More Design Patterns

Horstmann ch.10.1,10.4

Design patterns

• Structural design patterns

– Adapter – Composite – Decorator – Proxy

• Behavioral design patterns

– Iterator – Observer – Strategy – Template method – Visitor

Adapters

• Cable adapter: adapts plug to foreign wall outlet
• OO Programming; Want to adapt class to foreign

interface type

• Example: Add CarIcon to container
• Problem: Containers take components, not icons
• Solution: Create an adapter that adapts Icon to

Component

Adapter

Have Icon Want Component

Adapter

public class IconAdapter extends JComponent { private Icon icon; public IconAdapter(Icon i) { icon = i; } public void paintComponent(Graphics g) { icon.paintIcon(this, g, 0, 0); } public Dimension getPreferredSize() { return new Dimension(icon.getIconWidth(), icon.getIconHeight()); } }

The ADAPTER Pattern

Context

• You want to use an existing class (adaptee) without modifying it.
• The context in which you want to use the class requires target

interface that is different from that of the adaptee.

• The target interface and the adaptee interface are conceptually

related. Solution

• Define an adapter class that implements the target interface.
• The adapter class holds a reference to the adaptee. It translates

target methods to adaptee methods.

• The client wraps the adaptee into an adapter class object.

The ADAPTER Pattern

The ADAPTER Pattern

Icon paintComponent() JComponent paintIcon() JFrame IconAdapter

QUIZ

We have list, but we want stack. Can we make adapter?

• 1. No, it is not possible
• 2. Yes, it is possible, but UML diagram is wrong
• 3. Yes, it is possible and UML diagram is correct
• 4. I don’t know

Adapter pattern Stack:

Proxies

• Proxy: a person who is

authorized to act on another persons behalf

• Example: Delay instantiation
• f object
• Expensive to load image
• Not necessary to load image

that user doesn't look at

• Proxy defers loading until

user clicks on tab

Image Loading

Simple approach: load image files from web address

JTabbedPane tabbedPane = new JTabbedPane(); for (int i=100; i<200; i++) { URL url = new URL("http://www.cs.au.dk/dProg2/..."+i+”.jpg”); JLabel label = new JLabel( new ImageIcon(url) ); tabbedPane.add(i, label); } All 100 pictures are loaded before the first is displayed May be slow May overflow memory

Deferred Image Loading

• Simple image loading:

JLabel label = new JLabel( new ImageIcon(url) );

• Using proxy:

JLabel label = new JLabel( new ImageProxy(url) );

• paintIcon loads image if not previously loaded

public void paintIcon(Component c, Graphics g, int x, int y) { if (image == null) image = new ImageIcon(url); image.paintIcon(c, g, x, y); } Picture is fetched only if/when needed

The PROXY Pattern

Context

• A class (the real subject) provides a service that is specified by an

interface type (the subject type)

• There is a need to modify the service in order to make it more

versatile.

• Neither the client nor the real subject should be affected by the

modification. Solution

• Define a proxy class that implements the subject interface type.

The proxy holds a reference to the real subject, or otherwise knows how to locate it.

• The client uses a proxy object.
• Each proxy method invokes the same method on the real subject

and provides the necessary modifications.

The PROXY Pattern

The PROXY Pattern

Icon ImageIcon ImageProxy paintIcon() paintIcon() JLabel

QUIZ

Only super-users should be able to delete items from the FilmCatalogue. Which pattern does the code and the UML diagram exemplify?

• 1. Adapter
• 2. Proxy
• 3. Composite
• 4. None of the above
• 5. I don’t know

Which pattern?

public interface Catalogue<E> { public boolean add(E item); public boolean delete(E item); } public class SecureCatalogue<E> implements Catalogue<E> { private boolean superUser; private Catalogue<E> cat = new FilmCatalogue<E>();; public SecureCatalogue(boolean su) { superUser = su; } public boolean add(E item) { return cat.add(item); } public boolean delete(E item) { if (superUser) return cat.delete(item); else return false; } }
