2017 Ceiling Fans Presentation Techno II The contemporary 72 - - PowerPoint PPT Presentation

2017 Ceiling Fans Presentation

• The contemporary 72” Techno II featuring a sleek Black finish is

designed to cool large areas and lofts.

• Energy-efficient DC motor consumes about 60% less energy than an

AC fan. This means reduced operating costs and a minimized environmental impact.

• Lengthy ABS blades are accentuated by subtle curves and provide

powerful air circulation.

• Integrated dimmable LED light kit with opal frosted glass provides

additional energy and cost-saving benefits. Plus, it eliminates the need to change lamps in hard-to-reach ceiling fans.

• Remote control included: operates six speeds, on/off function for fan

and light and reverse function for summer/winter comfort.

Techno II

2

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72042 72" Black Black Opal Frosted Glass 165M DC Motor 12° 3/4" X 4" Down Rod Only 54" 7234 233

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost**  17.5 100 3000 1250 80 25000 22.8 $2.11

Integrated Light Source * Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Techno II

3

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72039 72" Titanium Titanium Opal Frosted Glass 165M DC Motor 12° 3/4" X 4" Down Rod Only 54" 7234 233

• The contemporary 72” Techno II featuring a Titanium finish is

designed to cool large areas and lofts.

• Energy-efficient DC motor consumes about 60% less energy than an

AC fan. This means reduced operating costs and a minimized environmental impact.

• Lengthy ABS blades are accentuated by subtle curves and provide

powerful air circulation.

• Integrated dimmable LED light kit with opal frosted glass provides

additional energy and cost-saving benefits. Plus, it eliminates the need to change lamps in hard-to-reach ceiling fans.

• Remote control included: operates six speeds, on/off function for fan

and light and reverse function for summer/winter comfort.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost**  17.5 100 3000 1250 80 25000 22.8 $2.11

Integrated Light Source * Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Zephyr

4

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72046 56" Brushed Nickel Rich Walnut/Maple Opal Frosted Glass 172mm X 20mm SS Motor 12° 3/4" X 6" Down Rod Only 54" 5450 79

• Square-edged blades and brackets add a distinctive modern touch to

the 56” Zephyr.

• LED light kit with opal frosted glass includes 2 dimmable T7 LED

lamps that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• 56” size makes the Zephyr ideal for great rooms, large living areas

and bedrooms.

• Remote control included for convenient operation.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 25000 22.8 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Alloy II

5

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72051 52" Brushed Nickel Rosewood/Light Maple Opal Frosted Glass 153mm X 17mm SS Motor 10° 3/4" X 4" Down Rod Only 54" 4584 76

• Popular Alloy design is refashioned into a new contemporary ceiling
• fan. The Alloy II features 6 slender blades with a new square shape.
• Reversible blades offer complementary finish options to customize

the look of the fan. A subtle Light Maple finish and contrasting Rosewood are stunning against the classic Brushed Nickel finish of the fan.

• LED light kit with opal frosted glass includes (2) T7 LED lamps that

provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Alloy LED

6

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72053 52" Gun Metal Black/Applewood Opal Frosted Glass 153mm X 17mm SS Motor 13° 3/4" X 4" Down Rod Only 54" 3576 59

• Sleek Gun Metal finish adds a modern edge to the 52” Alloy fan,

a popular design that continues to trend.

• Reversible blades offer the option of Black for a monochromatic

look or Applewood for more classic transitional styling.

• LED light kit with opal frosted glass includes (2) T7 LED lamps

that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Alloy LED

7

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72090 52" Brushed Nickel Beech/Wengue Opal Frosted Glass 153mm X 17mm SS Motor 13° 3/4" X 4" Down Rod Only 54" 3576 59

• The classic 52” Brushed Nickel Alloy fan has improved energy-

efficiency with the addition of an LED light kit.

• LED light kit with opal frosted glass includes (2) T7 LED lamps that

provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Alta Vista

8

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72059 52" Matte Black Black/Bleached Cherry Opal Frosted Glass 153mm X 17mm SS Motor 12° 3/4" X 4" Down Rod Only 54" 4789 81

• The contemporary Alta Vista is a stylish, energy-efficient choice for

larger living areas and bedrooms.

• A versatile Matte Black finish suggests a hint of drama on the 52”

Alta Vista fan.

• Integrated dimmable LED light kit with opal frosted glass provides

additional energy and cost-saving benefits.

• Integrated LED eliminates the need to change lamps in hard-to-

reach ceiling fans.

