SLIDE 1

Sliding Substitution of Failed Nodes

Atsushi Hori, Kazumi Yoshinaga, Yutaka Ishikawa RIKEN AICS Thomas Herault, Aurélien Bouteiller, George Bosilca University of Tennessee, ICL

15年10月2日金曜日

SLIDE 2

EuroMPI 2015, Bordeaux

Motivation

Having spare node set seems to be the last

resort

“in such case, spare node can be used.”
Having spare node is not the answer,

but new research issue

2

15年10月2日金曜日

SLIDE 3

EuroMPI 2015, Bordeaux

Fault Resilience

Fault tolerance in Exa-flops era
High failure rate
High I/O bandwidth requirement
User-level fault resilience
Less I/O bandwidth required
e.g., ULFM (User-Level Fault Mitigation)
We need a recovery strategy !!

3

15年10月2日金曜日

SLIDE 4

EuroMPI 2015, Bordeaux

Survival from Node Failure

Jobs with dynamic load balancing
e.g., Task bag, PIC, ...
Job shrinking to exclude failed nodes
Tasks running on failed node(s) are

migrated to live nodes

Jobs without dynamic load balancing
e.g., Stencil computation, ...
Very difficult to balance load
Having spare nodes seems to be the

answer ...

4

15年10月2日金曜日

SLIDE 5

EuroMPI 2015, Bordeaux

Stencil Computation

Survival from a node failure
Load balancing
Preserving communication pattern
Less code modification

5

Shift the load on to healthy nodes New complex communication pattern

15年10月2日金曜日

SLIDE 6

EuroMPI 2015, Bordeaux

Spare Node

In an error handler (of ULFM, for example)
create a new MPI communicator to
exclude the failed node, and
include a spare node.
then, migrate the task running on the failed

node to the spare node

No change in the kernel part of application
However, at the network level, the regular

stencil communication pattern can be lost !

6

15年10月2日金曜日

SLIDE 7

EuroMPI 2015, Bordeaux

Is spare node really the answer ?

Our scope
Is there any penalty? If any, how much?
How spare nodes should be allocated?
How many spare nodes should be allocated?
How failed nodes should be substituted be

spare nodes?

Out of scope
How (soft/hard) errors are detected
How checkpoints are taken
How tasks are migrated

7

15年10月2日金曜日

SLIDE 8

EuroMPI 2015, Bordeaux

Spare Node Penalty (1)

Spare node allocation and node utilization

8 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 2D(1,1) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 2D(2,1) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 2D(2,2)

2 4 6 8 10 12 14 10,000 100,000 1,000,000 % Spare Nodes # Nodes 2D(1,1) 2D(2,1) 3D(1,1) 3D(2,1) 3D(3,1)

15年10月2日金曜日

SLIDE 9

EuroMPI 2015, Bordeaux

How many spare nodes ?

MTBF of a node
50,000 Hr. ≈ 5 Years
MTBF of Exa (106 nodes)
0.05 Hr. = 3 Min.
#Spare = 10,000 (1%)
500 Hr. ≈ 20 Days
104 out of 106

9 10 100 1,000 10,000 10,000 100,000 1,000,000 System MTBF (50,000H/Node) # Nodes 2D(1,1) 2D(2,1) 3D(1,1) 3D(2,1) 3D(3,1)

15年10月2日金曜日

SLIDE 10

EuroMPI 2015, Bordeaux

Spare Node Allocation

Changing spare node allocation method

according to the number of nodes

10

1 2 3 4 5 10,000 100,000 1,000,000 % Spare Nodes # Nodes 2 4 6 8 10 12 14 10,000 100,000 1,000,000 % Spare Nodes # Nodes 2D(1,1) 2D(2,1) 3D(1,1) 3D(2,1) 3D(3,1)

15年10月2日金曜日

SLIDE 11

EuroMPI 2015, Bordeaux

Spare Node Penalty (2)

Possibility of communication performance

degradation

5P Stencil communication pattern

11

S F

Spare Nodes Normal After substitution

2D Cartesian Network and XY Routing

15年10月2日金曜日

SLIDE 12

EuroMPI 2015, Bordeaux

Sliding Substitution

0D Sliding
1D Sliding
2D Sliding
3D, 4D, .... Sliding

12 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 22 23 21 24 25 26 27 28 29 30 31 32 33 34 35

0D Sliding

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 22 23 24 25 26 21 28 29 30 31 32 27 34 35 33

1D Sliding 2D Sliding

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 Spare Nodes Spare Nodes

Node 21 fails

15年10月2日金曜日

SLIDE 13

EuroMPI 2015, Bordeaux

5P Stencil on 2D Network

Simulated Results
Spare Allocation
2D(2,1) > 2D(1,1)
Max. Failure
0D: up to #Spare
1D: 3 (or more)
2D: up to 2

(2D Cart. Topo.)

