Rock Ranger 150 – Standard Features

 Designed and certifies as a mining vehicle  The vehicle is unique because of it’s coil spring suspension and articulated frame.  Various model options available.  The vehicle also boasts hub mounted wet disc Service/Park brakes, making it fully compliant with S.A.NS. 1589.

OPTION 1: SUPERVISION/UTILITY VEHICLE  5 seats  1.5 Ton Payload OPTION 2: SERVICE RECOVERY VEHICLE  3 Seats  1.5 Ton Payload On Board Air Compressor:  Tyre Inflation  Pneumatic Tools/Impact Wrench/Greasing Equipment  Vetter Bags Tools, Spare Parts & Hardware:  Storage Racks/Spares Bins  Oxygen-Acytelene Gas Bottles  Portable LED Lighting Hydraulic Power Take-Off:  Jaws of Life  40 Ton Toe Jack  Porta-Power Jacking Cylinder  Roof Bolt Pull Testing Equipment  Hose Crimper with Hose Cut-off Wheel Utility Crane OPTION 3: EMERGENCY RESPONSE VEHICLE (UINDERGROUND AMBULANCE)

Rock Ranger 150 – Model Options

 ELECTRICAL SYSTEM 24V negative earth - 55A alternator Lights Halogen 50W 4 forward 2 rear with red brake lights LED Navigation Lights C.A.S. System – Optional Overspeed System –Optional Data Logging – Optional  PERFORMANCE 1st gear: 5km/hr (max) - 2nd gear: 12km/hr 3rd gear: 28km/hr - 4th gear: 32km/hr  WEIGHT Operating: 4000kg Max Payload: 1500kg  DIMENSIONS Length 6969mm Width 1700mm Height 1400mm Wheel base 2715mm Ground Clearance 260mm Seating 5 Pax.  TURNING RADIUS Outer 6499mm Inner 4327mm  FIRE SUPPRESSION ANSUL 101 Manual with Auto Battery Disconnect  ENGINE OPTIONS Water-Cooled Deutz TCD2012 EPA Tier 3 Air-Cooled Deutz F4L914W/D914LO4 - EPA Tier 2 Catalytic Purifier & Fume Diluter  TRANSMISSION Dana Clark Power Shift 4-speed forward & reverse Constant 4-wheel drive  AXLES Rigid, Planetary Hub Reduction Coil Spring suspension system  BRAKES Wet Disc Hydraulic Brakes (Hub mounted) Spring applied fail safe park brake (Hub mounted) On all 4 wheels Tyre size: 8.25 x 15  STEERING Frame Articulation ±32° Orbital valve & steering wheel Frame Oscillation ±10°  HYDRAULICS 175bar, 65l/min

Rock Ranger 150 – Technical Specifications

 Deutz F4L914W EPA Tier 2  Air Intake system  T12000 Transverter  8.25x15 UGS Tyres.  T- Back Seats  All Filters are common between Ranges  A large portion of the Electrical Switch Gear is the same

Rock Ranger 150 – Parts Commonality with MV-U40 Range of Vehicles

BLIND SPOT BLIND SPOT BELOW 1000mm BLIND SPOT BELOW 600mm REAR VIEW CAMERA

Rock Ranger 150 – Visibility Diagram

Rock Ranger 150 Vehicle Dimensions

 Tier 2,3 – 4 Engine options available  On board Oil Filtration Pump & Filter for Hydraulic oil filling  ISRT T – Back Seats with Aircraft type seat belts  4 Wheel Drive – permanent  Leaf Spring Suspension – front & back  Heavy Duty Shock Absorbers  Articulataed Steering with Twin, Single acting Steering Cylinder  Hydrostatic Transmission with Variable Displacement Pump and motor. Automotive Displacement Control  Heavy duty UVB 60 Full Floating Axles with Oil Cooled, Multi-disc SAHR Brake Mounted on each wheel (2 per axle)  24 volt Electricity system (Mining Standards)  Heavy Duty Mining Tyres (BKT Minestar)  Heavy duty 3-piece Mining Rim (Inward facing Locking Ring)  Auto apply Parking Brakes applies automatically when doors are open, Neutral is selected or insufficient Brake release pressure occurs  ProtecFire Automatic Fire Suppression system with Auto Battery Disconnect Switch  LED Hella High Power working lights – front & rear  Navigation lights – Front & rear LED type  Reverse Modulated Service Brakes with Single Line design  Positive Brake Flushing and Cooling with Filtration  Full Murphy Engine Protection System with Engine Shut down when fault is detected  Heavy Duty Drive Shafts with Greaseable Universal Joints  Safety Door Switches automatically sets parking  Brake when doors are opened. Park Brakes must be Manually released  Wheel Locks supplied as Standard (2 piece)  Spare Wheel (1 piece) supplied as standard  Starter Motor relay included to prevent excessive Cranking

