Real-Time Resampling Processor for SWARM Mark Peryer Harvard Smithsonian Center for Astrophysics August 16, 2017 Presentation Overview Background Objectives Design Results Future work Background Event Horizon Telescope (EHT) Image the
SLIDE 2
SLIDE 3
Background
Event Horizon Telescope (EHT)
Image the event horizon of SgrA* Global network of telescopes Very Long Baseline Interferometry (VLBI)
SLIDE 4
Submillimeter Array
Mauna Kea, Hawaii 8 element interferometer 32 GHz instantaneous bandwidth
SLIDE 5
SWARM
ROACH2 platform ADCs record data at 4.576 GSps One Quadrant = ~38 Gigabits every second!
SLIDE 6
Compatibility Issue SMA
4.576 GHz Frequency Domain ≠
EHT
4.096 GHz Time Domain
SLIDE 7
APHIDS
Non-real-time GPU resampling system
ROACH2 ROACH2 ROACH2 ROACH2 ROACH2 ROACH2 ROACH2 ROACH2
SWITCH
10 GbE
SWARM
Single Quadrant
SDBE
ROACH2
UDP VDIF Time q2 UDP VDIF Time q2 UDP VDIF Time q2 UDP VDIF Time q2 4.69 Gbps 4.69 Gbps 9.38 Gbps 4.75 Gbps
Aggregate Data Rates 37.50 Gbps Into Switch/SDBE 18.99 Gbps Into Mark 6
Mark 6
Data Recorder
GPU Server
q2 VDIF unpack 16K-pt FFT N-pt FFT M-pt FFT q2 VDIF unpack 16K-pt FFT N-pt FFT M-pt FFT q2 VDIF unpack 16K-pt FFT N-pt FFT M-pt FFT q2 VDIF unpack 16K-pt FFT N-pt FFT M-pt FFT TCP VDIF TCP
GeForce GTX 980 GeForce GTX 980 GeForce GTX 980 GeForce GTX 980
Mark 6
Data Recorder
Mark 6
Data Recorder Disk transport post-observation
SLIDE 8
Improvements
APHIDS
𝙔 Costly 𝙔 Time Inefficient 𝙔 Quantization Error
Real-Time Resampler
✓Inexpensive ✓ Instantaneous Results ✓ Limited Quantization Error
SLIDE 9
Target Hardware
SKARAB
Virtex 7 FPGA 40 GbE interface
SLIDE 10
40GbE (Rx) Depacketize (B-engine) Data Transpose Data Reprocessing Packetize (VDIF) 40GbE (Rx) 32768 point Inverse FFT Resampling Requantize
High-Level Overview
SLIDE 11
Resampling
4576 4096 = 143 128 Upsample by 128 Downsample by 143
⬇ 2
L LPF H(k)
M
Input
⬆ 3
LPF
SLIDE 12
Practicality
⬆128 ⬇143 585 billion samples every second! Throw away 581 billion samples
SLIDE 13
Solution
⬆16 ⬇17.875
128 143 16 8 13 11 4576 4096 = 16 143/8 = 16 17.875
SLIDE 14
z-1 z-1 b0 b1 b2 b3 ∑ ∑ t0 t1 t2 3b0 +2b2 4b0 +3b2 5b0 +4b2 t0 t1 t2 2b1 +1b3 3b1 +2b3 4b1 +3b3
z-1 z-1 z-1 b0 b1 b2 b3 ∑
Upsampling
F 2F F F
Inefficient Clock rate increased Efficient Clock rate unchanged
SLIDE 15
4 samples every clock cycle 1 new sample every 16 clocks Pattern repeats for parallel inputs
Scaling Up
Time
SLIDE 16
SLIDE 17
FIR Filter
63rd order FIR filter Low pass filter 64 coefficients Least-squares linear phase
Magnitude response of filter
Fpass = 2.138 GHz Fstop = 2.288 GHz
SLIDE 18
16 Filters 1024 multiplies 768 adds
FIR Filter Design
SLIDE 19
Downsampling
16 outputs every clock ⬇ by 17 and 18 ROM stores mux select Repeats every 143 clocks
SLIDE 20
Simulated Input
1 GHz sine wave 4.576 GHz sample rate 16 parallel samples per clock
SLIDE 21
Simulated Results
Theoretical output from MATLAB Output from Simulink Design
SLIDE 22
Bit Growth
16_14 bit input 16_14 bit coefficients 34_28 bit output 8_7 bit input 8_7 bit coefficients 18_14 bit output Full bit depth Reduced bit depth
SLIDE 23
Resource usage
LUTs 7% Reg. 0.5% BRAMs 0.5% DSPs 0%
SLIDE 24
Conclusion
Real Time Implementation Parallel FIR Filter Design Fits on Target Hardware
SLIDE 25
Future Work
Remove invalid outputs Incorporate into Real-Time Resampling System
SLIDE 26
Acknowledgements
Jonathan Weintroub Sheperd Doeleman André Young Rurik Primiani Bob Wilson Arash Roshanineshat SKA Team Casper Community