• Remote control included for convenient operation.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost**  18 75 3000 1080 80 25000 22.8 $2.17

Integrated Light Source * Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Bendan LED

9

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72065 52" Brushed Nickel Catalpa Wood Opal Frosted Glass 153mm X 17mm SS Motor 12° 3/4" X 4" Down Rod Only 54" 4452 72

• An integrated LED light kit enhances the exceptional energy-saving

performance of the Bendan ceiling fan.

• This well-recognized fan gets a modern-day makeover with

hammered accents on the fan’s housing and a new Catalpa Wood finish on the elegantly-shaped blades.

• Integrated dimmable LED light kit with opal frosted glass provides

additional energy and cost-saving benefits. Plus, it eliminates the need to change lamps in hard-to-reach ceiling fans.

• Remote control included for convenient operation.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost**  17.5 100 3000 1250 80 25000 22.8 $2.11

Integrated Light Source * Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Desoto

10

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72074 52" Oil Rubbed Bronze Mahogany/Cherry Opal Frosted Glass 153mm X 17mm SS Motor 12° 3/4" X 6" Down Rod Only 54" 4861 81

• The eye-catching Desoto ceiling fan features a rich Oil Rubbed

Bronze finish and a versatile contemporary design.

• This fan is distinguished by a unique, free-floating blade bracket

design and 4 beautiful Mahogany blades.

• LED light kit with opal frosted glass includes (2) T7 LED lamps that

provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Thurlow

11

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72076 54" Weathered Bronze Driftwood/ Reclaimed Hickory N/A 153mm X 17mm SS Motor 12° 3/4" X 6" Down Rod Only 54" 5045 83

• The Thurlow fan truly makes a statement and can adapt to a variety
• f home décor styles, from industrial vintage to traditional.
• Ideal for cooling great rooms, large living areas and bedrooms, the

Thurlow has a 54” blade-span.

• Contrasting Weathered Bronze and Brushed Nickel finishes call

attention to a distinctive blade bracket design that adds to its industrial appeal.

• Two new distressed blade finishes, Driftwood and Reclaimed

Hickory, enhance the vintage character.

Cayuga

12

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72077 60" Brushed Nickel Rosewood/Light Maple Opal Frosted Glass 188mm X 20mm SS Motor 11° 3/4" X 6" Down Rod Only 54" 6098 75

• The 60” Brushed Nickel Cayuga fan with 6 blades looks
• utstanding as it cools any larger space, from great rooms to large

bedrooms.

• The offset blade brackets add uniqueness to the design.
• LED light kit with opal frosted glass includes 2 dimmable T7 LED

lamps that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• Remote control included for convenient operation.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 25000 22.8 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Cayuga

13

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72078 60" Oil Rubbed Bronze Applewood/Cherry Opal Frosted Glass 188mm X 20mm SS Motor 11° 3/4" X 6" Down Rod Only 54" 6098 75

• The 60” Oil Rubbed Bronze Cayuga fan with 6 blades looks
• utstanding as it cools any larger space, from great rooms to large

bedrooms.

• The offset blade brackets add uniqueness to the design.
• LED light kit with opal frosted glass includes 2 dimmable T7 LED

lamps that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• Remote control included for convenient operation.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 25000 22.8 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Vintage

14

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72079 52" Oil Rubbed Bronze Rosewood/Light Maple Frosted Ribbed Glass 153mm X 15mm CRS Motor 11° 3/4" X 4" Combo 78" 3835 60

• Add charm to any space with our traditional Vintage ceiling fan,

now available in Oil Rubbed Bronze finish with reversible Rosewood and Light Maple blades.

• Includes a 3 light kit with frosted ribbed glass shades and 3

candelabra base, 60 watt torpedo lamps.

• This combo mount type can be installed with or without the

included down rod.

Delancey LED

15

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72089 52" Brushed Chrome Silver Opal Frosted Glass 125S DC Motor 13° 3/4" X 4" Down Rod Only 78" 5206 163

• The addition of an LED light kit enhances the exceptional energy-

saving performance of the Delancey ceiling fan.

• Energy-efficient DC motor consumes about 60% less energy than

an AC fan. This means reduced operating costs and a minimized environmental impact.

• LED light kit with opal frosted glass includes 2 dimmable T7 LED

lamps that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• Remote control with six speed levels, on/off switch for fan,
• n/off/dimmer for light and a reverse switch for summer/winter
• peration.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 25000 22.8 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Castle LED

16

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72091 52" Brushed Nickel Weathered Maple/Beech Opal Frosted Glass 153mm X 15mm CRS Motor 12° 3/4" X 6" Combo 54" 3914 70

• Now offering the option of an LED light kit with our stately Castle

ceiling fan.

