NTN-SNR 1 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 1 30.04.19

SOLUTIONS FOR AGRICULTURE

NTN-SNR offer for implements

NTN-SNR 2 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 2 30.04.19

A WORLDWIDE LEADER

FOR YOUR INDUSTRY

CONSTRUCTION CATERPILLAR – KOMATSU - HITACHI - WIRTGEN AGRICULTURE JOHN DEERE – CLAAS – KUBOTA – AGCO - SAME DEUTZ FAHR - KUHN WIND TURBINE GE – VESTAS – NORDEX – ENERCON – GOLDWIN - HITACHI RAILWAY ALSTOM – BOMBARDIER – KAWASAKI – HYUNDAI ROTEM - CSR MACHINE TOOLS DMG MORI - YAMAZAKI MAZAK – FANUC – DOOSAN – HAAS - OKUMA TRANSMISSION AND HYDRAULIC MOTORS MANUFACTURER : ZF – DANA – CARRARO DRIVETECH - BOSCH REXROTH – DANFOSS – POCLAIN HYDRAULICS AERONAUTICS CFMI – PRATT & WHITNEY – AIRBUS – ROLLS ROYCE – AGUSTA-WESTAND

A WORLDWIDE LEADER

FOR YOUR INDUSTRY

NTN-SNR 3 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 3 30.04.19

WE SERVE YOUR INDUSTRY

AGRICULTURAL EQUIPMENT

NTN Corporation : a partner of all agricultural equipment manufacturers Major supplier of JOHN DEERE, KUBOTA, CLAAS, SAME DEUTZ FAHR, KUHN

300

OEM customers

DELIVERED IN EUROPE

N°2

Worldwide

ON AGRICULTURAL MARKET

4M

Bearings sold

FOR AGRI EQUIPMENT 2000

Dedicated

BEARING SOLUTIONS

NTN-SNR 4 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 4 30.04.19

ACHIEVING YOUR OBJECTIVES IS WHAT DRIVES US

From tillage to maintenance through the harvest, we put our know-how to your provision to offer you adapted products for your farming equipment, proven by the leading names in the sector.

NTN-SNR

A TEAM OF SPECIALISTS AT YOUR SERVICE

NTN-SNR 5 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 5 30.04.19

NTN-SNR AGRICULTURAL OFFER:

A RANGE DESIGNED FOR THE LEADING PLAYERS OF THE MARKET

1

COMPOSED OF THE MOST REQUESTED BEARINGS WORLDWIDE

2

ALLOWING YOU TO EASE YOUR CUSTOMER’S DAILY LIFE

3

NTN-SNR

A TEAM OF SPECIALISTS AT YOUR SERVICE

NTN-SNR 6 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 6 30.04.19

AGRI

IMPLEMENTS

DEDICATED

PRODUCTS

RANGE OVERVIEW

NTN-SNR 7 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 7 30.04.19 Soil preparation Seeding Hay making Baling Harvesting Maintenance

OUR SOLUTIONS FOR ALL APPLICATIONS

NTN-SNR 8 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 8 30.04.19

The bearing is directly exposed to a hostile environment : mud, straw, stones, water, etc. The NTN-SNR solution combines the high performance of an automotive bearing to agricultural world requirements

Application : disc harrow

HUA-4M12-S01 after 900ha in field

SOIL PREPARATION

AGRIHUB

Nos Our references

• Volmer
• Köckerling
• Fenet
• Galucho
• Bednar
• Alpego

NTN-SNR 9 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 9 30.04.19

Application : rotary harrow

SOIL PREPARATION

P6X PRECISION

Assembly measurement procedures can sometimes take

• time. They must imperatively be

well done to ensure the reliability of the machine. NTN-SNR propose P6X tapered roller bearings to ease the mounting and gain time.

Nos Our reference

• Kuhn

NTN-SNR 10 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 10 30.04.19

Application : rollers

The bearing is directly exposed to a hostile environment : mud, straw,

stones.

NTN-SNR has develop a solution to respond to a high level of pollution, to high pressure cleaning and

stone projection.

UC206AGR after internal bench test

SOIL PREPARATION

AGR SEALING

Nos Our references

• Kuhn
• Volmer
• Quivogne
• Grimme
• Farmet

NTN-SNR 11 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 11 30.04.19

Application : seeding discs

Bearings are close to the soil with a high level of pollution : dust, projection of stones, mud, straws, water jet cleaning NTN-SNR found the solution for a maximum efficiency working in the moment load.

SEEDING

4 POINTS CONTACT BALL BEARING

Nos Our references

• Kuhn
• Köckerling

NTN-SNR 12 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 12 30.04.19

HAY MAKING

DOUBLE ROW ANGULAR CONTACT BALL BEARING

Application : cutting bars

Bearings face a corrosive environment (grass, mud, fiber, windings) and work in a vertical position with a high speed (up to 3000 rpm) NTN-SNR build a solution that insure a maximum efficiency of the machine thanks to sealing performance and product technology.

Nos Our reference

• Kuhn

KUHN has placed its trust in NTN-SNR for four decades. "The longer service life and the consistent quality of the bearings supplied are for us a valuable asset", says Bernard Jacob, lead buyer at KUHN.

NTN-SNR 13 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 13 30.04.19

Application : balers

Because every machine has to be reliable during the intensive period of use, NTN-SNR developed agricultural inserts bearing with specific sealing and hexagonal bore to ease the mounting.

Nos Our references

• John Deere
• Claas

BALING

INSERT BEARING WITH SQUARE BORE

NTN-SNR 14 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 14 30.04.19

Application : harvesters (example : potato)

Harvesters are complex machines that have many requirements. NTN-SNR suggests 3 performant sealings : L3, L4 and AGR to be adapted to all the constraints.

HARVESTING

L3, L4 AND AGR SEALING

Nos Our references

• AVR
• Grimme

NTN-SNR 15 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 15 30.04.19

Regreasing bearings can take time in your daily life. NTN-SNR propose a connected pump to ease your daily life : now, you can control your pump everywhere and anytime.

Maintenance

MAINTENANCE

OMEGA PUMP

NTN-SNR 16 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 16 30.04.19

MAINTENANCE

LUBRICATION RANGE

Progressive distributor Heavy duty grease The guarantee to have the right quantity of grease in the right place. Years of experience serving extreme applications Manual pump An ideal tool for greasing in agricultural field.

NTN-SNR 17 30.04.19 SOLUTIONS FOR AGRICULTURE : IMPLEMENTS 17 30.04.19

AGRICULTURAL MACHINERY

THANK YOU FOR YOUR ATTENTION

The NTN-SNR range for implements
