Raw Data Reconstruction with Raw-Data Reconstruction with PROOF

• C. Cheshkov, P. Hristov

24/10/2008 ALICE Offline Week C O e ee

Many thanks to:

Andrei,Federico,Fons,Jan,Gerri,Latchezar,Rene for the discussions and help and Marco & Jan Fiete for their great support on CAF! for their great support on CAF!

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 2

What is all about?

R AliR t d t i ll l d i PROOF

Run AliRoot raw-data reco in parallel mode using PROOF Fast reconstruction feedback Tuning of reco-parameters and code Fast test before going to full-blast AliEn production Fast test before going to full blast AliEn production It may sound a bit abstract, but in fact that was one of the

• ptions we needed urgently during the LHC start-up
• ptions we needed urgently during the LHC start-up

Use case:

− raw-data files << #slaves − Higher (compared to ESD) event size and processing time

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 3

Contents

Overview

Overview

AliReconstruction implemented as Tselector

− Input List

Code executed on slaves (also I/O)

− Code executed on slaves (also I/O) − Output files

Performance on CAF

Documentation

Documentation Outlook 24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 4

July 08, Federico's office Lets make a TSelector

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 5

It turned out to be a bit more It turned out to be a bit more difficult...

I itR Init QA mgr Init Run: C t R R d InitRun: Create RawReader Init CDB Modified set run# from RAW Init Geometry Create RawReader Init run-loaders Init CDB Set run# from RAW Init Geometry I it GRP Init GRP Load all needed OCDB entries Unload used OCDB entries Init Reco-params Init GRP Init Reco-params Init vertexers and trackers Open ESD files Out-of-Loop QA SlaveBegin: Read selector input list Init run-loaders Init vertexers and trackers Open ESD files Reconstruct Event: ... In-loop QA Intermediate ESD files Init QA mgr Process: Recreate RawReader ... TkDiff 4.1.4 report ... Finish Run: Close files etc. Out-of-loop QA In-loop QA ... SlaveTerminate: Close files etc. number of diffs: 104 17 regions were deleted 20 regions were added 67 regions were changed ESD tags Finish QA Finish QA Terminate: ESD tags

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 6

AliReconstruction :: public TSelector AliReconstruction :: public TSelector

CLIENT MASTER SLAVES

collection of raw-data files SlaveBegin: Restore AliReconstruction Init run-loaders Init vertexers/trackers

CLIENT MASTER SLAVES

InitRun: Create raw-reader Get run # gProof Init vertexers/trackers Open ESD files Init QA mgr Get u # Load OCDB R Input List TGeo geometry OCDB t i Raw data xrootd Run: Raw-data-chain->Process() OCDB entries Mag field map

AliReconstruction

Process: Recreate raw-reader from tree entry Terminate: Create tags Standard event reco Event QA Merging ESD files ESD SlaveTerminate: Close files etc. Finish QA 24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 7

AliReconstruction :: public TSelector

Completely transparent for the user:

− Prepare collection of raw-data files (one run)

( )

− Open PROOF session − Enable AliRoot (reco libs) on master and slaves

( )

− Run your favourite (or standard) rec.C by providing files collection as

input (“collection://xxx”)

− One can use any specific OCDB storage, custom reco options, reco-

params etc. If PROOF session is not opened > runs locally and allows quick

− If PROOF session is not opened -> runs locally and allows quick

check/debugging of the AliRoot code

Same code base used as if running sequentially Same code base used as if running sequentially Note: One has to patch v5-21-01-alice with the fixes in PROOF

• utput files merging

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 8

• utput files merging

Input List

Contains all 'parameter-like' objects common to slaves

Single access to OCDB from client machine

Single access to OCDB from client machine Allows to customize reconstruction (as if running locally) Size:

− Dominated by OCDB entries − Depends on the active detectors − From a few MBs to ~50-60 MBs at most

It took quite some time to debug the code as input-list was

copied on the master (default constructor TGeoManager deletes previous instance)

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 9

O Sl On Slaves

• First read input list:

−

Restore AliReconstruction state from client session

−

Restore OCDB manager state <- OCDB entries

−

Set TGeo geometry and field map

• Initialize:

−

AliRoot run-loaders (for managing intermediate reco files)

−

Open ESD/ESD-friend files & initialize QA mgr

• Process:

−

Get AliRawEvent entry from raw-data tree

−

Recreate raw-reader out of it

−

Run standard single-event reco

• Finally:

−

Close all files & finalize QA

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 10

On Slaves (Local I/O)

AliRoot reco output files:

AliRoot reco output files:

− ESD − ESD-friend (switchable) − QA files (switchable)

Q ( )

− Intermediate (RecPoints, Digits) files (was not

switchable) switchable)

− Log (switchable)

