Speculation on the origin of sub- baseline excursions of CH 4 at Cape Grim GMAC 2016, Boulder, Colorado Zo Loh | Research Scientist 17 May 2016 OCEANS & ATMOSPHERE Co-authors O&A: Paul Krummel, Rebecca Gregory, Paul Steele,

slide-1
SLIDE 1

Speculation on the origin of sub- baseline excursions of CH4 at Cape Grim

GMAC 2016, Boulder, Colorado

OCEANS & ATMOSPHERE

Zoë Loh | Research Scientist 17 May 2016

slide-2
SLIDE 2

Co-authors

  • O&A:
  • Paul Krummel, Rebecca Gregory, Paul Steele, Marcel van der Schoot, Darren

Spencer, David Thornton, Bronwyn Dunse and Ian Galbally

  • O&A/University of Bristol:
  • Ann Stavert
  • Cape Grim BoM staff:
  • Jeremy Ward and Nigel Somerville + all those at Casey in recent years
  • ANSTO
  • Scott Chambers and Alastair Williams

Speculation on the origin of sub-baseline excursions of methane at Cape Grim 2 |

slide-3
SLIDE 3

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Continuous methane data: Cape Grim

3 |

slide-4
SLIDE 4

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Continuous methane data: Cape Grim & Casey

4 |

slide-5
SLIDE 5

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Sub-baseline methane excursions

5 |

slide-6
SLIDE 6

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Sub-baseline methane excursions

6 |

slide-7
SLIDE 7

CRDS and GC-FID measurements

Speculation on the origin of sub-baseline excursions of methane at Cape Grim 7 |

slide-8
SLIDE 8

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Cape Grim methane residuals: 2013

8 |

slide-9
SLIDE 9
  • Intrusions of stratospheric air

– Expect ozone to be anti-correlated with methane during the event

  • Long range transport around the Southern Ocean

– ‘Dynamic isolation’? – Look at the radon & trajectories

  • Marine boundary layer chlorine radical attack

– Look at the correlation with ethane

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Possible mechanisms

9 |

slide-10
SLIDE 10

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

June 2013: Ozone

10 |

slide-11
SLIDE 11

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

June 2013: Radon

11 |

slide-12
SLIDE 12

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

June 2013: Ethane

12 |

slide-13
SLIDE 13

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

13 |

slide-14
SLIDE 14

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

14 |

slide-15
SLIDE 15

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

15 |

slide-16
SLIDE 16

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

December 2013: Ozone

16 |

slide-17
SLIDE 17

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

December 2013: Ethane

17 |

slide-18
SLIDE 18

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

December 2013: Propane

18 |

slide-19
SLIDE 19

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

December 2013: Radon

19 |

slide-20
SLIDE 20

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

20 |

slide-21
SLIDE 21

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

21 |

slide-22
SLIDE 22

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

22 |

slide-23
SLIDE 23

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Trajectories

23 |

slide-24
SLIDE 24
  • Intrusions of stratospheric air

– Wintertime seems to have some of these type of events

  • Long range transport around the Southern Ocean

– Radon is sub 100mBq.m-3, but not notably lower, however; – Trajectories do look to be long range SO transport

  • Marine boundary layer chlorine radical attack

– Depleted ozone, ethane and propane

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Possible mechanisms

24 |

slide-25
SLIDE 25

Conclusions

  • Sub-baseline excursions of CH4
  • Do not (all) seem to be due to stratospheric intrusions
  • Possibly long range transport over the Southern Ocean – dynamic isolation
  • Possibly chlorine radical depletion of methane
  • Do similar events occur at Casey?
  • If so, they are much smaller in magnitude. Does this tell us anything?... Mean

latitudinal OH or source of MBL chlorine radical?

Speculation on the origin of sub-baseline excursions of methane at Cape Grim 25 |

slide-26
SLIDE 26

O&A Zoë Loh Research Scientist t +61 2 9239 4518 e zoe.loh@csiro.au w www.csiro.au

OCEANS & ATMOSPHERE

Thank you

slide-27
SLIDE 27

Residuals at Casey

Speculation on the origin of sub-baseline excursions of methane at Cape Grim 27 |

slide-28
SLIDE 28

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Synoptic conditions: 13 Dec 2013

28 |

slide-29
SLIDE 29

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

Synoptic conditions: 16 Dec 2013

29 |

slide-30
SLIDE 30

Speculation on the origin of sub-baseline excursions of methane at Cape Grim

December 2013: Hydrogen

30 |

slide-31
SLIDE 31

Australian Greenhouse Gas Observation Network

Speculation on the origin of sub-baseline excursions of methane at Cape Grim 31 |

  • Cape Grim
  • Gunn Point – tropical site
  • Burncluith & Ironbark – coal seam

gas fugitives

  • Macquarie Island (LoFlo only)
  • Casey Picarro G2301
  • RV Investigator G2301 & Aerodyne

N2O/CO

  • Arcturus & Otway (CCS)

decommissioned