• r Starter Motor Engagement whilst Engine is running

 Large Truck type reversing Mirrors fitted (2 piece)  Reverse Alarm fitted OPTIONAL EXTRAS  OSCON Overspeed Brake Interlock with Data Logging  NEROHUB CAS/PDS Interface with Data Logging  Reversing Camera  Utility Winch – Hydraulic Type  Hydraulic Power Take-off for “Jaws of Life” Equipment  Additional Front Lighting Package

Reef Rover 050 – Standard Features

Reef Rover 050 – Technical Specifications

 ENGINE OPTIONS Air/Oil Cooled Deutz F3L2011 EPA Tier 2 Deutz F4L2011 EPA Tier 2 Deutz D2011 L4I EPA Tier 3 Water Cooled Kubota V2403-CR-TE413 EPA Tier 4  TRANSMISSION Hydrostatic with variable Displacement Piston Pump (Automotive Control) and 2-speed Piston Motor  AXLES UVB 60FF Axles with Spring Applied Hydraulic release (SAHR) Wet Disc Brakes Brakes mounted to each Wheel (2 per Axle) with Positive Brake Flushing and Wear Inspection Port Front Axle has limited Slip Differential Tyre Size: 8.25 x 15  STEERING Frame Articulation ±32° Orbital valve with Steering Wheel & Adjustable Column  HYDRAULICS 175bar 8.5cc Brake Pump – Gear Type 11.0cc Steering Pump – Gear Type Auto-Apply Parking Brake Valve with Door Interlock Separate Hydraulic Tanks for Steering/Brakes & Hydrostatic Transmission  ELECTRICAL SYSTEM 24V (negative earth) Lights - LED Type Hella 2 forward, 2 Rear with Red Brake Lights, LED Type LED Type Navigation Lights NEROHUB CAS/PDS Interface (Optional) OSCON Overspeed System (Optional)  PERFORMANCE Low Range – Forward & Reverse – 15km/h High Range – Forward only - 23km/h  WEIGHT Gross: 4620kgs Nett: 3820kgs  DIMENSIONS Length 5980mm Width 2010mm Height 1460mm Wheel base 2630mm Ground Clearance 225mm Seating 5 Pax. + 500kgs or 8 x Pax.  TURNING RADIUS Outer 5500mm Inner 3150mm  FIRE SUPPRESSION SYSTEM ProtecFire Detexline Automatic System with Auto Battery Disconnect

Reef Rover 050 Turning Circle & Vehicle Dimensions

Reef Rover 050 Visibility Diagram

Reef Rover 050 – Engine & Transfer Case Reef Ranger 050 – Drivetrain Arrangement

UV Botswana prides itself on the ability to deliver customer specific, purpose-built low profile Utility Vehicles. In order to continuously offer the client innovative and tailor-made solutions for their low profile utility needs, UV Botswana has a vast range of vehicles in operation, as well as a constant development of concept vehicles under testing through our Research and Design Department, therefore information in this brochure is subject to change without notice. In order to obtain the latest technical sales specifications and a quote, please contact our authorised distributors:

Sales Information Sales Information

GHH Mining Machines Mine Machines

Contact us:

UV Botswana (Pty) Ltd Physical address: Plot 9800 Tekwane Close, Somerset West – Francistown Tel: +267 241 9922 - Fax: + 267 242 0443 Kevin Tink – Managing Director - E-mail: ktink@minetech.co.bw Rick van Malsen – General Manager - E-mail: rvanmalsen@uvbotswana.co.bw
