Traff ffic M Mana nagement C Cente enters rs fo for th the e Extre treme Do Do-It-Your urselfe fer Tom Mahood City of Orange Traffic Engineer March 28, 2007 ITE 2007 Technical Conference Traffic ffic M Management C t Cente

slide-1
SLIDE 1

Traff ffic M Mana nagement C Cente enters rs fo for th the e Extre treme Do Do-It-Your urselfe fer

Tom Mahood City of Orange Traffic Engineer March 28, 2007

ITE 2007 Technical Conference

slide-2
SLIDE 2

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

  • 1. What traffic management software do you want to

use? (Typically driven by existing or planned controllers)

  • 2. What communications links are available or planned?
  • 3. What communications protocol to use?

So, can "we" (us City-types) build a TMC ourselves?? Maybe….Depends upon the answers to the following questions:

slide-3
SLIDE 3

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

TMC-Traffic Signal Communication Links

  • Fiber optic cable (High cost, not for DIY, great bandwidth)
  • Existing copper (Low cost, possible DIY, moderate bandwidth)
  • Radio links (Can be low cost, easy DIY, modest bandwidth)
  • T1 lines (Moderate recurring cost, DIY, good bandwidth)
  • Cellular modems (Low recurring cost, DIY, low bandwidth)

The system can be a mixture of any of these. The "right tool for the right job" applies.

slide-4
SLIDE 4

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

Communications Protocols –Ethernet or Serial? Ethernet

  • Widespread
  • Superficially complex
  • Plentiful equipment
  • High bandwidth
  • ITS Dept support
  • Easily scales

Serial

  • Used to be THE standard
  • Simple in low numbers
  • Equipment phasing out
  • Moderate bandwidth
  • Device dependent
  • "So last Century"
slide-5
SLIDE 5

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

Welcome to Mission Control Approximate hardware cost ~ $122,000

slide-6
SLIDE 6

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

The magical guts that make it all happen

slide-7
SLIDE 7

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

You can never be too rich, be too thin or have too many screens

slide-8
SLIDE 8

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

Wait, you say you can’t afford a Mission Control? How about a functional equivalent for $2,400?

slide-9
SLIDE 9

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

And never, EVER forget….

slide-10
SLIDE 10

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

  • TMC room remodel (design and construction) $7k + $29k
  • TMC control console $10k
  • Two computer workstations, a laptop and system server $10k
  • Video display wall with 90” central screen and six 20” monitors $80k
  • Two CCTV cameras with wireless video links $13k
  • One CCTV camera with fiber link $6k
  • Communications racks, video switch and support hardware $6k

Total hardware cost ~ $161,000 Software cost: $101,000 Total initial TMC cost: $262,000

Total cost without "Mission Control" would have been ~ $140,000

Summary of Initial Costs for City of Orange

slide-11
SLIDE 11

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

But let’s talk about the really fun stuff…..

Hardware!!!

slide-12
SLIDE 12

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

Inexpensive (<$800) fiber optic modem

  • 2 copper, 2 SM fiber ports
  • Unmanaged, easy to use
  • Just plug and go
  • Can daisy-chain controllers
  • Very rugged and hardened
  • Needs two fibers (1 in & 1 out)
slide-13
SLIDE 13

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

  • Serial port device server (~$170 each)
  • Allows RS-232 serial ports to be accessed over Ethernet network
  • Battery backup units can be monitored from the TMC
  • Minimal setup (only have to assign IP address for device)
  • Can work for controllers too
slide-14
SLIDE 14

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

Can you find the traffic monitoring camera?

Development's contribution to traffic mitigation installed under the terms of a negotiated development agreement

slide-15
SLIDE 15

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

It’s always fun to drill holes in someone else’s building

slide-16
SLIDE 16

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer 5.8 GHz Wireless Video Link

  • Distance to TMC ~ 4 miles
  • Cohu PZT camera
  • Verint "SmartSight" radio
  • Home Depot fittings & paint
  • Scrap aluminum
  • "Free" electricity

Total cost ~ $7,000

slide-17
SLIDE 17

But be afraid of window washers…Be very afraid

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

slide-18
SLIDE 18

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

More wireless video fun…… Typical intersection TMC end

slide-19
SLIDE 19

Traffic ffic M Management C t Cente ters fo for th the Ext xtrem eme Do-It It-Your

  • urse

selfer

So, asking the question again… Can we build a TMC ourselves?? Probably…..because…. Engineering School = HARD Traffic Management Center = Easy
