Smart.Net-IP NETWORKED ACCESS CONTROL Smart.Net-IP NETWORKED ACCESS CONTROL Smart.Net-IP is a simple, modular approach to networked access control with scalability in mind. Easy management from a central location PC from anywhere with an


slide-1
SLIDE 1

Smart.Net-IP

NETWORKED ACCESS CONTROL

slide-2
SLIDE 2

Smart.Net-IP

NETWORKED ACCESS CONTROL

· Smart.Net-IP is a simple, modular approach to networked · Easy management from a central location PC from anywhere with an Internet connection and a web browser. access control with scalability in mind.

slide-3
SLIDE 3

· Capacity for over 4000 tags · Proximity cards only or card + PIN operation · Location and roll call reporting · Attendance reports for payroll support · Windows desktop and web browser administration · On demand email notifications

MAIN FEATURES

slide-4
SLIDE 4

· Single installation on a local machine for maximum security · Remote workstations simply connect using an Internet Browser, Mobile Smart Phone or Tablet Device · No additional installation of software or application needed.

SOFTWARE

slide-5
SLIDE 5 CR1216 3V + DDCCEC Power Supply Door Controller Electric Locking Device Magnetic Contact Entry Reader Exit Reader (Optional) Exit Button Break Glass (Optional) Next Door Controller Smart Door Node Previous Door Controller

· Door Controller has total control of a single door · All system settings and events are stored locally at the door controller · Full door access control online or offline · All devices located at the door means reduced cable and labour costs

SINGLE DOOR ARCHITECTURE

slide-6
SLIDE 6

NETWORKING USING USB ADAPTER

· Scalable for up to 128 doors · Max. distance of 1.2 km · Daisy chain configuration.

CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC

Ground Floor: Offices Ground Floor: Storage First Floor: Offices First Floor: Training Rooms BROADBAND Internet USB adapter LOCAL PC REMOTE ACCESS

slide-7
SLIDE 7 CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC

BROADBAND

  • r IP SWITCH

Internet

NETWORKING USING IP ADAPTERS

· Flexible configuration with IP adapters in multiple locations · Scalable for up to 128 doors · Max. distance of 1.2 km.

CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC CR1216 3V + DDCCEC

Ground Floor: Offices Ground Floor: Storage First Floor: Offices First Floor: Training Rooms IP adapter IP adapter IP adapter IP adapter LOCAL PC REMOTE ACCESS

slide-8
SLIDE 8

Accessories

· Emergency break glass unit · Magnetic door contact

WHAT DO I NEED FOR A SINGLE DOOR INSTALLATION?

System Administration

· Personal Computer · Software

Door Control

· Door controller · Proximity reader · Proximity tags · Power Supply · Exit request button

Network Communication

· USB or IP Adapter · Networking Cable

Electric locking

· Magnetic Lock or Electric Strike

slide-9
SLIDE 9

Smart.Net-IP

THANK YOU

Unit 1, AMC Business Park 12 Cumberland Avenue Park Royal, London, NW10 7QL T : E : W : sales@doorentrydirect.com www.doorentrydirect.com +44 (0)208 621 6210
