Presented by Daniel Gilbert Raw Water Mains Modelling Prioress Mill WPS Network Overview Operational Incident Burst on 48inch Isolate 48 inch Prioress Mill 8 bar Max Is there enough pressure to reach SOR WPS Sluvad Water Treatment

slide-1
SLIDE 1

Presented by Daniel Gilbert

Raw Water Mains Modelling

slide-2
SLIDE 2

Network Overview

Prioress Mill WPS

slide-3
SLIDE 3

Operational Incident

Burst on 48inch

‐ Isolate 48 inch

‐ Prioress Mill 8 bar Max

Is there enough pressure to reach SOR WPS – Sluvad Water Treatment Works ?

slide-4
SLIDE 4
slide-5
SLIDE 5

Model Construction

Modelling Constraints Time Data

slide-6
SLIDE 6

Prioress Mill WPS (22m AOD) Critical Point (89m AOD) SOR WPS (48m AOD)

slide-7
SLIDE 7

Head losses Velocity Pressures

Conclusion

0.8m/km 6.4m total 73.4m Required 1.4 m/s
