SLIDE 1
@ardalis | ardalis.com | weeklydevtips.com
FORCE MULTIPLIER FOR DEV TEAMS
t h s
C# Design Patterns: Proxy APPLYING THE PROXY PATTERN Steve Smith - - PowerPoint PPT Presentation
C# Design Patterns: Proxy APPLYING THE PROXY PATTERN Steve Smith - - PowerPoint PPT Presentation
C# Design Patterns: Proxy APPLYING THE PROXY PATTERN Steve Smith FORCE MULTIPLIER FOR DEV TEAMS @ardalis | ardalis.com | weeklydevtips.com t h s What problems does proxy solve? Objectives How is the proxy pattern structured? Apply the
SLIDE 2
SLIDE 3
Problem: Need to control access to a type for performance, security, or other reasons.
SLIDE 4
Real World Examples
SLIDE 5
Common Software Examples
SLIDE 6
Common Software Examples
User Interface Twittergrambook ServiceProxy Client App API Service Twittergrambook API Endpoints
SLIDE 7
Proxy Usage in Software
SLIDE 8
Proxy Structure
SLIDE 9
Proxy Structure
SLIDE 10
Virtual Proxy
Proxy Variants
Remote Proxy Smart Proxy Protective Proxy
SLIDE 11
s h s
Virtual Proxy Stands in for an expensive-to-create object Typically responsible for getting real object UI Placeholders Lazy-Loaded Entity Properties
SLIDE 12
Demo
t h s
Virtual Proxy in C#
SLIDE 13
s h s
Remote Proxy Client works with proxy as if remote resource were local Hides network details from client Centralizes knowledge of network details
SLIDE 14
Demo
t h s
Remote Proxy in C#
SLIDE 15
s h s
Smart Proxy Performs additional logic around resource access Resource counting Cache management Locking shared resources
SLIDE 16
Demo
t h s
Smart Proxy in C#
SLIDE 17
s h s
Protective Proxy Manages access to a resource based on authorization rules Eliminates repetitive security checks from client code and the resource itself Acts as a gatekeeper around a resource
SLIDE 18
Demo
t h s
Protective Proxy in C#
SLIDE 19
When used properly, proxy implementations help you to follow Separation of Concerns and the Single Responsibility Principle.
SLIDE 20
Separation of Concerns
Related Principles
Avoid mixing separate concerns or ideas in the same class or method
Loose Coupling
Prefer loose coupling to third party dependencies
Single Responsibility
Classes should have only
- ne responsibility; one
reason to change
Some principles suggest the use of a Proxy as the solution in certain cases.
1
SLIDE 21
Flyweight Adapter Prototype Decorator
Related Patterns
SLIDE 22
t h s
A proxy controls access to another class There are at least 4 kinds of proxy variants: Virtual Remote Smart Protective Proxy classes can be generated automatically, especially remote proxies An appropriate use of proxy often helps your code follow good coding principles Latest sample code:
https://github.com/ardalis/DesignPatternsInCSharp
Key Takeaways
