Proxy Token Translation Service - internals

Mischa Sall´ e

msalle@nikhef.nl

EGI Community Forum, Bari 12 November 2015

Mischa Sall´ e (Nikhef) 1 / 13

Token Translation Service

Focus on interaction VO-portal ↔ Master-portal (TTS)

A Proxy Token Translation Service Mischa Sall´ e (Nikhef) 2 / 13

Token Translation Service

Our token: short-lived RFC3820 (VOMS) proxy certificate Translation from SAML identity to proxy certificate Access to TTS must be restricted to certain services:

→ delegation scenario: use OpenID Connect TTS acts as OIDC server (Authorization Server and protected Resource) VO Portal acts as OIDC client Use OIDC access token to obtain proxy certificate

A Proxy Token Translation Service Mischa Sall´ e (Nikhef) 3 / 13

End Entity Certificate

Also need End-Entity Certificate (EEC) Cache EEC in MyProxy credential store behind TTS CILogon portal-delegation scenario (http://goo.gl/VnMKXS)

Uses OpenID Connect for MyProxy protocol OIDC server in front of a MyProxy Online CA TTS acts as OIDC client Uses OIDC access token to obtain End-Entity Certificate

→ Use protocol and OpenID Connect server twice!

A Proxy Token Translation Service Mischa Sall´ e (Nikhef) 4 / 13

Building blocks

End Entity Certificate: produced using MyProxy online CA OIDC4MP DS is OIDC server TTS/Master Portal is OIDC client EEC cached in MyProxy credential store Proxy Certificate (our token): produced using EEC in MyProxy credential store TTS/Master Portal is OIDC server VO Portal is OIDC client proxy is retrieved and used by VO portal

Building Blocks Mischa Sall´ e (Nikhef) 5 / 13

TTS Overview: getting a certificate

Architecture Mischa Sall´ e (Nikhef) 6 / 13

TTS Overview: cmdline via ssh backdoor

Architecture Mischa Sall´ e (Nikhef) 7 / 13

TTS Overview: using OIDC only

Architecture Mischa Sall´ e (Nikhef) 8 / 13

TTS Overview: complete picture

Architecture Mischa Sall´ e (Nikhef) 9 / 13

Bonus features

OpenID Connect server:

Reuse OIDC4MP server for pure OpenID Connect SAML-to-OIDC token translation service (not difficult in itself) Broader use for Master Portal

SSH backdoor for commandline access:

VO portal: SSH pubkey upload (similar to GitHub, CERN) Master Portal (TTS): store in LDAP cron-job: authorized keys with fixed command (myproxy-logon wrapper) user obtains proxy using SSH-Agent → No need for ECP, Moonshot, custom passwords etc.

Discussion Mischa Sall´ e (Nikhef) 10 / 13

More Bonus features

Smooth transition from PUSP:

MyProxy CA not much different from MyProxy credential store Can use robot cert+key instead of CA cert+key Few simple changes in config of MyProxy CA → produce PUSP instead of EEC

Based on well-maintained and proven software:

Production software, widely used in US Actively developed Maintainers are part of AARC Easy to replace components (modular setup)

Discussion Mischa Sall´ e (Nikhef) 11 / 13

Next steps

Implementation Master Portal: minor adaptations to profile (already agreed upon): /getproxy endpoint extra OIDC server servlet inside Master portal

/getproxy endpoint behind /authorize endpoint

/authorize endpoint

first server servlet then client servlet flow for pure OIDC, probably using different scope

implement SSH key upload: /putkey endpoint?

Next steps and conclusions Mischa Sall´ e (Nikhef) 12 / 13

Final remarks

Work in progress but looking good! Based on AARC-SA1 pre-pilot work Combining existing blocks, minimal glue Many thanks to Tamas Balogh (doing a lot of the hard work)

Next steps and conclusions Mischa Sall´ e (Nikhef) 13 / 13

Some References

Our setup: https://wiki.nikhef.nl/grid/CILogon_Pre-Pilot_Work OpenID Connect for MyProxy: http://goo.gl/VnMKXS CILogon docs: http://www.cilogon.org/portal-delegation MyProxy: http://grid.ncsa.illinois.edu/myproxy/

OA4MP: http://grid.ncsa.illinois.edu/myproxy/oauth/ protocol: http://grid.ncsa.illinois.edu/myproxy/protocol/

VOMS: e.g. http://italiangrid.github.io/voms/ ssh authorized keys: man sshd