Comm. Perf.
2D > 1D > 0D

13

B B B B B B B B B B C C C C C

5 10 15 20 25 30 35 1 2 3 4 5 6 7 8 9 10

Max. Collisions

B Mesh C Torus B B B B B

5 10 15 20 25 30 35 1 2 3 4 5 6 7 8 9 10

B B B

2 4 6 8 10 1 2 3 4 5

Max. Collisions

# Failures

B B

2 4 6 8 1 2 3 4 5 # Failures

??? combinatory explosion

no message collision
up to 2 failures

up to 3 failures in worst case

15年10月2日金曜日

SLIDE 14

EuroMPI 2015, Bordeaux

5P Stencil Comm. Perf.

14

K K K K K K

KKK

256KiB 1MiB 4MiB

1

2 3 4 Relative Latency

K K K K K K

KKK

256KiB 1MiB 4MiB

K K K

K K K

KKK

256KiB 1MiB 4MiB

K K K

K K K

KKK

256KiB 1MiB 4MiB

K K K

K K K

KKK

256KiB 1MiB 4MiB

K K K

K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

1

2 3 4 Relative Latency

K K K K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

1

2 3 4 5 6 Relative Latency

K K K K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

K K K

K K K

KKK

256KiB 1MiB 4MiB

K

K K K K K

KKK

256KiB 1MiB 4MiB

1

2 3 4 5 6 Relative Latency

K K K K K K

KKK

256KiB 1MiB 4MiB

the K

BG/Q

Smaller is better

15年10月2日金曜日

SLIDE 15

EuroMPI 2015, Bordeaux

Collective Performance

15

KKK KKK

K K K

0D 1D 2D

1

2 3

Rel. Perf. (based on 15x31)

K K K K K K K K

K K K K

0D 1D 1D+ 2D

KKK

KKK

K K K

0D 1D 2D

K

K K K K K K K

K K K K

0D 1D 1D+ 2D

2

4 6 8 10 12

Rel. Perf. (based on 16x32)

KKK KKK

K K K

0D 1D 2D

K

K K K K K K K

K K K K

0D 1D 1D+ 2D

1

2 3

Rel. Perf. (based on 16x32)

KKK KKK

K K K

0D 1D 2D

1

2 3

Rel. Perf. (based on 15x31)

K K K K K K K K

K K K K

0D 1D 1D+ 2D

K K K

K K K

0D 1D 2D

1

2 3

Rel. Perf. (based on 23x23)

K K K K K K K K

K K K K

0D 1D 1D+ 2D

1

2 3

Rel. Perf. (based on 23x23)

K K K K K K

K K K

0D 1D 2D

1

2 3

Rel. Perf. (based on 23x23)

K K K K K K K K

K K K K

0D 1D 1D+ 2D

1

2 3

Rel. Perf. (based on 23x23)
On K and BG/Q,

collective ops are

ptimized for

their network.

Having spare

nodes makes the

ptimization very

difficult.

BG/Q’ optimization

works only with MPI_COMM_WORLD

Smaller is better

15年10月2日金曜日

SLIDE 16

EuroMPI 2015, Bordeaux

Summary

Study on spare node substitution has just

begun

Comm. perf. degradation is observed
5P stencil :
Simulation: up to 100 times larger latency
Experiment: < 20 times larger latency
Collective : up to 12 times larger latency

16

15年10月2日金曜日

SLIDE 17

EuroMPI 2015, Bordeaux

Current and Future Work

Evaluations with real applications
Node-Rank re-mapping algorithms, or better

substitution methods

Dragonfly and/or Fat-tree network ?
Experiments using Tsubame 2.5 (Fat-tree) is

scheduled

At this moment, it is still unclear if having spare

nodes is a promising technique

17

15年10月2日金曜日

SLIDE 18

EuroMPI 2015, Bordeaux

Acknowledgement

Thank to

Dr. Norbert Attig

at Jülich Supercomputing Center to give us a chance to use JUQUEEN.

18
