Shared-clock methodology for time-triggered multi-cores Keith F. Athaide Project supervisor: Michael J. Pont Technical supervisor: Devaraj Ayavoo Communicating Process Architectures (CPA) 2008 8 th -10 th September 2008 Overview Aims

SLIDE 1

Shared-clock methodology for time-triggered multi-cores Keith F. Athaide

Project supervisor: Michael J. Pont Technical supervisor: Devaraj Ayavoo

Communicating Process Architectures (CPA) 2008 8th-10th September 2008

SLIDE 2

2

Overview

 Aims  Execution policies

– Co-operative – Pre-emptive

 Execution architectures  Shared-clock architecture

– Algorithm for non-broadcast topologies

 Multi-processor microcontroller architecture  Case study description  Results  Conclusions

SLIDE 3

3

Aims

 Maintain the predictability and robustness of co-operative

single-processor systems

– Custom system-on-chip (SoC) – Time-triggered applications

 Heterogeneous processors  How to synchronise the different processors?

SLIDE 4

4

Execution policy

 System has many functions  Functions often decomposed into discretely executing

blocks called tasks

– Periodic or aperiodic tasks

 Periodic tasks may have static or dynamic periods  Tasks have deadlines  Tasks are executed according to a policy

– Co-operative execution policy – Pre-emptive execution policy

SLIDE 5

5

Co-operative execution policy

Time Time  Tasks must yield control when required  Resource sharing needs no complex locking

mechanisms

– Same processor, one execution thread

 System responsiveness inversely related to longest task

execution time

SLIDE 6

6

Pre-emptive execution policy

Time  Tasks can interrupt each other  Interruption controlled by priorities  Predictability dependent on uniformity in pre-empting

instructions

 Problems such as priority inversion

SLIDE 7

7

Scheduler architectures

 Event-triggered

– Multiple events – Feasibility depends on

 the number of events expected  the number of events serviceable by hardware

– “Construct by correction”

 Time-triggered

– Single event – Other events sensed by polling – “Correct by construction” – Can be power hungry

SLIDE 8

8

Shared-clock architecture

Receive Tick Send ACK Run tasks Slaves Timer Overflow Send Ticks Run tasks Receive ACKs Master Timer Overflow Hardware [overflow]

SLIDE 9

9

Shared-clock non-broadcast topology

 Existing implementations

need communication topologies supporting broadcasts

– Buses like CAN

 Can be simulated by

point-to-point transmissions

– Hardware or software

 Tree broadcast

– MPI collective

communication algorithm

 Lag due to point-to-point

transmissions

a d b c e g h f i g a d h e b c f i

SLIDE 10

10

Multiprocessor architecture

 Network Interface Module (NIM)

– Messaging component as peripheral or co-processor

 Debug cluster

– Write to memories – Set breakpoints, stepping, etc.

Processor Debug Messaging peripheral Timer GPIO

NIM

Memory

Cluster Cluster Network-on-chip (NoC) NIM Cluster NIM Cluster NIM

Processor

SLIDE 11

11

Network interface modules (NIMs)

 Asynchronous communication  Error detection

– 12-bit checksums (CRCs)

 No automatic error correction

– Errors cause no extra communication – Software notes and corrects errors

 Static routing  Serial-parallel communication  Variable number of channels  Lack of predictability in

communication latency might affect

verall predictability of the shared-

clock system

Transport Network Data link Channel Channel

SLIDE 12

12

PH Processor

 Single interrupt

– Built for time-triggered applications – Multiplexed from any number of sources

 Soft-core processor (VHDL source available)  32-bit reduced instruction set computer (RISC)  MIPS I ISA (excluding patented instructions)  Harvard architecture  32 registers  5-stage pipeline

SLIDE 13

13

Hardware implementation

SLIDE 14

14

Hardware usage of NIMs

1 2 3 4 600 650 700 750 800 Bits per channel 6 8 16 Number of channels Hardware slices used

SLIDE 15

15

Case study description

 Nine nodes

– Mesh topology

 Three scheduler types

– SCH1: P1 as master; P1

sends Ticks only when previous is acknowledged

– SCH2: P1 as master; P1

sends Ticks in turn

– SCH3: Tree broadcast

 Relative times measured P5 P2 Debug P6 P7 P3 P4 P0 P1 P1 P0 P4 P3 P7 P2 P6 P5

SLIDE 16

16

Timer sense times (microseconds)

P0 P2 P3 P4 P5 P6 P7 50 100 150 200 250 300 SCH1 SCH2 SCH3

SLIDE 17

17

Timer sense times for SCH3 (microseconds)

P0 P3 P4 P2 P7 P5 P6 10 20 30 40 50 60 70 80

SLIDE 18

18

Timer sense time jitter (microseconds)

P0 P2 P3 P4 P5 P6 P7 0.5 1 1.5 SCH1 SCH2 SCH3 SCH3 (local)

SLIDE 19

19

Timer sense time jitter in SCH3 (microseconds)

P0 P3 P4 P2 P7 P5 P6 0.5 1 1.5 P1 local