If we get rid of intermediate files, the I/O would

minimal

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 11

Fil l R L d File-less Run-Loaders

Idea: TFile > TDirectory (no I/O all event objects in

Idea: TFile -> TDirectory (no I/O, all event objects in

memory) W i l t d d t t (d t il f

Was implemented and tester (details on performance

slides)

− Controlled via the url of galice.root file − Some methods not implemented at TDirectory level − In AliReconstruction - disable unloading/loading and writing of rec-

points, digits data

− At the moment code is unstable (problems with ROOT garbage

collection)

Will b itt d t fid

Will be committed as soon as we get more confidence

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 12

Output Files

Using output-file merging functionality in

Using output file merging functionality in PROOF (based on TFileMerger) B d f lt

By default

− Only ESD files are merged

y g

− Resulting file arrives locally

N it t i t d d li t hi

Necessitate running xrtood daemon on client machine Check the way to run and configure xrootd on CAF-reco

web page (shown at the end of the talk) web-page (shown at the end of the talk)

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 13

Output Files

How to merge ESD-friend files?

− Opened transparently inside ROOT − How to create PROOF-output file?

p

Possibility to specify another output ESD file location (url)

Make resulting ESDs available in CAF as data-set (optionally)

− Make resulting ESDs available in CAF as data-set (optionally)

Possibility to retrieve other output files (expert mode)

AliR i S O ( l) ?

AliReconstruction::SetOutput(url) ?

− If location is file url – store ESD (and ESD-friends) there − If location is folder – store all output files (one sub-folder per slave)

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 14

Performance on CAF...

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 15

Performance – init time

Linear dependance Slope depends mainly on the

size of OCDB objects sent to slaves

Gerri is implementing the

p g concept of 'input data'

−

Data is uploaded on slaves storage similarly to PAR files similarly to PAR files

−

Transparent to the user

−

Updated only when input data changes p y p g

−

There should be no dep on #slaves -> init time will be diminshed to a few s

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 16

Performance – processing rate

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 17

Perforamnce – local I/O

Processing rate in ev/s (4 files, 2.2 GB, 1200 evts)

No QA No QA,ESD-friend No QA,ESD-friend,run-loaders No QA,ESD friend,run loaders

2 4 6 8 10 12 14 16

No QA,ESD-friend,run-loader,log

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 18

6 8 6

Performance – cache size

Packets much shorter than Packets much shorter than

tree cache (and xrootd read- ahead?) size

− Leads to an overhead input

data rate

− More slaves -> packets

become shorted -> effect is more pronounced

One has to play with both

sizes

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 19

Test w/o read ahead in xrootd client Test w/o read-ahead in xrootd client and smaller tree cache

Processing rate:

Processing rate:

− No effect for the runs

with more detectors with more detectors

− Performance of ITS-

l tl i d

• nly greatly improved

Overall slow-down is

most likely due to AliRoot update ;-) AliRoot update ; )

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 20

Test w/o read ahead in xrootd client Test w/o read-ahead in xrootd client and smaller tree cache

Input data rate:

− Now effect is

pronounced not only f ITS b t l for ITS run, but also for all runs with small e ent si e event size

− I guess ROOT resets

tree cache depending

• n the entry size

Some crashes with

smaller cache size

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 21

smaller cache size

Tests with longer packets

Not tested to full extent due to some technical

Not tested to full extent due to some technical problem R t t t h

Recent tests show

− Mediocre results − System is unstable...

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 22

Documentation

http://aliceinfo.cern.ch/Offline/Activities/Reconst

http://aliceinfo.cern.ch/Offline/Activities/Reconst ruction/RecoOnCAF/index.html Will t t d t ith h i t t h

Will try to update with each important change or

addition

Reminder: users can also use analysis-task-

force mailing list force mailing list

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 23

Experience on GSI-AF

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 24

O tl k Outlook

Optimize performance Optimize performance

− Find optimal parameters (packet-size, tree cache depending

• n event size #files/slaves etc )
• n event size, #files/slaves etc.)

− Check the influence of reco code memory consumption

S h b i d i i i i h PROOF d

− Somehow put obtained optimizations in the PROOF code

(packetizer,...)

I d d d l OK

Input data – under development - OK Handling of output files - straightforward Handling of output files straightforward Scalability of the system in case of more files

− Master is quite unstable - serialization?

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 25

The machinery works so try it out and send us

The machinery works, so try it out and send us

your feedback!

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 26

Spares

24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 27

Exercise with local data-set

4 files x 4 slaves (eff ~24 slaves) 4 files x 2 slaves (eff ~22 slaves 4 files x 1 slave (only local slaves) 4 fil ll l 4 files x all slaves i td f t 5 10 15 20 25 via xrootd from castor 24/10/2008 Raw-Data Reco with PROOF (C.Cheshkov, P.Hristov) 28
