Modules Spacing and Mutual Shading PVMD Olindo Isabella Delft University of Technology Learning objectives 1. PV module design 2. Electrical properties 3. Temperature effects 4. Mounting issues 1. Mutual shading and module spacing

Modules Spacing and Mutual Shading PVMD Olindo Isabella Delft University of Technology
Learning objectives 1. PV module design 2. Electrical properties 3. Temperature effects 4. Mounting issues 1. Mutual shading and module spacing • Shade-free time window • Row spacing • Ground cover ratio 2. Earthing 3. Practical example of mounting issues 5. Reliability and I-V tests
Considerations By: Richard Masenor
Module Shading Same location, same time of the day Winter Summer
Module Shading Winter Industry practice : optimize for 21 st Dec in a certain shade-free time window
Shade-Free Time Window 12h 11h 13h 60 ° 14h 10h 10h 14h 50 ° 15h 9h Solar Elevation 40 ° 16h 8h 30 ° 17h 7h 20 ° 6h 18h 5h 10 ° 19h 10 ° 30 ° 60 ° 90 ° 120 ° 150 ° 180 ° 210 ° 240 ° 270 ° 300 ° 330 ° 360 ° Solar Azimuth East West
Module Spacing d shadow z l h a S θ M θ M Row spacing, d             
Shade-Free Time Window 12h 11h 13h 60 ° 14h 10h 10h 14h 50 ° 15h 9h Solar Elevation 40 ° 16h 8h 30 ° 17h 7h 20 ° 6h 18h 5h 10 ° 19h 10 ° 152 ° 208 ° 30 ° 60 ° 90 ° 120 ° 150 ° 180 ° 210 ° 240 ° 270 ° 300 ° 330 ° 360 ° Solar Azimuth East West
Module Spacing d shadow z l h a S θ M θ M Row spacing, d Correction factor between Azimuths Rule of thumb: d ~ 3 l           
Ground Cover Ratio (GCR) 𝐵𝑠𝑓𝑏 𝑄𝑊 𝑏𝑠𝑠𝑏𝑧 𝐻𝐷𝑆 = 𝐵𝑠𝑓𝑏 𝑢𝑝𝑢𝑏𝑚 𝑕𝑠𝑝𝑣𝑜𝑒 Trade-off High GCR Low GCR Higher system costs Larger shade (*) J. M. Gordon & H. J. Wenger; Central-station solar photovoltaic systems; (1991)
Recap 12h 13h 11h 60 ° 10h 14h 50 ° 15h 9h Solar Elevation 40 ° 16h 8h 30 ° 17h 7h 20 ° 6h 18h 5h 10 ° 19h 180 ° 240 ° 30 ° 60 ° 90 ° 120 ° 152 ° 208 ° 270 ° 300 ° 330 ° 360 ° Solar Azimuth West East
Recap d shadow z l h a S θ M θ M Row spacing, d
