Domestic water in commercial buildings Reginald Brown Tap Drinking Domestic Mains Wholesome Fresh Sanitary Potable 2 The built environment experts Mains water myths Sterile Aerobic bacteria 3- 34 cfu/ml as supplied to BSRIA -

slide-1
SLIDE 1

Domestic water in commercial buildings

Reginald Brown

slide-2
SLIDE 2

2

The built environment experts

Sanitary

Wholesome

Domestic

Potable

Drinking Fresh

Mains Tap

slide-3
SLIDE 3

3

The built environment experts

Mains water myths

Sterile

  • Aerobic bacteria 3- 34 cfu/ml as supplied to BSRIA -

could be much higher out of the tap

Pure

  • 140 Ca, 6 Mg, 60 SO4, 58 Cl, 36 NO3 mg/l
  • TDS ~ 450 mg/l

Harmless

  • Domestic water leaks probably cause more damage in

buildings than heating and cooling system leaks. Insurance claims run into million of pounds each year.

slide-4
SLIDE 4

4

The built environment experts

Water quality reports

Available free from water companies web sites

slide-5
SLIDE 5

5

The built environment experts

Domestic water system issues

  • Corrosion and erosion

– Pipes needing replacement in less than 2 years

  • Colonisation by bacteria and other microbes

– Pseudomonas – Legionella – Protozoa, filamentous fungi etc

  • Joint failures

– Catastrophic release of water Unfortunately no time for

joint failures today!

slide-6
SLIDE 6

6

The built environment experts

Corrosion

slide-7
SLIDE 7

7

The built environment experts

Corrosion risks

  • Most domestic water systems use copper tube
  • Copper pipework in new or refurbished buildings is at

high risk of pitting leading to pinhole corrosion from:

– microbiologically influenced corrosion (MIC) – disinfectant residues – flux residues – scale deposits

If the water is allowed to stagnate !!!

slide-8
SLIDE 8

8

The built environment experts

Legionella guidance

The draft of HSG 274 Part 2 The control of legionella bacteria in hot and cold water systems has a recommendation to use gas pressure testing to avoid a prolonged stagnation period prior to commissioning. If accepted by industry this may reduce the risk of some causes of pitting. The draft also suggests that weekly flushing of filled systems should be implemented to reduce stagnation and maintain the level

  • f chlorine from the incoming supply.

BSRIA experience is that weekly flushing unlikely sustain the mains chlorine level or be sufficient for the control of pitting corrosion.

slide-9
SLIDE 9

9

The built environment experts

Corrosion feature on outside

slide-10
SLIDE 10

10

The built environment experts

Typical nodule in base of pipe

slide-11
SLIDE 11

11

The built environment experts

Malachite and azurite crystals capping corrosion pit

slide-12
SLIDE 12

12

The built environment experts

Section of perforated pit

Malachite & Azurite (mineral forms of basic copper (II) carbonate) Cuprite (a mineral form of copper (I) oxide)

slide-13
SLIDE 13

13

The built environment experts

Two sections from the same pipe

slide-14
SLIDE 14

14

The built environment experts

Pitting features

slide-15
SLIDE 15

15

The built environment experts

Linear spots

slide-16
SLIDE 16

16

The built environment experts

Micrograph of spots

slide-17
SLIDE 17

17

The built environment experts

Why black?

slide-18
SLIDE 18

18

The built environment experts

Basic SEM

slide-19
SLIDE 19

19

The built environment experts

Scanning electron microscope (SEM) micrograph

slide-20
SLIDE 20

20

The built environment experts

SEM Energy dispersive x-ray spectroscopy (SEM-EDS)

slide-21
SLIDE 21

21

The built environment experts

Elemental maps around the perforation

Copper Chlorine Oxygen Phosphorous

slide-22
SLIDE 22

22

The built environment experts

Progress of corrosion pinholes

Surface dirt and debris Carbon film Chlorination residue Biofilm Flux residue

Stagnation

Initiation of corrosion cell Pitting Perforation

slide-23
SLIDE 23

23

The built environment experts

Microbiologically influenced corrosion

slide-24
SLIDE 24

24

The built environment experts

Typical result of microbiological corrosion

slide-25
SLIDE 25

25

The built environment experts

Electron micrographs of microbiological corrosion features

Underside of nodule Pitted surface

slide-26
SLIDE 26

26

The built environment experts

Assessing the cause of pitting

  • It is more productive to look at pits that are still

forming than a hole

  • Well developed pits have similar composition

irrespective of the original cause – usually rich in chlorine

  • Assessment of the root cause of pitting depends on

looking at the general surface of the pipe (visually and by composition of scale) as well documentary evidence regarding the history of the system

  • In-pipe endoscopy can help to determine the extent
  • f the problem
slide-27
SLIDE 27

27

The built environment experts

Incidence of pinholes

  • Most corrosion pin-holes occur in cold water pipes

– Most commercial building systems use pumped hot water circulation which avoids stagnation – only the final connection to the tap will be subject to stagnation

  • All erosion pin-holes occurs in hot water pipes on the

return

– The root cause is excessive flow velocity in poorly balanced systems

slide-28
SLIDE 28

28

The built environment experts

Endosopy in 15 mm copper pipe using 6mm camera

slide-29
SLIDE 29

29

The built environment experts

Erosion

slide-30
SLIDE 30

30

The built environment experts

Turbulent erosion

slide-31
SLIDE 31

31

The built environment experts

Turbulent erosion

slide-32
SLIDE 32

32

The built environment experts

Erosion of scale

slide-33
SLIDE 33

33

The built environment experts

Cavitation

slide-34
SLIDE 34

34

The built environment experts

Bacteria

slide-35
SLIDE 35

35

The built environment experts

Bacteria and other microbes

  • Microbiologically influenced corrosion

– Sulphate reducing bacteria – Pseudomonads

  • Pathogenic bacteria

– Pseudomonas aeruginosa – Legionella

slide-36
SLIDE 36

36

The built environment experts

Endoscopy of 15 mm hot pipe

slide-37
SLIDE 37

37

The built environment experts

The source of the video

slide-38
SLIDE 38

38

The built environment experts

Draft legionella guidance

  • A lot more background information on water systems but the

principles of legionella control have not changed

  • Recommendation on avoidance of stagnation is generally

welcomed as mentioned earlier but some concerns on the safety and effectiveness of gas pressure testing

  • Some concern also over the inclusion of chlorine as a candidate

for continuous supplementary disinfection as it is not very effective against legionella and potentially detrimental to some system materials

slide-39
SLIDE 39

39

The built environment experts

Differences in risk assessment between legionella and pseudomonas aeruginosa

  • Legionella

– Enters the system through the water supply – Colonises parts of the system with favourable temperature and nutrients – Risk assessment looks at the design, construction and

  • peration of the water system
  • Pseudomonas aeruginosa

– Enters the system from the outlets – Colonises the outlets and fittings – Risk assessment looks at the way the outlets are used and maintained i.e. people factors – Specialist guidance in HTM 04-01: Addendum - Pseudomonas aeruginosa – advice for augmented care units

slide-40
SLIDE 40

40

The built environment experts

Thank you!

  • The new Illustrated Guide to Domestic Water

Services will be published later this year and available as a free download to BSRIA members.

  • BSRIA is also involved in the drafting of

BS 8554 Code of practice for the sampling and monitoring of hot and cold water services in buildings also to be published later this year.
