consultants Mechanical Engineering Vform Cost Consultant Tritech General Contractor Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 2

  3. Location Sri Lanka is located off of south India. Colombo is about seven degrees north of the equator. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 3

  4. Climate Colombo features a tropical monsoon climate. Average temperature ranges between 81° and 84° F, and it receives 95 inches of rain annually. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 4

  5. Project Site The project is located in a low-rise industrial park adjacent to the airport. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 5

  6. Existing Building The project is a renovation of an existing two story factory building to EnerPHit standards. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 6

  7. Site Context Trees provide some shade but the majority of building is exposed to the sun. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 7

  8. Existing Interior Exposed steel structure with few partitions. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 8

  9. Cultural Context Users are accustomed to a greater diversity of interior and exterior configurations for building programs. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 9

  10. Design Analysis & Feasibility Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 10

  11. Local Design Exposed steel frame with extensive areas of glass infill. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 11

  12. Local Design Program areas pulled back within the structure to allow for open exterior spaces. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 12

  13. Local Design Some roof overhang. Decorative exterior shading panels. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 13

  14. Cross-Section The upper floor is the main production area features a broad column-free space. The lower area perimeter is pulled back up to a full bay in areas. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 14

  15. Ground Floor Offices and meeting rooms. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 15

  16. Upper Floor Main production area. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 16

  17. Challenges Feasibility Study • Few specification on original drawings to establish baseline for cost and performance. • Difficult to establish historical primary energy use and cost as separate from industrial process loads. • No local distributor for typical Passive House products (tapes, air barrier, ERV etc). • Complex occupancy and usage patterns. Performance Goals • Certifiable to EnerPHit standards. Cultural and Aesthetic Goals • Provide mix of treated and untreated interior and exterior program spaces. • Maintain exposed steel structure design intent. • Create a regional model and local experience for future high performance development. Feasibility Process and Results • Extensive research and evaluation of loads and options. • 77% reduction in primary energy usage. • 6-7 year payback period. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 17

  18. Energy Modelling & PHPP Verification Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 18

  19. PHPP Verification Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 19

  20. Primary Energy By End Use - kWh/m 2 .yr Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 20

  21. Sewing Process Loads Primary Energy - kWh/m 2 .yr Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 21

  22. Solar-Charged Desiccant Dehumidification System Roof = 3,000 m2 Solar thermal array = 500 m2 PV array = 1600 m2 System requires reheat - only have electric on site Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 22

  23. Cooling Load - PHPP Sensible Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 23

  24. Cooling Load - PHPP Latent Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 24

  25. Passive House Design Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 25

  26. EnerPhit Strategy Maintain continuous insulation and air barrier. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 26

  27. Final Design Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 27

  28. Final Design Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 28

  29. Final Design Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 29

  30. Envelope Overview Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 30

  31. Masonry Envelope Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 31

  32. Key Details Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 32

  33. Key Details Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 33

  34. Key Details Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 34

  35. Construction Photo Insulated roof panels. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 35

  36. Construction Photo Rear gable wall masonry infill. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 36

  37. Construction Photo Plaster on masonry infill. Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 37

  38. QA / QC Procedures Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 38

  39. QA / QC - Construction Checklists - Typical Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 39

  40. QA / QC - Construction Checklists - Unique Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 40

  41. Additional Dehumidification Controls - Electric Reheat Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 41

  42. Additional Dehumidification Controls - Heat Pipes w/ Heat Recovery Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 42

  43. Additional Dehumidification Controls - Energy Cost Savings Electric Reheat Scenario Heat Pipe w/ Heat Recovery Scenario 271,876 kWh/yr savings x $0.075 /kWh $20,390 annual savings Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 43

  44. Thanks! Sri Lanka EnerPHit Industrial Building | NYPH 2017.06.16 Page 44
