PRODUCT PRESENTATION

2019

• SIGHT GLASS
• POD (CMP)
• HUB
• COLUMN
• BOWL

OUTLINE

SIGHT GLASS

THE LUNETA

Stop using those old, dark, flat sight

• glasses. The Luneta Sight Glass

provides a crystal-clear, 360-degree view of in-service oils. It is shatterproof, chemically resistant and made to withstand harsh environments, including extreme

• temperatures. You’ll never want to

use those hard-to-read sight glasses again!

Hex for Easy Wrench Installation 360° Viewing Etched Cross Hair Flat Surface

for high-definition viewing without obstruction

Eye-Lets

FEATURES

SIGHT GLASS

THE LUNETA

Flat window sight glasses cast a shadow over the oil and make it difficult to see inside. 3D Sight Glasses like Luneta’s, proudly displays the oil, allowing light to enter and illuminate the lubricant, making condition monitoring easier and more effective.

OLD WAY NEW WAY

BEFORE and AFTER

Flat Window Sight Glass Luneta Sight Glass

SIGHT GLASS

THE LUNETA

Noticeably Dark Color

Identifying OIL DEGRADATION

Oil degradation means the oil has begun to break down due to a combination of time, heat, water and air. When the oil breaks down it loses its physical properties, in addition to producing varnish and corrosion on the inside of a

• machine. Oil degradation is most

easily identified by a darkening of the oil’s color inside a sight glass.

SIGHT GLASS

THE LUNETA

OLD WAY NEW WAY

Flat Window Sight Glass Luneta Sight Glass

Difficult to See Color

POD

THE CONDITION MONITORING

The Condition Monitoring Pod (CMP or POD for short) is a multi-parameter device that lets you observe the oil level, color, clarity, aeration, foaming, corrosion, varnish, wear debris and much more. You will quickly identify root causes and symptoms of failure that previously would have gone undetected.

Oil Sampling Port Corrosion Indicator Etched Cross Hairs Magnet

FEATURES

POD

THE CONDITION MONITORING

The Condition Monitoring Pod features a built-in sampling valve for convenient sampling without having to shut down your machine or expose the oil to contaminants. Additionally, the sampling valve is attached to a stainless-steel pilot tube that can be bent to whatever angle is desired for proper live-zone sampling. TIP: Sampling is recommended when the conditions within the Pod’s sight glass have

• changed. This prevents costly and unnecessary lab tests.

OIL SAMPLING

POD

THE CONDITION MONITORING

OLD WAY NEW WAY

The Condition Monitoring Pod features a built-in magnet for capturing and displaying ferrous wear debris. This magnet is installed

• n the sight glass of the Pod for convenient
• bservation while the machine is still
• running. The sight glass can also be rotated

so that the magnet can be lifted out of the

• il for further analysis.

Magnet Wear Debris

TIP: Small amounts of wear debris are often present in oil and will collect on the magnet over time. Action should be taken when there is a sudden increase in wear debris, which signifies a serious event and impending failure. This is one of the many reasons why daily inspections of Luneta’s products are necessary.

Identifying WEAR DEBRIS

Magnet

OLD WAY NEW WAY

POD

THE CONDITION MONITORING Cannot See Wear Debris

Corrosion on Indicator Dark Color

Identifying OIL DEGRADATION

The Condition Monitoring Pod features a Copper Corrosion Indicator to detect the presence of acidic conditions due to oil

• degradation. If the Copper Corrosion

Indicator shows corrosion in the form of discoloration on the surface, then your oil has begun to break down and you should expect other cupric elements in your machine to be at risk of corrosion.

POD

THE CONDITION MONITORING Cannot See Color or Corrosion

TIP: If Corrosion is detected, pull an oil sample from the Pod’s sampling valve and send it to a lab for further analysis.