• LED light kit with opal frosted glass includes (2) T7 LED lamps

that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• This combo mount type can be installed with or without the

included down rod.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Turbo Swirl LED

17

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72092 30" Gun Metal Black Opal Frosted Glass 153mm X 12mm CRS Motor 18° 3/4" X 4" Combo 24" 2564 47

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 1 9 60 3000 800 80 15000 13.6 $1.08

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

• The Turbo Swirl fan boasts powerful air circulation in a compact

30” size.

• Sleek, Gun Metal fan now includes a long-lasting Omni A19 LED

lamp.

• This combo mount type can be installed with or without the

included down rod.

Tulsa LED

18

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72094 52" Brushed Nickel Rich Walnut/Bird's Eye Maple White Alabaster Glass 153mm X 17mm SS Motor 12° 3/4" X 6" Combo 54" 3315 57

• The bold traditional Tulsa fan has improved energy-efficiency with

the addition of an LED light kit.

• LED light kit with white alabaster glass includes (2) T7 LED lamps

that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

• This combo mount type can be installed with or without the

included down rod.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Carolina LED

19

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72096 52" Oil Rubbed Bronze Applewood/Cherry Amber Alabaster Glass 153mm X 17mm SS Motor 12° Hugger 12" 3361 65

• The Oil Rubbed Bronze Carolina fan, a classic hugger design, is

now available with an LED light kit.

• LED light kit with amber alabaster glass includes (2) T7 LED

lamps that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Carolina LED

20

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72097 52" Brushed Nickel Rich Walnut/Bird's Eye Maple White Alabaster Glass 153mm X 17mm SS Motor 12° Hugger 12" 3361 65

• The Brushed Nickel Carolina fan, a classic hugger design, is now

available with an LED light kit.

• LED light kit with white alabaster glass includes (2) T7 LED lamps

that provide energy and cost-saving benefits.

• Long-lasting LEDs eliminate the need to change lamps in hard-to-

reach ceiling fans.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 16 120 (2 x 60) 3000 1600 80 15000 13.6 $1.92

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Lafayette LED

21

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Down Rod Size Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72098 52" Weathered Iron Light Oak Yellow Alabaster Glass 153mm X 15mm SS Motor 12° 3/4" X 6" Combo 54" 4588 78

• The addition of an LED light kit to the Indoor/Outdoor Lafayette

ceiling fan improves its energy-efficiency and brings a cozy ambience to any space.

• Rustic LED lantern light kit with yellow alabaster glass now includes

an Omni A19 LED lamp.

• Long-lasting LEDs provide energy and cost-saving benefits, and

eliminate the need to change lamps in hard-to-reach ceiling fans.

• This combo mount type can be installed with or without the

included down rod.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 1 9 60 2700 800 80 25000 22.8 $1.08

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Sumter LED

22

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72131 52" Classic Bronze Applewood With Shade/Dark Cherry Amber Alabaster Glass 153mm X 15mm CRS Motor 12° Hugger 12" 354 6

• Add a touch of traditional sophistication and year-round comfort to

your home with the classic bronze Sumter LED fan.

• Hugger mount style is perfect for large rooms with low ceilings.
• Light kit with amber alabaster glass includes two energy-efficient

9W Omni A19 LED lamps.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 18 120 (2 x 60) 3000 1600 80 15000 13.6 $2.16

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Sumter LED

23

Fan Specifications

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72132 52" Brushed Nickel Weathered Maple/Beech White Alabaster Glass 153mm X 15mm CRS Motor 12° Hugger 12" 354 6

• Add a touch of traditional sophistication and year-round comfort to

your home with the brushed nickel Sumter LED fan.

• Hugger mount style is perfect for large rooms with low ceilings.
• Light kit with white alabaster glass includes two energy-efficient 9W

Omni A19 LED lamps.

LED Light Source Specifications

Number

• f

Lamps Total Energy Used (Watts) Equiv. Incand. Wattage Light Appearance (Kelvin) Total Lumens CRI Avg. Rated Hours Life in Years* Total

• Est. Yearly

Energy Cost** 2 18 120 (2 x 60) 3000 1600 80 15000 13.6 $2.16

* Based on 3hrs./day ** Based on 3hrs./day 11¢/kWh

Petite

24

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72133 30" Brushed Nickel Rosewood/ Light Maple Opal Mushroom Glass 153mm X 9mm CRS Motor 18° Hugger 12" 2027 44 72135 30" White White/ White Washed Pine Opal Mushroom Glass 153mm X 9mm CRS Motor 18° Hugger 12" 2027 44 72158 30" Antique Brass Walnut/Oak Opal Mushroom Glass 153mm X 9mm CRS Motor 18° Hugger 12" 2027 44

• The Petite collection of ceiling fans is now shipping with (1) 60W, candelabra base G16 ½ lamp for

added convenience.