OLD WAY NEW WAY

Identifying WATER CONTAMINATION

Corrosion on Indicator Cloudy

The Condition Monitoring Pod features a Steel Corrosion Indicator to detect the presence of water. If the Steel Corrosion Indicator shows corrosion in the form of discoloration on the surface, then there is water in your system and your oil’s rust inhibitors have begun to fail. You should also expect other ferrous elements in your machine to be at risk of corrosion.

POD

THE CONDITION MONITORING Difficult to See. Is it white because of air

• r water?

TIP: If Corrosion is detected, pull an oil sample from the Pod’s sampling valve and send it to a lab for further analysis.

OLD WAY NEW WAY

HUB

THE

HUB

THE

The Hub is a multi-port adapter that allows easy installation of oil level sight glasses, bottom sediment and water (BS&W) bowls, drain valves, quick connects for attaching filtration equipment, etc. In addition to four lateral ports, the Hub features a recessed oil sampling

• port. It is ideal for equipment with

limited or inaccessible fluid port locations.

FEATURES

Sampling Valve 4 Lateral Ports Shielded and Robust Design Rotatable every 45o

HUB

THE

The Hub elegantly turns one port into five - there are two 1” NPT lateral ports, two ¾” NPT lateral ports, and a central ¼” NPT port for the sampling valve. The Hub is adjustable every 45-degrees to ensure optimal orientation of the lateral ports.

OLD WAY NEW WAY

BEFORE and AFTER

HUB

THE

The Hub features a built-in sampling valve with an attached pilot tube for easy live-zone

• sampling. The valve is recessed

into the Hub for protection from accidently impacts. The pilot tube is 12” and stainless steel. Both standard flow and high flow sampling valve options are available.

OLD WAY NEW WAY

OIL SAMPLING

COLUMN

THE

COLUMN

THE

The Column is a crystal-clear oil level sight glass that allows you to visually inspect the condition and level of oil in pumps, gearboxes, storage tanks and reservoirs. It features a one-piece design with 1-inch NPT threads at each end and includes either a 3-Micron Breather or a Vent- to-Headspace option at the top. Two tamper- proof level rings mark the idle and running oil level.

Tamper-Proof Level Rings Crystal Clear View of Oil

FEATURES

Vent-to- Headspace Option 3-Micron Breather Option Tamper-Proof Level Rings Durable One-Piece Design

COLUMN

THE

Most oil level sight glasses are difficult to see, they are marred with obstructions, they don’t have any good breathing options, and they do not provide reliable ways to mark the maximum and minimum oil levels. Luneta’s Columns solve all those problems with a crystal-clear sight glass that permits monitoring of the oil level from great distances, contamination free breathing options, and tamper proof level rings.

BEFORE and AFTER

OLD WAY NEW WAY

BOWL

THE

BOWL

THE

The Bowl is designed to capture and purge bottom sediment and water. A contoured base ensures no sediment is left behind, and a magnetic drain valve captures and displays any wear debris. Made of high impact Tritan™, the Bowl also features a shielded drain valve, a single- piece design, a built-in Hex for easy installation and eye-lets for tagging critical information.

Shielded Drain Valve Magnet Drain Valve Hex with Eyelets 360° Viewing Contoured Base

FEATURES

Collect WEAR DEBRIS

BOWL

THE

The Bowl includes a magnetic drain valve to capture and display any wear debris. TIP: Small amounts of wear debris are often present in oil and will collect on the magnet

• ver time. Action should be taken when

there is a sudden increase in wear debris, which signifies a serious event and impending failure. This is one of the many reasons why daily inspections of Luneta’s products are necessary.

Ferrous Sludge Wear Debris

Purge WATER & BOTTOM SEDIMENT

BOWL

THE

The Bowl is designed to capture and purge bottom sediment and water. Gravity pulls the denser materials do the bottom and displays them for analysis. A drain valve provides the ability to purge the material, so it doesn’t get reintroduced into the system. A contoured base ensures no water or sediment is left behind upon purging.

WATER SEDIMENT PURGING

TIP: Daily inspection and purging of the Bowl is recommended.

Sediment Water

QUESTIONS?

Please visit

www.LUNETA.com

For more information