• Designed to bring traditional charm to any small room, the versatile Petite ceiling fan includes an opal

mushroom glass shade that casts a warm glow.

• Offering big power in a 30” size, these hugger-mount ceiling fans feature three fan speeds and a

reversible switch for year-round comfort in small rooms with low ceilings.

72133 72135 72158

Casanova Supreme

25

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72136 42" Antique Brass Oak/Walnut Opal Schoolhouse Glass 153mm X 10mm CRS Motor 12° Hugger 12" 1316 27 72138 42" Polished Brass Walnut/Oak Opal Schoolhouse Glass 153mm X 10mm CRS Motor 12° Hugger 12" 1316 27 72144 42" White White/ White Washed Pine Opal Schoolhouse Glass 153mm X 10mm CRS Motor 12° Hugger 12" 1316 27

• The Casanova Supreme fans now include (1) 60W, candelabra base G16 ½ lamp for added convenience.
• The classically-styled Casanova Supreme ceiling fan offers comfort in a traditional silhouette and includes an
• pal schoolhouse glass shade that casts a welcoming, bright light.
• Available in a variety of finishes to match any décor.

72136 72138 72144

Hadley

26

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72128 42" Brushed Nickel Dark Cherry/ Rosewood White Alabaster Glass 153mm X 10mm SS Motor 12° Hugger 12" 2788 56 72130 42" Oil Rubbed Bronze Applewood/Cherry White Alabaster Glass 153mm X 10mm SS Motor 12° Hugger 12" 2788 56

• The Hadley 42” collection now includes (2) 60W, candelabra base G16 ½ lamps for added convenience.
• The 42” hugger mount style is perfect for cooling small to medium size rooms with low ceilings.
• An elegant white alabaster bowl light kit complements the brushed nickel and oil rubbed bronze finishes.

72128 72130

Contempra Trio

27

Item No. Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72149 42" Oil Rubbed Bronze Dark Cherry/Walnut Frosted Glass 153mm X 10mm CRS Motor 12° Hugger 12" 2829 51 72150 42" White White/ White Washed Pine Frosted Glass 153mm X 10mm CRS Motor 12° Hugger 12" 2829 51 72151 42" Satin Brass Walnut/Maple Frosted Glass 153mm X 10mm CRS Motor 12° Hugger 12" 2829 51 72157 42" Antique Brass Oak/Walnut Frosted Glass 153mm X 10mm CRS Motor 12° Hugger 12" 2829 51 72159 42" Brushed Nickel Rosewood/ Bird’s Eye Maple Frosted Glass 153mm X 10mm CRS Motor 12° Hugger 12" 2829 51 72149 72151 72150 72159 72157

• The classic Contempra Trio collection is now shipping with (3) 40W, candelabra base torpedo lamps for

added convenience.

• The 42” hugger mount style is perfect for small to medium size rooms with low ceilings.
• A cluster of 3 frosted shades emits bright, beautiful illumination.
• Available in a variety of popular finishes to match any traditional décor.

Contempra IV

28

Size Finish Blade Finish Glass Motor Type & Size Blade Pitch Mount Type Lead Wire Length Airflow (ft3/min) Airflow Efficiency (ft3/min/watt) 72160 52" Brushed Nickel Rosewood/ Bird's Eye Maple Frosted Ribbed Glass 153mm X 15mm CRS Motor 11° Hugger 12" 3341 57 72162 52" Oil Rubbed Bronze Dark Cherry/Walnut Frosted Ribbed Glass 153mm X 15mm CRS Motor 11° Hugger 12" 3341 57 72163 52" Antique Brass Oak/Walnut Frosted Ribbed Glass 153mm X 15mm CRS Motor 11° Hugger 12" 3341 57 72164 52" White White/ White Washed Pine Frosted Ribbed Glass 153mm X 15mm CRS Motor 11° Hugger 12" 3341 57 72165 52" Polished Brass Walnut/Oak Clear Ribbed Glass 153mm X 15mm CRS Motor 11° Hugger 12" 3341 57

• The classic Contempra IV collection is now shipping with (4) 40W, candelabra base torpedo lamps for

added convenience.

• The 52” hugger mount style is perfect for large rooms with low ceilings.
• A cluster of 4 frosted ribbed shades provides bright illumination.
• Available in a variety of popular finishes to match any traditional décor.

72163 72160 72162

Available in May

72164 72165

Available in May

For additional information or to place your order, call us at 800.999.2226, email your order to

• rders@westinghouselighting.com or contact your

Westinghouse Lighting Sales Representative.

Specifications are subject to change without notice. Please visit www.westinghouselighting.com for the latest information.

Contact Westinghouse
